Triol MT01 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R O U T E R
М Т 0 1
V e r s i o n
v
1 . 0
0 5 . 2 0 1 5
А Т . 6 8 7 4 2 2 . 0 5 2
O M
e v e r i t h i n g
n e w
e m e r g e s
n o w

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Triol MT01

  • Page 1 R O U T E R М Т 0 1 V e r s i o n 1 . 0 0 5 . 2 0 1 5 А Т . 6 8 7 4 2 2 . 0 5 2 e v e r i t h i n g n e w e m e r g e s...

  • Page 2: Table Of Contents

    Table of Contents 1. Product designation ..................3 2. Complete set of supply ..................4 3. МТ01 basic characteristics and parameters ............4 4. МТ01 functional diagram ................... 5 5. Arrangement of МТ01 connectors and interfaces ............ 6 6. МТ01 interfaces and connectors ................. 8 6.1.

  • Page 3: Product Designation

    МТ01 operates in Client mode. In this mode a МТ01 is connected to the data collecting server and trans- mits data to it from external devices connected to this server. For operation in this mode MT01 may use any SIM-card from a local provider. In Client mode МТ01 is connected to GSM/GPRS/3G network automatically, and afterwards it estab- lishes a connection with a preset server.

  • Page 4: Complete Set Of Supply

    2. Complete set of supply МТ01 router — 1 pc. 2. МТ01 certificate — 1 pc. 3. Power receptacle — 1 pc . 4. RS232/485 – RS485 interface plug — 1 pc. 5. GSM antenna — 1 pc. 6. WAGO 209-123 mounting bracket — 2 pcs. 3.

  • Page 5: Мт01 Functional Diagram

    Operating manual 4. МТ01 functional diagram GSM/GPRS GPS antenna antenna SIM 1 SIM switch Ethernet GSM/GPRS module SIM 2 RS232/RS485 Controller Indication RS485 Voltage converter Power supply USB 2.0 T R I O L C O R P O R A T I O N w w w .

  • Page 6: Arrangement Of Мт01 Connectors And Interfaces

    5. Arrangement of МТ01 connectors and interfaces Industrial version of МТ01 in robust and light-weight casing made of aluminium is provided. Arrangement of the router connectors, interfaces and light-emitting diodes is shown in Fig. 5.1, 5.2 and 5.3. Fig. 5.1 — Right side panel Fig.
  • Page 7 Operating manual 13 12 15 14 Fig. 5.3 — LED arrangement on casing surface The following elements are numerated in Fig. 5.1, 5.2 and 5.3: USB 2.0 socket. 2. Ethernet socket. 3. RS232/485 socket. 4. Power input connector. 5. First SIM-card tray (SIM 1). 6.

  • Page 8: Мт01 Interfaces And Connectors

    6. МТ01 interfaces and connectors The following interfaces are available in a device: • USB 2.0; • 10/100 Mb Ethernet; • combined RS232/485; • power input connector; • SMA plug for GSM antenna. 6.1. USB interface Referenced in Fig. 5.1 by pos. 1. Used to connect external peripherals. Note: This interface is operable only if HOST mode is available.

  • Page 9: Rs232/485 And Rs485 Interface

    Referenced in Fig. 5.1 by pos. 3. PCB connector: DMC 1,5/ 4-G1F-3,5-LR P20THR — 1787030 (Fig. 6.3). This connector is used to connect external devices with RS232/485 interface to MT01. Fig. 6.3 — RS232/485 and RS485 interface Fig. 6.4 — PCB connector: DFMC 1,5/4 -ST-3,5-LR — 1790506.

  • Page 10: Power Input Connector

    Table 6.2 — Assigning interfaces RS232 / 485 and RS485 Contact Signal Designation RS485 A Data transfer RS485 B Data receive Earth Common for «single» RS485 interface Earth Common for «combined» RS232/RS485 interface RS485 A Data transfer RS485 B Data receive RS232 Rx Data transfer RS232 Tx...

  • Page 11: Gsm Antenna Sma Plug

    Operating manual Fig. 6.6 — PCB connector: DFMC 1,5/2-ST-3,5-LR — 1790483. Plugging part Table 6.3 — Designation of connector leads Contact Signal Designation DC supply voltage positive pole. 1, 2 Protected by fuse as well as by overvoltage (when voltage applied to the input exceeds 40 V) and incorrect polarity protection circuit.

  • Page 12: Мт01 Status Indication

    7. МТ01 status indication Four light-emitting diodes are brought out onto the МТ01 casing to inform an operator of the MT01 operating modes. Table 7.1 — Characteristics of МТ01 indicators LED color Brief Operation and No. description Power supply If glowing, МТ01 is powered on...

  • Page 13: Sim-Card Installation Into Мт01

    Operating manual 8. SIM-card installation into МТ01 To connect МТ01 to Internet using a cellular service, a SIM-card of mini-SIM format (standard SIM-card) is required. Prepare a SIM-card, whip off the query of PIN code for it. Note: Mini-SIM format differs from other card formats by its dimensions. Be careful when obtaining a SIM-card from your communications service provider as a modem is not designed for operation with SIM-cards of other formats.

  • Page 14: Мт01 Mounting

    Fig. 9.1 — WAGO 209-123 bracket Attach mounting brackets to the rear wall of the MT01 casing by self-driving screws (for this purpose two holes are provided in the casing). Mounting brackets and self-driving screws are included into the scope of supply.

  • Page 15: Мт01 Mounting On A Flat Surface

    Operating manual 9.2. МТ01 mounting on a flat surface Overall dimensions (in mm) of МТ01, its fasteners and holes for self-tapping screws are given on the draw- ing (Fig. 9.4). To mount a modem on a flat surface, make use of M3 fasteners. Two holes are provided in the modem casing (see Fig.

  • Page 16: Device Operation Description

    10. Device operation description When power is applied to МТ01, red LED 1 starts glowing, which fact indicates that MT01 is powered on. Afterwards, yellow LED 4 starts glowing. This means that a communication module is switched on. A communication module establishes communication using a certain algorithm described in Section titled «Working with SIM-cards».

  • Page 17: Setting-Up Through A Server (Using A Configuration File)

    Via RS485 w/o amplifier – up to 32 devices, and with an amplifier – up to 247 devices. RS485 A RS485 A PLUG RS485 B RS485 B MT01 RS485 A RS485 A RS485 B RS485 B RS232 Rx RS232 Tx...

  • Page 18: Internet Accessibility Setup Using Web-Interface

    To get in the router settings, enter IP-address in the address bar of a browser (Internet Explorer, Mozilla Firefox, Opera, Google Chrome, etc.) that is specified in the MT01 Manual (typically this is 10.0.0.1), where- upon press ENTER button on the keyboard (Fig. 11.4).
  • Page 19 Operating manual Fig. 11.4 — Example of address bar Enter «admin» as a user name and as a password in the pop-up window, and press OK. Then the МТ01 web-interface home page will open (Fig. 11.5). Fig. 11.5 — МТ01 web-interface home page This page displays actual settings of МТ01.
  • Page 20 To set up a connection with the Internet, move to «SIM 1» or «SIM 2» tab. For that end left click on the rel- evant button. Settings window will open upon that (Fig. 11.6). Fig.11.6 — МТ01 settings window In this window basic settings required for connection to the Internet are to be entered. Setting up mainly involves entering an access point and PIN code of the card.
  • Page 21 Operating manual Table 11.1 — Description of fields for setting up Internet connection Factory default Element Description setting Name of access point for switched cellular connection provided by Access point (APN) Void cellular service provider. Enable it if cellular service provider gives information for con- Authentification nection by authentification as for the switched cellular connec- tion.

  • Page 22: Editing Configuration File

    11.5. Editing configuration file МТ01 web-interface allows a user to edit a configuration file. Press «Read» button, whereupon an active con- figuration file will open in the window. Edited file may be saved. Overall view of the editor is shown in Fig. 11.8. Fig.

  • Page 23: Мт01 Firmware Updating (Upgrading)

    МТ01 has a local configuration file containing data required for ensuring MT01 operation within a telemetry system. A local configuration file contains data that are also required for authorization of MT01 on a server. Successful authorization makes it possible to send a configuration file to the server so that to synchronize the data.

  • Page 24: Contacts And Technical Support

    Our experts are always ready to answer your questions, to help in installation, setting up and trouble- shooting of any Triol equipment in the process of its operation. Note: Before contacting the technical support service it is advisable to update the software of the device to the up-to-date version.
