Summary of Contents for Autoelectric JMP10GPBL
- Page 1 PORTABLE EMERGENCY PORTABLE EMERGENCY JUMP STARTER JUMP STARTER Owner's Manual PLEASE READ BEFORE OPERATING THIS EQUIPMENT. Model: JMP10GPBL...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS FCC NOTICE: CAUTION This equipment has been tested and found to RISK OF ELECTRC comply with the limits for a Class B digital device, SHOCK DO NOT OPEN pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful... - Page 3 IMPORTANT SAFETY INSTRUCTIONS Before using the unit , be sure to read all operating instructions carefully , please note that these are general precautions and may not pertain to your unit. For example, this unit may not have the capability ,to be connected to an outdoor antenna. 1) Read these instructions.
- Page 4 10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,and the point where they exit from the apparatus. 11) Only use attachments /accessories specified by the manufacturer. 12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with apparatus.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS 17）Overloading Do not overload wall outlets and extension cords as this can result in a risk of fire or electric Shock. 18) Object and liquid entry Never push objects of any kind into they product through openings as they may touch dangerous voltage points or short out parts that could result in fire or electric shock.
- Page 6 22) Safety check Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operation condition. 23) Wall or celling mounting The product should be mounted to a wall or celling only as recommended by the manufacturer.
-
Page 7: Location Of Controls
LOCATION OF CONTROLS (Power On/Off) Button 2. USB port 3. LED Indicators 4. USB port DC (in) Jack 6. DC 12V Output Jack (Behind the rubber cover) 7. LED Flashlight... -
Page 8: Power Source
POWER SOURCE Recharging this unit before use: This unit has a built in Li-ion rechargeable battery. Recharge it before use as follows: 1. Recharge by AC: Insert the small plug from the supplied AC/DC Adapter to the DC (in) Jack on the unit. Plug the AC/DC Adapter to wall outlet having AC 100-240V~, 50/60 Hz as the figure below: NOTES:... - Page 9 2. Recharge through the Car Cigarette Lighter Socket: Insert the small plug from the supplied car adapter to the DC (in) Jack on the unit. Insert the Car Adaptor to the Cigarette lighter socket on your car as the figure below: During charging, the Blue Indicators will light and blinking.
-
Page 10: Operation
OPERATION To start a Car: If the battery of the car was consumed, restart your car with this unit as below: 1. Connect Red clip “＋” and Black clip “－” of the supplied Car Battery Connection Cable to the “＋” and “－” contacts of your car battery. 2. - Page 11 Notes: To start a car, power of the unit must more than 40% (2 out of 5 power indicators is light when press the Power On/Off Button to check). If the power of the unit not enough, recharge the unit before connect to the car battery. If the Plug from the Car Battery Connection Cable is inserted into the unit.
- Page 12 LED FLASHLIGHT: Press and hold the (Power On/Off) Button approximately 1 second to turn the Flashlight on. In Flashlight on mode: ~ Press the (Power On/Off) Button to turn to blink mode 1 (3 short then 3 long blink circularly) . ~ Press the (Power On/Off) Button again (Total two times) to turn to blink mode 2 (Fast blinking) .
- Page 13 LIMITED WARRANTY LIMITED WARRANTY Craig warrants this product to be free from manufacturing defects in material and Surge warrants this product to be free from manufacturing defects in material and workmanship under normal use for a period of 90 days from date of purchase. If service workmanship under normal use for a period of 90 days from date of purchase.
