Summary of Contents for Audiodesign impact ag 6
- Page 1 SETUPMEMO OWNER MANUAL Impact AG 6 - AG 8 Audiodesign Srl Acoustic Guitar Amplifier Via dell’industria, 28 - 42025 CAVRIAGO (RE) +39 0522 941444 - Fax +39 0522 942363 www.audiodesign-pro.com info@audiodesign.it...
- Page 2 Improper installation could cause fi re risk and/or personal injury. Conformity: Audiodesign Pro products comply with presently existing directives and standards. After sales service: All Audio Design PRO products have been inspected and tested before leaving the factory and , if properly used, they will work for many years.
- Page 3 Acoustic Guitar Amplifier Acoustic Guitar Amplifier Impact AG Serie Impact AG Serie CONNECTIONEXAMPLES Introduction Congratulations for choosing an IMPACT AG series amplifier for acoustic guitars. This series is featured by a great flexibility of use and by a particularly detailed and precise sound.
- Page 4 From these inputs you may listen to a song or background music. what you are playing, adjusting independently recording volume from headset volume or even use the IMPACT AG 6 as a monitor and connect it to a bigger system SETTINGS:...
- Page 5 Acoustic Guitar Amplifier Acoustic Guitar Amplifier Impact AG Serie Impact AG Serie Impact AG 6: Adjust signal level to amplifi er Acoustic guitar amplifi er Further settings are possible on the mixed signal: Choose effect to use (all inputs) (**) Frequency response: 50 - 20.000 Hz...
- Page 6 20. Headphones 6,3 Jack Stereo connector 21. Balanced Line out XLR 22. Balanced Line out 6.3 Jack 23. Line out level adjustment CONTROL PANEL Impact AG 6 24. Stereo outlet (RCA) 25. Stereo outlet level adjustment 26. Phantom power input button and LED indicator 27.
