Summary of Contents for Atmel AT85RFD-07
- Page 1 AT85RFD-07 Getting Started User Guide...
-
Page 2: Table Of Contents
AT85RFD-07 Getting Started User Guide Table of Contents Section 1 Introduction ... 1-1 Atmel Registration...1-1 Section 2 Package Download ... 2-3 Web Site download ...2-3 Nand Flash Download...2-3 Package Content ...2-4 Section 3 Tools Install... 3-5 Requirement ...3-5 In System Programming...3-5 3.2.1... -
Page 3: Introduction
Registration AT85RFD-07 Getting Started User Guide The AT85RFD-07 Starter Kit is designed to give designers a quick start to develop code on the AT85C51SND3Bx as well as for prototyping and testing of new designs. In order to keep posted on any new information concerning the AT85C51SND3Bx prod- ucts (new firmware delivery, new tool version, …) register at the following address:... -
Page 4: Section 2 Package Download
Download AT85RFD-07 Getting Started User Guide The Nand Flash memory of the AT85RFD-07 is delivered pre-programmed with the demo firmware and AT85C51SND3B documentation. Since the board is manufactured in large quantities, the package may be out of date. It is strongly recommended to down- load the latest version of the AT85C51SND3B package from our web site. -
Page 5: Package Content
Package Download Package Content 7712A–MP3–02/07 2. Open the AT85RFD-07 disk, its content is as follows: The Atmel directory contains the AT85C51SND3B package. The Update directory is the location where to place the update package for the auto- matic firmware upgrade feature (see firmware user’s guide). -
Page 6: Section 3 Tools Install
The in system programming install consists of: Atmel MusicPlayerIsp Tool ™ Java Run time Environment if necessary To install the Atmel MusicPlayerIsp, go to “Atmel\at85c51snd3b\Tools\In System Pro- gramming” directory and execute music-player-isp-X_Y_Z.exe; where X_Y_Z is the tool revision number. Press Next to proceed... - Page 7 Tools Install 7712A–MP3–02/07 Read and accept the licence agreement Select the installation directory (use the proposed default) AT85RFD-07 Getting Started User Guide...
- Page 8 Tools Install Validate the information The installation starts… AT85RFD-07 Getting Started User Guide 7712A–MP3–02/07...
-
Page 9: Sun Jre
Start MusicPlayerIsp to check Java runtime installation If the following pop-up appears, proceed with the SUN To install the JRE, go to “Atmel\at85c51snd3b\Tools\In System Programming” directory and click on the “Sun JRE download” URL shortcut. Follow the install procedure of the SUN JRE. - Page 10 Atmel does not make any commitment to update the information contained herein. Unless specifically providedot- herwise, Atmel products are not suitable for, and shall not be used in, automotive applications. Atmel’s products are not intended, authorized, or warranted for use as compo- nents in applications intended to support or sustain life.
