Summary of Contents for TechVision BTB40W
- Page 1 User Manuel with Installation Instructions Bluetooth Hidden Speaker System (BTB40W) www.techvision.co.uk...
- Page 2 Introduction This system uses Industry Spa Tactile Transducers, connected to a Bluetooth Amplifier, producing brilliant “Hidden Sound”. Tactile Transducers work by transferring their energy into the material they are attached to. As the surface becomes the sound board they work better with dense materials such as wood and plasterboard.
- Page 3 Specification - Tactile Transducer Speaker (Full Range) Frequency Range 20Hz – 20KHz Max Power Output 50W at 8 Ohm Dimensions 80 diameter*40mm Specification – Bluetooth Amplifier Spec Transmission Range 5m to 10m Max Power Output 2ch * 20W Voltage 12Volt DC / 4amp Dimensions (W*L*H) 133 * 88 * 45mm...
-
Page 4: Installation Guide
Installation Guide Affix the transducer plates to your chosen surface using either epoxy resin or screws. Fix the transducers to the plates using the fixing bolt provided. Plug the Red & Black connections into the rear of the amplifier. Plug the amplifier in and power on. We recommend setting the volume to 70%. Turn on your music device (phone, etc) and SEARCH for Bluetooth devices.
