Summary of Contents for ABTronic X8S
- Page 1 ABTRONIC™X86S Fitness Belt PAGE 1 USER MANUAL...
- Page 2 PAGE 2 ABTRONIC™X8S Fitness Belt Congratulations on your choice of the ABTRONIC™X8S Fitness Belt. Please read this manual before first use. CONTROLS PROGRAM Button to change 6 programs LED Light 2 LED Light 1 OFF/- Button, decrease Intensity ON/+ ...
- Page 3 3. MODE : This button “M” is used to select one of the 6 preprogrammed exercise modes. The setting is indicated by the color and location of the two LED lights on the unit. The AbTronic™X8S unit has the following 6 exercise modes: Program LED 1 LED 2...
-
Page 4: Operation
PAGE 4 ABTRONIC™X8S Fitness Belt OPERATION BATTERY 1. Open the battery door by pushing it in the direction of the arrow: 2. Insert one piece CR 2032 Lithium battery into the battery compartment. The positive “+” pole of the battery should be facing you. -
Page 5: Basic Use
ABTRONIC™X86S Fitness Belt PAGE 5 BASIC USE 1. Attach the Abtronic™X8S control unit onto the X silicon pad holder. Insert the controller by aligning the marking on the controller case with the holder: Insert the control unit aligning it with the shorter marking... - Page 6 PAGE 6 ABTRONIC™X8S Fitness Belt APPLYING GEL SHEETS Precautions Do not use damaged, worn or dirty gel sheets as this „ might result in burns. Always, stick gel sheets to all electrodes while using the „ product. Don’t apply the product directly to skin, this may be painful or cause irritation or burns.
- Page 7 ABTRONIC™X86S Fitness Belt PAGE 7 3. After affixing all gel sheets properly, peel off the remaining film, which has wording, and ready to stick on your skin Do not peel off the gel sheet affixed to the electrode, until you need to replace them with new ones! 4.
- Page 8 Please see below diagram with recommended exercise points. However, the ABTRONIC™X8S is a personalized training tool and can be adapted to suit the individual. If the below contractions are not effective, please the unit over the area closest. Use the optional provided elastic belt for additional support to hold the unit in position, if needed.
- Page 9 PAGE 9 FRONT BACK Control Unit: 1. Press the ON/+ button to power up the ABTRONIC™X8S control unit. 2. Select the Mode by pressing the “Mode” button repeatedly. Every time you press the “Mode” button a different LED or combination will light up indicating...
- Page 10 PAGE 10 ABTRONIC™X8S Fitness Belt If you do not feel any stimulation reposition the product 1-2 cm at a time up or down, until you find the trigger points for the muscle stimulation. Please turn the unit off before repositioning! ...
- Page 11 ABTRONIC™X86S Fitness Belt PAGE 11 4. The intensity has 10 steps. With every push of the button ON/+ you increase the intensity by one step, with every push of the button OFF/- you decrease the intensity by one step. To switch the unit off, press the OFF/- button several times, until the LED lights go off.
- Page 12 Important Notes If there is no gel sheet on the ABTRONIC™X8S, or if it is not placed tightly against the skin, an uncomfortable tingling sensation can occur. This can also happen if the body has built up excessive oils on the skin.
-
Page 13: Care And Cleaning
ABTRONIC™X86S Fitness Belt PAGE 13 TAKING CARE OF YOUR UNIT The ABTRONIC™X8S is made of quality materials. The only maintenance required with the ABTRONIC™X8S is to clean the conductive area gently, while you are replacing the gel sheets, with a wet cloth and soapy water, further the battery needs to be replaced. -
Page 14: Important - Please Read
Q. Can this machine be used for all ages? A. Yes - absolutely. ABTRONIC™X8S is not age dependent and can be used at any age. However, the very elderly and children should use it under supervision and, keep the intensity low. - Page 15 ABTRONIC™X8S into your program. Q. I am getting a prickling sensation but no contraction. A. Move the ABTRONIC™X8S slightly to find the right trigger points that give maximum contractions and the most pleasant feeling. Try increasing the intensity. This could also be caused because either the gel sheet worn or dirty, or is not tightly placed against the skin.
- Page 16 „ undiagnosed pain syndromes and hemorrhagic diseases. ABTRONIC™X8S should NOT be used on injured or „ otherwise impaired muscles ABTRONIC™X8S should NOT be used on the heart area. „ WARNINGS 1. The long-term of chronic electrical stimulation are unknown. 2. Apply electrodes ONLY to normal, intact, clean skin.
- Page 17 4. Never use the ABTRONIC™X8s while driving, operating machinery or during activities in which involuntary muscle contractions may endanger the user or others. 5. Do not use the ABTRONIC™X8s in the bath or shower 6. Persons with suspected heart problems or epilepsy should obtain appropriate medical advice.
-
Page 18: Adverse Effects
Recommended Age The ABTRONIC™X8S is not suitable to use for infants or toddlers, it is suitable to use at any other age, however, the very elderly and children should use it under supervision... -
Page 19: Troubleshooting Guide
ABTRONIC™X86S Fitness Belt PAGE 19 TROUBLE SHOOTING GUIDE PROBLEM POSSIBLE CAUSE SOLUTION LEDs do not Batteries are Install batteries „ „ light up at all not installed Batteries Check polarity „ „ are installed “+” sign incorrectly. Batteries are Replace „... - Page 20 PAGE 20 ABTRONIC™X8S Fitness Belt LEDs light up, Intensity set to Increase „ „ but nothing low level intensity by occurs pushing the up button Worn or dirty Make sure the „ „ gel sheets. gel sheets are still adhesive Otherwise use „...
-
Page 21: Specification
ABTRONIC™X86S Fitness Belt PAGE 21 SPECIFICATION Channel: Single Channel Program Modes 6 Program Modes Intensity Control: Adjustable 0-28uA, Max output 28uA peak to peak into 10k ohm load each channel. Wave Form Asymmetrical Bi-Phase Square Pulse Out Voltage Adjustable 0-168V, Max output 168V peak to peak into 10k ohm load each channel. - Page 22 This product is brought to you by: AbTronic by Red Lemon Incorporation www.abtronic.co www.red-lemon.com © by Red Lemon Incorporation MMXV RLX8sEngV1.2...
