- Page 1 Scout Battery Sweeper Model No.: Operator and Parts Manual 608730 NOBLES 12875 RANSOM STREET HOLLAND MI 49424 U.S.A. 608794 CUSTOMER SERVICE: 1-800-365-6625 FAX: 1–800–678–4240 Rev. 01 (06-00) Home Find... Go To..
-
Page 2: Table Of Contents
Printed in U.S.A. make sure it is handed over to you in perfect working Nobles is a registered United States trademark of Tennant Company. order: To maintain the machine in this condition and Scout is a United States trademark of Tennant Company. -
Page 3: Safety Precautions
OPERATION 5. When servicing machine: SAFETY PRECAUTIONS – Avoid moving parts. Do not wear loose jackets, shirts, or sleeves. – Block machine tires before jacking The machine, composed of a brush and a suction machine up. system, is to be used EXCLUSIVELY to clean dry –... -
Page 4: Machine Controls & Components
OPERATION MACHINE CONTROLS & COMPONENTS UNCRATING MACHINE Unpack the machine with the utmost care; avoid carrying out any operation that could damage it. Once it has been unpacked, check whether it is damaged. If you notice that it is not in correct working order, DO NOT use it and inform your dealer. -
Page 5: Preparing Machine For Operation
OPERATION ATTENTION: The battery must be prepared before it is mounted on the machine. This simple PREPARING MACHINE FOR OPERATION precaution will prevent the machine from being damaged by the electrolytic liquid of the battery. 1. Mounting the side brush (Figure 1). WARNING: Batteries emit hydrogen gas. -
Page 6: Cleaning The Waste Bins
OPERATION In particular: RECHARGING BATTERY WARNING: Flammable materials or reactive metals can cause explosion or fire. Do not pick WARNING: Batteries emit hydrogen gas. Do not use the machine to clean up wires, ropes or Explosion or fire can result. Keep sparks and straps or soak up water and other liquids. -
Page 7: Machine Maintenance
OPERATION FILTER MAINTENANCE MACHINE MAINTENANCE FOR SAFETY: Before leaving or servicing machine, stop on level surface, turn off machine All service performed should be completed by persons and remove key. who understand the machine or an Authorized Service The filter is one of the machines main components. It Center. - Page 8 OPERATION To Adjust Main Brush Height: REPLACING AND ADJUSTING THE SIDE BRUSH 1. Remove the upper cover. FOR SAFETY: When servicing machine, 2. Loosen the knurled lock nut below the adjustment disconnect battery connections before working on handle and turn handle in the direction desired machine.
- Page 9 OPERATION To Replace the main drive belt: REPLACING THE FLAPS 1. Remove belt from the pulleys. FOR SAFETY: When servicing machine, 2. Replace the belt. Position belt to the right side of disconnect battery connections before working on the belt tightener roller (Figure 6). machine.
-
Page 10: Recommended Stock Items
OPERATION REPLACING THE TRACTION CABLE To remount the side brush lifting cable: FOR SAFETY: When servicing machine, 1. Put the cable inside the handle. disconnect battery connections before working on 2. Close up the handle and fix it to its support. machine. -
Page 11: Trouble Shooting Guide
OPERATION TROUBLE SHOOTING GUIDE PROBLEM CAUSE SOLUTION The machine does not Drive belt is broken. Replace belt. move forward. The main brush is not The motor has burnt out. Replace motor. spinning. A wire is detached. Repair connection. The side brush is not spin- The belt is broken. -
Page 12: Specifications
OPERATION SPECIFICATIONS Model: SCOUTt 28 MAXIMUM WIDTH WITH SIDE BRUSH 810 mm (32 in) MAXIMUM LENGTH WITH SIDE BRUSH 1160 mm (45.6 in) MAXIMUM HEIGHT WITH SIDE BRUSH 1000 mm (39.3 in) ACTUAL CLEANING WIDTH (MAIN BRUSH) 520 mm (20.5 in) WEIGHT 88Kg (194 lbs) WEIGHT OF BATTERY... -
Page 13: Wiring Diagram
WIRING DIAGRAM 12V ELECTRICAL DIAGRAM MAIN BRUSH MOTOR BLUE TRACTION MOTOR BLUE FAN MOTOR BLUE FUSE 30A 30A 20A SWITCH – BAT + SC.F BATTERY BATTERY RECHARGE + ALIM FUSE SOCKET 1A/250V FUSE SC;F + BAT #604258 Fusible Link 50A #604257 Fuse, 1A/250V KEY SWITCH Scoutt... -
Page 14: Parts List
PARTS LIST CHASSIS GROUP Scout t 28 (06–00) Home Find... Go To.. - Page 15 604224 Screw 8x10 604216 Handgrip painted 603343 Cover, rightside DRubber handle cover Ø 24/24 604217 603344 Cover, leftside 608186 Decal, Nobles Logo 603345 Cover, front 603347 Hopper, Blue 604225 Screw 8x16 DReinforced gasket 604226 Nut M 6 604221 1.5 Mt...
- Page 16 PARTS LIST ELECTRICAL/FILTER GROUP OPTIONAL ALIM. BATTERY DANGER 31 11 Scout t 28 (06–00) Home Find... Go To..
- Page 17 PARTS LIST ELECTRICAL/FILTER GROUP Ref. Part No. Description Qty. Ref. Part No. Description Qty. 604183 Dashboard’ s plate 604202 Inner snap ring Ø 16 603360 Key switch 604203 Articulated bar DKey, replacement 606197 604204 Screw 10x16 DBackside flap 604184 Bipolar switch 604205 DRight side flap 604185...
- Page 18 PARTS LIST BRUSH GROUP Scout t 28 (06–00) Home Find... Go To..
- Page 19 PARTS LIST BRUSH GROUP Ref. Part No. Description Qty. Ref. Part No. Description Qty. 604104 Side brush sheathing 604148 Outer snap ring Ø 15 603351 Handle, Drive 604149 Outer snap ring Ø 12 604105 Turned adjuster Ø 7 604150 Brush adjusting fixing pivot 603350 Lever, sidebrush drive 604151...
- Page 20 PARTS LIST DRIVE GROUP Scout t 28 (06–00) Home Find... Go To..
- Page 21 PARTS LIST DRIVE GROUP Ref. Part No. Description Qty. Ref. Part No. Description Qty. 603356 Cover, Wheel 604093 Washer 5x20 604077 Screw 6x10 604094 Pulley Ø 55 604078 Washer 6x24 604095 Screw 6x20 604079 Outer snap ring Ø 28 604096 Bearing 6000 2RS 604080 Bearing HFL 1426...
