PORTABLE DVD PLAYER

SD-P2900SR

OWNER S MANUAL

DIGITAL VIDEO

Owner's Record

The model number and serial number are on the bottom of your DVD player. Record these numbers in the spaces below.

Refer to these numbers whenever you communicate with your Toshiba dealer about this DVD player.

Model number:

Downloaded From Disc-Player.com Toshiba Manuals

Serial number:

Introduction

Preparations

Playback

Function Settings

Connections

Others

○

PX1D00001371

Table of Contents

Need help?

Do you have a question about the SD-P2900SR and is the answer not in the manual?

Questions and answers

Summary of Contents for Toshiba teli SD-P2900SR

Page 1 Introduction Preparations PORTABLE DVD PLAYER Playback SD-P2900SR OWNER S MANUAL Function Settings Connections DIGITAL VIDEO Others Owner’s Record The model number and serial number are on the bottom of your DVD player. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this DVD player.
Page 2: Safety Precautions
SAFETY PRECAUTIONS WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY. CAUTION: This equipment employs a Laser System.
Page 3 In the spaces provided below, record the Model and Serial No. located on the bottom of your DVD player. Model No. Serial No. Retain this information for future reference. About disposal The cold cathode ﬂ uorescent lamp in the LCD panel contains a small amount of mercury. Please follow local ordinances or regulations when you dispose of the product.
Page 4 SAFETY PRECAUTIONS Location of the required label Following information is only for EU-member states: The use of the symbol indicates that this product may not be treated as household waste. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This unit is fully transistorized and does not contain any parts that can be repaired by the user. DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
Page 6 IMPORTANT SAFETY INSTRUCTIONS ADDITIONAL SAFETY INSTRUCTIONS 13. When you use headphones, keep the volume 19. Do not touch a spinning disc. When you open the at a moderate level. If you use the headphones disc holder, the disc may have not stopped spinning. continuously with high volume sound, it may cause Touching a spinning disc may cause personal injury hearing damaged.
Page 7 24. Do not use this product while walking or driving. 28. Battery Pack Neglecting this may cause a trafﬁ c accident. a) Never throw the battery pack into a ﬁ re, as that could cause the battery pack to explode. 25.
Page 8 IMPORTANT SAFETY INSTRUCTIONS g) Never dispose of used battery packs with other n) Never shock the battery pack by dropping or ordinary solid wastes, since they contain toxic throwing it. substances. Always dispose of used battery packs o) If the liquid contained within the battery pack leaks, in accordance with community regulations that use a large amount of water and immediately apply to the disposal of batteries.
Page 9 30. After unpacking coin-shaped batteries, store them in Failure to observe the above instructions could poly bags, etc. separately one by one when unused. result in the driver’s inattention to and/or distraction If you leave them unwrapped, they may be short- from road hazards.
Page 10 IMPORTANT SAFETY INSTRUCTIONS e) When handling, using or storing the adapter power k) Some cars may not have a compatible socket. cord NEVER: NEVER modify this adapter to ﬁ t an incompatible Place or locate near any apparatus that produces cigarette lighter socket and/or power port.
Page 11: Precautions
Precautions Notes on handling Notes on locating Do not shock the LCD monitor. It may cause unit When you place this player near a TV, radio, or damage and malfunction. VTR, the playback picture may become poor and the sound may be distorted. In this case, move the Do not use the player in a place subject to vibration.
Page 12 Precautions (continued) Notes on moisture condensation Do not use the player when moisture condensation may occur. Moisture condensation damages the player. Please If you use the player in such a situation, it may read the following carefully. damage discs and internal parts. Remove the Moisture condensation occurs, for example, when you disc, connect the AC adapter, turn on the player, pour a cold drink into a glass on a warm day.
Page 13 About this owner’s manual Notes on region numbers This owner’s manual explains the basic instructions of The region number of this player is 5. Region numbers, this player. Some DVD video discs are produced in a corresponding to speciﬁ c geographical playback area, manner that allows speciﬁ...
Page 14: Table Of Contents
Table of contents Connecting to headphones ....... 35 Introduction Playing a disc ............36 SAFETY PRECAUTIONS ........2 Pausing playback (Still mode) .......37 IMPORTANT SAFETY INSTRUCTIONS ....5 Adjusting the volume of the speakers or the connected headphones ........37 Precautions ............11 Using the top menu ..........37 Identiﬁ...
Page 15 Changing the camera angle ....... 46 Connecting to audio equipment ......69 Connecting to an AV ampliﬁ er Selecting subtitles ..........46 (via digital audio input) ..........69 Selecting a playback sound....... 47 Connecting to an audio system equipped with Playing audio/video/picture ﬁ...
Page 16: Identiﬁ Cation Of Controls
Identiﬁ cation of Controls Instructions and actual buttons Most instructions are based on remote control operation, unless otherwise noted. You can use the buttons on the remote control and those on the main unit as well when they have the same function. Some functions are available only from the remote control.
Page 17 Downloaded From Disc-Player.com Toshiba Manuals...
Page 18 Identiﬁ cation of Controls (continued) ■ Downloaded From Disc-Player.com Toshiba Manuals...
Page 19: Accessories
Accessories Check that the following accessories are supplied. Remote control (MEDR16UX) Audio/video cable Component video cable Power cord* Coin-shaped battery (CR2025) Carrying case Headphones AC adapter (ADPV16A)* Battery pack* (SD-PBP100R) Use this for carrying, etc. of the player. Owner’s manual Vehicle adapter Do not use an AC adapter, a power cord, a battery pack and a vehicle adapter other than one specified.
Page 20: Notes And Information
Notes and Information Playable discs This player can play the following discs. Disc Disc Mark Disc Size Contents DVD Video •Video(moving pictures)+Audio 12cm/8cm disc •Video + Audio (DVD VR format (Compatible with CPRM)/DVD Video format)* 12cm DVD-RW *Finalized discs only. •Video + Audio (DVD VR format (Compatible with CPRM)/DVD Video format)* DVD-R 12cm...
Page 21 Notes On VIDEO CDs ・ You cannot play discs other than those listed left. This player supports VIDEO CDs equipped with the ・ You cannot play discs of DVD-RAM or non-standardized PBC (Version 2.0) function. (PBC is an abbreviation for discs, etc., even if they may be labeled as left.
Page 22 Notes and Information (continued) On handling discs Store discs vertically in a case. Stacking or placing objects on discs outside of their case may cause Do not touch the playback side warping. of the disc. Playback Notes on copyright side Do not attach paper or tape to discs.
Page 23 Playable memory cards Notes on memory cards This player can play the following memory cards. Some memory cards may not be played back due to its capacity and/or manufacturer, etc. Card Card Mark Contents Do not insert any memory card other than those •...
Page 24 Notes and Information (continued) Notices for use Do not place the memory card in your pants pocket. Ensure that you insert the memory card correctly into The memory card may break if any strong force is this player. applied, such as when sitting. Do not eject the memory card while it is in use.
Page 25: Preparations
Preparations Preparations before using. ● Preparation of the remote control ● Power connection ● Using the battery pack ● Powering on/off ● Changing the AV mode Downloaded From Disc-Player.com Toshiba Manuals...
Page 26: Preparation Of The Remote Control
Preparation of the remote control Insert the speciﬁ ed battery to the remote control. See Operating with the remote control page 8 , for safety use of coin-shaped batteries. Point the remote control at the remote sensor and press Gently insert a ﬁ ngernail in groove q the buttons.
Page 27: Power Connection
Power connection Connect the supplied AC adapter to wall outlet as CAUTION below. • Do not connect the power plug to a power outlet other than that indicated on the label, as this can result in a risk of ﬁ re or electric shock. •...
Page 28: Using The Battery Pack
Using the battery pack The supplied battery pack can power the player for Open the connector cover on the bottom of the player. operation outdoors or in a place with no outlets. WARNING Holes • Do not use a battery pack other than one speciﬁ ed as it can result in a ﬁ...
Page 29 Important Notes Charge the battery pack with a surrounding temperature of ・ • Detach the battery pack from the player after being +10°C to +30°C (+50°F to +86°F). used. ・ While the charge is in progress, do not disconnect the AC adapter and the power cord until the POWER indicator turns ■...
Page 30 Using the battery pack (continued) ■ Detaching the battery pack Important • After detaching the battery pack, be sure to close the Turn the player off. battery cover in order to avoid a short-circuiting which Disconnect the AC adapter and the power cord may be caused by contact with metal objects to the from the player.
Page 31: Powering On/Off
Powering on/off Slide the power switch to turn the power on or off. POWER Condition Power Switch indicator Green POWER Charging Orange indicator Power switch Downloaded From Disc-Player.com Toshiba Manuals...
Page 32: Changing The Av Mode
Changing the AV mode You can enjoy various pictures of discs or connected equipments by changing the AV mode. Change it depending on your needs. Press MODE repeatedly to select the AV mode. Each time you press MODE, the AV mode changes on the screen as below. Select when you want to view the picture of a disc on the LCD monitor of this player.
Page 33: Playback
Playback Play your favorite disc. ● Loading a disc ● Changing the camera angle ● Selecting subtitles ● Connecting to headphones ● Selecting a playback sound ● Playing a disc ● Playing audio/video/picture ﬁ les ● Changing a playback speed ●...
Page 34: Loading A Disc
Loading a disc For disc compatibility information, see page 20 . Close the disc cover. Open the LCD monitor. Press the edge around “CLOSE”. ■ To remove the disc Press OPEN on the main unit to open the disc cover and remove the disc from under the rim while gently pressing down on its center.
Page 35: Connecting To Headphones
Connecting to headphones You can connect headphones to the headphone jack CAUTION using a stereo mini plug. • Keep your ﬁ ngers clear of the disc as it is spinning. Neglecting to may cause serious personal injury. • Be careful not to catch your ﬁ ngers in the disc holder. Stereo mini plug ( ...
Page 36: Playing A Disc
Playing a disc DVD-V ■ Preparations Press STOP to stop playback. • Turn on the power of the player. • Place a disc to the player. About Resume playback function Caution The player memorizes the location where playback is Never operate the player in a moving vehicle. stopped and resumes playback from the location where Vibration may prevent proper playback of the player or cause you stopped.
Page 37: Pausing Playback (Still Mode)
Pausing playback (Still mode) Using the top menu Press PAUSE/STEP during playback. DVD-V e.g. The picture gets still and sound is muted. 1 Press TOP MENU. To resume normal playback, press PLAY. The top menu appears. 2 Press select the title you want. If the titles in the top menu are assigned a number, Adjusting the volume of the speakers or you can select the title by pressing number buttons.
Page 38 Playing a disc (continued) ■ About the screen saver ■ About the LCD If 20 minutes elapse while the power is on and there ・ The LCD panel contained in this product is is no disc in the player or while the disc is stopped, manufactured using an extremely high level of the screen saver is automatically displayed (when precision technology;...
Page 39: Changing A Playback Speed
Changing a playback speed Playing in fast reverse or fast forward Playing frame by frame DVD-V DVD-V Press REV or FWD on the remote control during Press PAUSE/STEP repeatedly during playback. playback. The sound is muted during frame by frame playback. : Fast reverse playback Press PLAY to resume normal playback.
Page 40: Playing A Desired Scene
Playing a desired scene DVD-V Skipping chapters or tracks Press to select the category you want to search. Press SKIP ( ) repeatedly to locate the chapter or track you want. Category To search by specifying: Title* Title number Playback starts from the selected chapter or track. Chapter* Chapter number ：...
Page 41: Marking The Desired Position To Locate (Bookmark Function)
Notes ■ To register a bookmark • Press the CLEAR button while pressing the SHIFT You can register up to 3 bookmarks. button to reset the numbers. • Some discs may not respond to this process. 1 At a scene where you want to register a •...
Page 42: Playing In Random Order
Playing in random order Playing repeatedly DVD-V DVD-V Repeating a speciﬁ c segment During playback, press RANDOM to display “Shufﬂ e on” on the screen. Press A-B RPT at the beginning of the segment (point A) you want to play Each time you press the button, the random mode repeatedly.
Page 43: Repeating A Title, Chapter Or Track
Notes Repeating a title, chapter or track • Some discs may not permit repeat playback. • The repeat mode will be canceled when you: During playback, press REPEAT – turn off the power. repeatedly to select the repeat mode. – open the disc cover. •...
Page 44: Playing In A Favorite Order
Playing in a favorite order DVD-V During stop, press MEMORY. Press to select “Play Program” then press ENTER. The programming display appears. The player starts memory playback. e.g. : DVD-V ■ To cancel the programmed selections Enter a track number when Program using a video CD.
Page 45: Zooming A Picture
Zooming a picture DVD-V ■ To resume normal playback Press ZOOM during playback. Press ZOOM repeatedly until “OFF” appears. The zoom icon appears. This operation is available Notes also during slow, still, fast • Some discs may not respond to zoom feature. forward or fast reverse •...
Page 46: Changing The Camera Angle
Changing the camera angle Selecting subtitles DVD-V DVD-V Press ANGLE while playing a scene Press SUBTITLE during playback. recorded with multiple camera angles. The current subtitle setting is displayed. The angle icon ( ) appears on the screen. Press SUBTITLE while the subtitle e.g.
Page 47: Selecting A Playback Sound
Selecting a playback sound Good morning! ¡Buenos días! Bonjour! DVD-V ■ Selecting sound channels of VIDEO CDs Press AUDIO during playback. During playback, press AUDIO repeatedly to select The current audio setting is displayed. the sound channel. e.g. D 2 ch Notes Sound recording Audio language...
Page 48: Playing Audio/Video/Picture Fi Les
Playing audio/video/picture ﬁ les This player requires discs/recordings to meet certain technical standards in order to achieve optimal playback quality. There are many different types of recordable disc formats (including CD-R containing MP3/WMA ﬁ les). Not all recordable discs DVD-V will operate or produce optimal playback quality.
Page 49 How to use a memory card Insert a memory card into the slot. Note ・ Do not eject the memory card while it is in Press MODE repeatedly until use. If ejected while in use, information on “ (Memory card)” appears. the memory card may be lost.
Page 50 Playing audio/picture ﬁ les (continued) ■ Playing repeatedly Notes ・Some media ﬁ les may not permit playback. Select “Repeat” on the screen using ・Some functions such as SKIP ( ) can be operated during playback then press ENTER. from the remote control directly. Each time you press ENTER, the repeat mode changes.
Page 51 ■ Playing in a favorite order ■ To display recorded track/ﬁ le You can combine your favorite track/ﬁ le and play in Select “Browser view” on the screen then press the order you determine. ENTER. 1 Select “Edit mode” on the screen using The track/ﬁ...
Page 52: Selecting The Sound Enhancement
Selecting the sound enhancement Adjusting the picture DVD-V DVD-V This function operates on the LCD of this player only. Press E.A.M.* Press PICTURE. The current sound enhancement setting appears. * E.A.M. = Enhanced Audio Mode The current picture setting appears. Press PICTURE repeatedly to select the Press E.A.M.
Page 53: On-Screen Display Mode
On-screen Display mode DVD-V Press to adjust the value. Press DISPLAY while pressing SHIFT during playback. Brightness 0 (Darker) to 16 (Brighter) The current instructional information appears. Contrast 0 (Lower) to 16 (Higher) e.g.: DVD video disc Color 0 (Paler) to 16 (Deeper) ...
Page 54 Downloaded From Disc-Player.com Toshiba Manuals...
Page 55: Function Settings
Function Settings You can change the default settings to customize performance to your preference. ● Customizing the function settings Downloaded From Disc-Player.com Toshiba Manuals...
Page 56: Customizing The Function Settings
Customizing the function settings DVD-V You can change the default settings to customize Change the selection by performance to your preference. other buttons, by referring to the Press SETUP during stop. corresponding pages , then press ENTER. The setting menu appears. To change other settings, press , then repeat steps Press...
Page 57 Video Aspect Ratio To select a picture size according to the aspect ratio DVD-V of your TV, when connected to this player to monitor playback picture. View Mode To select a picture size of the LCD. DVD-V Video out To set the connection terminal to use when you want DVD-V to connect and output to an external device.
Page 58 Customizing the function settings (continued) ■ Language Audio DVD-V English: To play sound tracks in English. OSD Menu DVD-V French: To play sound tracks in French. English: To view on-screen displays in English. Spanish: To play sound tracks in Spanish. Français: To view on-screen displays in French.
Page 59 ■ Video DivX subtitle Western European: To display subtitles in west Aspect Ratio DVD-V European language. Central European: To display subtitles in Central 4:3 : Select when a standard 4:3 TV is connected. European language. Cyrillic: To display subtitles in Cyrillic 16:9 : Select when a 16:9 wide TV is connected.
Page 60 Customizing the function settings (continued) View Mode DVD-V Video out DVD-V Off: Fill: Pictures are expanded horizontally and For normal use. vertically to ﬁ t the shape of the screen. No Playback pictures appear on the LCD of this player. picture cropping.
Page 61 ■ Audio Digital Out DVD-V Bitstream: E.A.M. DVD-V Select when connected to an ampliﬁ er equipped with a Dolby Digital, DTS, MPEG1 or MPEG2 decoder. Normal: The player outputs digital audio signal in the bitstream Normal sound. format when you play a DVD video disc recorded in the Dolby Digital, DTS, MPEG1 or MPEG2 recording To obtain expansive virtual surround sound effects from system.
Page 62 Customizing the function settings (continued) ■ Rating 3 Press to select “Parental control” and enter the password you set then press ENTER. Parental control DVD-V 4 Press ENTER while selecting “Parental control”. DVD video discs equipped with the parental lock 5 Press to select the parental level to set and function are rated according to their content.
Page 63 ■ To change your 5-digit security code ■ Default 1 After selecting “Set password”, press the 9 button ﬁ ve times then press ENTER. Default The 5-digit security code is cleared. No : 2 After selecting “Set password”, press the number To not restore the function settings to their default buttons to create a new 5-digit security code.
Page 64 Downloaded From Disc-Player.com Toshiba Manuals...
Page 65: Connections
Connections You can connect the player to a TV or audio system. ● Viewing on a connected TV ● Viewing pictures from connected video equipment ● Connecting to audio equipment ● Using the automobile/vehicle adapter or power port Downloaded From Disc-Player.com Toshiba Manuals...
Page 66: Viewing On A Connected Tv
Viewing on a connected TV You can connect a TV to this player to view playback picture on it. Precedence of signal quality is COMPONENT > S VIDEO > AV OUT. Via the AV OUT jack Via the S VIDEO jack To S-Video input Signal flow S-Video cable (not supplied)
Page 67: Via The Component Video Connector
Notes Via the COMPONENT VIDEO connector • Refer to the owner’s manual of the connected TV as well. • When you connect the player to your TV, be sure to turn off To component video input the power and unplug both units from the wall outlet before making any connections.
Page 68: Viewing Pictures From Connected Video Equipment
Viewing pictures from connected video equipment You can use the LCD of this player to monitor pictures of connected video equipment. Connect video equipment to the AV IN Press MODE repeatedly so that “ jack of this player. IN)” appears on the LCD. The player is ready to display pictures of the connected equipment on the LCD.
Page 69: Connecting To Audio Equipment
Connecting to audio equipment Connecting to an AV ampliﬁ er (via You can enjoy high quality dynamic sounds by connecting the player to audio equipment. digital audio input) The connecting method depends on the types of audio input, digital or audio. Signal flow Select the method according to the type of your equipment.
Page 70: Connecting To An Audio System Equipped With Analog Audio Inputs
Connecting to audio equipment (continued) Connecting to an audio system equipped CAUTION with analog audio inputs • When you are connecting (via the BITSTREAM/PCM jack) an AV decoder that does not have Dolby Digital, DTS or MPEG2 decoding function, be sure to set “Digital Signal flow Out”...
Page 71: Using The Automobile/Vehicle Adapter Or Power Port
Using the automobile/vehicle adapter or power port For use of the DVD player in a car, this adapter can • ALWAYS use caution when touching the adapter, cigarette lighter socket or power port. The adapter, lighter socket and power the DVD player from the cigarette lighter socket. power port may become heated after prolonged use.
Page 72 Using the automobile/vehicle adapter or power port (continued) 1 Turn off the DVD player. Notes • Never operate the player in a moving vehicle. Vibration may 2 Insert the pin plug of the adapter into the DC IN prevent proper playback of the player or cause damage to 12V jack of the DVD player.
Page 73: Others
Others Useful informations. ● Output sound conversion table ● Before calling service personnel ● Speciﬁ cations Downloaded From Disc-Player.com Toshiba Manuals...
Page 74: Output Sound Conversion Table
Output sound conversion table Audio selection and outputs “Bitstream” “Analog 2ch” “PCM” Sound recording system Discs BITSTREAM/PCM Speakers/AV OUT jack/ BITSTREAM/PCM Speakers/AV OUT jack/ BITSTREAM/PCM Speakers/AV OUT jack/ jack Headphone jacks jack Headphone jacks jack Headphone jacks Bitstream Dolby Digital Bitstream 48 kHz Linear...
Page 75: Before Calling Service Personnel
Before calling service personnel Check the following guide for the possible cause of a problem before contacting service. Symptom Cause Correction No power. • The AC adapter or power plug is • Connect the AC adapter or power plug securely. disconnected.
Page 76 Before calling service personnel (continued) Symptom Cause Correction The player does not start • No disc is inserted. • Insert a disc. playback. • An unplayable disc is inserted. • Insert a playable disc. (Check the disc type, colour system and region number.) •...
Page 77: Speciﬁ Cations
Speciﬁ cations ■ Player ■ Connectors Power supply AV output (AV OUT) DC 12 V (Rated current : 2 A (Maximum: during battery ø3.5mm mini jack × 1 pack charging)) Video: 1.0 V (p-p), 751, negative sync., 100 – 240 V AC, 50/60 Hz (with the supplied AC adapter) Audio: 2.0 V (rms), 1001 Mass AV input (AV IN)
Page 78 Speciﬁ cations (continued) ■ Liquid crystal display ■ Supplied accessories Audio/video cable ............1 Panel size 25.9 cm (10.2 inches diagonally measured) Remote control (MEDR16UX)..........1 Coin-shaped battery (CR2025)........1 Projection system TN colour transmission AC adapter (ADPV16A).............1 Driving system Power cord.................1 Amorphous silicon TFT active matrix Battery pack (SD-PBP100R)..........1 Resolution Component video cable.............1...
