ELECTRONIC ENGINEERING LTD.
CSB - 60
Microwave barrier
Outdoor Detector 60m Range
INSTALLATION INSTRUCTIONS
&
USER MANUAL
P/N 7111060 Rev. 1.0 Y.S/A.Y
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CSB - 60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Crow CSB - 60

  • Page 1 ELECTRONIC ENGINEERING LTD. CSB - 60 Microwave barrier Outdoor Detector 60m Range INSTALLATION INSTRUCTIONS & USER MANUAL P/N 7111060 Rev. 1.0 Y.S/A.Y...
  • Page 2 The CSB-60 is a bi-station microwave detector for outdoor applications. It comprises a transmitter (T) and receiver (R) which, when mounted facing each other, create a perimeter protection with coverage of up to 60m. The dimensions of the antenna’s lobe vary according to the chosen antenna, the distance between the two units and the selected system sensitivity.
  • Page 3 Installation instructions. Selecting mounting location The installation of the CSB-60 requires that the transmitter and the receiver face each other, so that the two antennas may be correctly aligned. The two units must be positioned in direct line at the edge of the area. Local conditions of the protected zone must be free from obstacles like walls, fences, trees and ditches or other microwave detectors and systems of anti-intrusion surveillance.
  • Page 4 Maximum lenght of protection zone = 60 m Maximum width of protection zone = 8m Maximum hight of protection zone = 3m Instalation height = 1 ~ 1.5 m Dead Zone 1.5~2 m Maximum depth of snow on the Maximum height of grass on ground = 0.5 m the ground = 0.3 m Fig.1.
  • Page 5 install an equal number of CSB-60 systems (T and R) in order to close the perimeter completely. The optimal way is to install transmitters (T) only or receivers (R) only at the point of overlap. Receiver Receiver Transmitter Transmitter Transmitter Receiver Fig.
  • Page 6: Terminal Block Connections

    TERMINAL BLOCK CONNECTIONS Fig. 5. PCB Layout. Transmitter Board Receiver Board Terminal Block Sensitivity Jumper Tamper switch Terminal Block - 12V + TAMP NO C NC +12V - TEST Terminal 1 - Marked “ - ” ( - 12V ) Terminal 1 - Marked “...
  • Page 7 CONTROL UNIT WIRING CONNECTIONS Receiver board Sensitivity Jumper -12V+ TAMP NO C Tamper switch Control panel +12Vdc ALARM POWER BOARD SUPPLY (For normal closed 12-30 V alarm circuit) -12Vdc Test button Transmitter Board - TEST Fig. 6. Control Unit and CSB-60 – Wiring Diagram...
  • Page 8 TEST AND TUNING Fig. 7. CSB-60R - Receiver unit Fig. 8. CSB-60T - Transmitter with binding band. unit with binding band. For preliminary set-up, focus the receiver and transmitter as if a virtual direct line connects the receiver and the transmitter. Make sure that the antenna’s radiating surfaces of R and T are parallel (radiating surface is perpendicular to the virtual direct line).
  • Page 9 Test procedure Walk Test After tuning the sensitivity, connect 12Vdc power to the system. Allow 2 minutes warm-up time. Make sure that the protected area is cleared of all people. Cross the middle part of the protected area. An alarm signal should be received in the control unit for 3 Sec. NOTE: Walk Test procedure should be conducted, at least once a year, to confirm proper operation and coverage of the detector.
  • Page 10: Specifications

    SPECIFICATIONS Microwave Frequency 2.45 GHz Modulation Frequency 2.5 KHz Maximum Transmitting Power 10mW (Continues) 25mW (Peak) Scope (Length of protection zone) Max. 60 m Lobe Width Approx. 8 m Lobe Height Approx. 3 m Power Supply Voltage 12...30 V Transmitter - 20 mA at 12Vdc Current consumption Receiver - 20 mA at 12Vdc Relay contacts values...
  • Page 11 There are no warranties, expressed or implied, of merchantability or fitness for a particular purpose or otherwise, which extend beyond the description on the face hereof. In no case shall CROW be liable to anyone for any consequential or incidental damages for breach of this or any other warranty, expressed or implied, or upon any other basis of liability whatsoever, even if the loss or damage is caused by CROW’s own...
