- Page 1 Domobar Super 2B user’s guide...
-
Page 2: Table Of Contents
Summary 1. Unpacking and Assembly 9. Troubleshooting 9.1. The machine is not working 9.2. No water can be pumped 2. Water 9.3. The Grouphead is not getting very warm 9.4. I can pump water, but the water is always cold 3. -
Page 3: Unpacking And Assembly
1. Unpacking and Assembly CAUTION: Vibiemme Domobar espresso machines are quite heavy. The shipping weight is around 84 pounds! We recommend getting assistance whenever the machine has to be moved or relocated. Open the box and carefully remove the machine. Setting the box on a carpeted surface or on a large, soft towel so that the machine has its backside down makes it easier to slide it out of the box. - Page 4 GFCI and have surge suppression of 15 amper. Upon careful inspection you may find some water stains or wet spots on your new Vibiemme that make the machine appear used. These spots are from testing at the factory to assure that the machine is operating properly before shipping.
-
Page 5: Water
Without these minerals, the boiler will The Vibiemme Domobar Super 2B is set by the manufacturer to draw fresh water from the reservoir and overfill. This can cause numerous problems and can even damage the machine. On the other hand, water collect waste water in the drip tray. -
Page 6: Using The Water Reservoir
Replace the Water Reservoir in the machine. Be sure that the hose enters the reservoir correctly and is not The Vibiemme Domobar Super 2B is set by the manufacturer to collect waste water in the drip tray. If kinked or pinched. Once you have verified that your water quality is appropriate for use in an espresso machine, fill the you use this kind of collection, please make sure to constantly check the water level inside the tank, Water Reservoir. -
Page 7: Start Up
CAUTION: Electrical surges can damage the Vibiemme Domobar electronics. Surges can also damage the heating element. Damage caused by electrical surges is not covered by warranty. -
Page 8: Start Up: Grouphead
4.5. Start up: brew pressure gauge The Vibiemme Domobar is manual in its function with only one switch controlled by a lever on the grouphead The Brew gauge on the right side of the display panel (scale 0 to 16 bar) displays the pressure in the itself. -
Page 9: First Use Of Machine
In the event of air getting drawn into the plumbing system (example: tip of silicone hose exposed to air) please For this first use of the Vibiemme Domobar, once the pressure is above about 0.5 you should flush the do the following: boiler to be sure that the machine is working properly. -
Page 10: Temperature Adjustment
6. Temperature Adjustment 7. Pressurestat Adjustment Coffee boiler temperature can be adjusted through the Display on the push-button panel of the Vibiemme The pressurestat controls temperature (pressure) by sensing the pressure in the steam boiler. Accessing the pressurestat adjustment is simple. Simply remove the Cup Warming Tray. Beneath you will see a perforated Domobar Super 2B. -
Page 11: Minimizing Temperature Variations During The Pull
Another way to lessen this scale accumulation is to pump water out of the boiler occasionally. This is particularly important if you rarely use the hot-water function of the Vibiemme Domobar. To refresh 9.3. The Grouphead is not getting very warm the water in the boiler, simply place a heat-resistant vessel under the hot water wand and open the valve. -
Page 12: I Can Pump Water, But The Water Is Always Cold
9.4. I can pump water, but the water is always cold Bitter coffee can come from: • Be sure the Power Switch is turn on position I. • Water that is too hot • Over Temperature Safety Thermostat tripped. This occurs if the pressurestat malfunctions or the water •... -
Page 13: Cleaning And Maintenance
At the end of each session, use the Grouphead Brush 10.1. After Each Pull which was included with your Vibiemme Domobar espresso machine to clean the screen as well as to give the area in which the grouphead gasket resides a good scrubbing. -
Page 14: Backflushing
10.5. Cleaning the Portafilter and Filter Basket Your Vibiemme Domobar was supplied with a blind filter to be used to backflush. This is the basket with no holes in it. To use it, follow these simple instructions: Pop the filter basket out of the portafilter body. Using a fingernail is not recommended as these commercial WARNING: The cleaning agent is quite strong. -
Page 15: Grouphead Gasket Replacement
The thick, rubber gasket that seals the Portafilter in the Grouphead is subjected to a lot of heat and The boiler and heat exchanger contain water. Because of that, if your Vibiemme Domobar is not going to pressure. Over time it will harden and the portafilter’s action will create a depression in the surface. If it be used for a while or is being placed into storage, some factors must be considered. -
Page 16: Waste Disposal
Waste disposal For the waste management of the used appliances in safety and in respect of the environment, you can deliver it to the appropriate sites for the differentiated waste collection, managed by the Commune. In case the appliance has got batteries, take them away before proceeding to the waste disposal. Since batteries contain substances highly polluting, they also must be disposed in a differentiated collection site. - Page 17 VIBIEMME S.p.A. - Via Gounod 25/27 , Cinisello Balsamo, 20092 (Milano) . Italy...
