Flame Heater – PH08 SERIES
ASSEMBLY AND OPERATION INSTRUCTIONS
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
DO NOT USE THE HEATER WHEN IT IS RAINING AND DO NOT LET ANY LIQUID
COME INTO CONTACT WITH THE GLASS TUBE WHEN THE HEATER IS IN USE.
ITEM # 126
Read these instructions before using this appliance.The
appliance must be installed in accordance with these
instructions and local regulations. The use of this
appliance in enclosed areas can be dangerous and is
PROHIBITED.
• Perform leak test after each changing of LPG cylinder.
• Never check for leaks with a match or open flame.
• Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this appliance.
• Close the valve of the gas cylinder or regulator.
• Extinguish all open flames; do not operate any
electrical appliances.
• Check for leaks as detailed in these instructions.
• If odor persists, contact your dealer or gas supplier
immediately!
- Do NOT return to place of purchase-
For customer service and warranty issues
contact our Customer Service Center at:
Email: cservice@suntastic.co.uk
Customer Service Hours: Mon. – Fri. 9:00 am – 5:00 pm, GMT
FOR OUTDOOR USE ONLY
1
WARNING
IF YOU SMELL GAS
***IMPORTANT NOTICE***
0808 178 1018 OR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PH08 series and is the answer not in the manual?

Questions and answers

Summary of Contents for Sun Tastic PH08 series

  • Page 1 Flame Heater – PH08 SERIES ITEM # 126 ASSEMBLY AND OPERATION INSTRUCTIONS WARNING Read these instructions before using this appliance.The appliance must be installed in accordance with these instructions and local regulations. The use of this appliance in enclosed areas can be dangerous and is PROHIBITED.
  • Page 2 PRECAUTIONS · Installation and servicing should only be performed by a qualified person. · Do not use the heater in an explosive atmosphere. · Before each use, check the gas hose. · Disconnect LPG cylinder before moving the heater. · Do not attempt to alter any parts of the heater. (Example: Using the heater without reflector or mesh protection guards.) ·...
  • Page 3: Installation

    APPLIANCE STAND AND LOACTION The appliance is for outdoor use only. Do not use it indoors or in an enclosed area. Always maintain proper clearance from combustible materials ( i.e. top 800mm and sides 650mm minium. ) LEAK TEST Gas connections on the appliance are leak tested at the factory prior to shipment. Possible mishandling of the appliance during the shipment might contribute to product integrity as a whole.
  • Page 4: Parts List

    PARTS LIST-1 Part NO. Part Name Picture Remarks Middle Plate Control Box Preassembled in the Middle plate Bottom Plate Lower Support Upper support Upper Plate Plate cover Preassembled in the Middle plate Glass tube Damper Preassembled in upper plate Reflector...
  • Page 5 PARTS LIST-2 Part NO. Part Name Picture Remarks Lower protection guard Connector Fixing bracket Side panel Front panel Screw M3/16’’ All preassembled in relative parts Handle Chain AA battery Optional part Wheels Rubber ring...
  • Page 6: Heater Assembly

    HEATER ASSEMBLY Tools Required: 1 Phillips head screwdriver, 1 adjustable spanner Attach wheel (21) assembly to Take the control box(2) and the plate cover(7) off the middle plate(1) by bottom plate (3). unscrewing the screws(17) Connect and fix the 4 lower Connect 4 upper supports (5) to the supports(4) to bottom plate(3) and lower supports (4) with screws(17),...
  • Page 7 Fix the plate cover(7) onto the Install a AA battery(20) into the middle plate(1) with screws(17). control box, then attach the control box(2) underneath the middle plate(1) with screws (17) Carefully put the glass tube(8) up Attach the reflector (10) on the damper through the center hole in the upper (9) with screws(17).
  • Page 8 9. Hang the protection guards (11) onto Fix 3 side panels (15) with screws (17). the frame by putting the hooks into the Note: Do not cover the side where the holes of the frame. Affix the guards by control knob is located. attaching the fixing brackets(14).
  • Page 9: Operation

    OPERATION fi LIGHT HIGH...
