Summary of Contents for TYPHOON DF-600
-
Page 1: Instruction Manual
ENGLISH DF-600 Slide Film Scanner Digitizing slides and negative films Instruction Manual Article No. 5200-00005-00 Film strips/ 1800/3600 dpi 1 buton framed slides resolution operation... - Page 2 ENGLISH Thank you for deciding on purchasing this quality product from TYPHOON.
-
Page 3: Table Of Contents
Driver installation Connecting the scanner Installing PhotoImpression 22 Chapter 6 Scanning pictures How to start PhotoImpression Inserting/Removing slides/negative film strips Basic settings Copy 28 Chapter 7 Other software options Preferences Photo editing tools Creativity Playback TYPHOON DF-600 Table of Contents... - Page 4 We assume We look forward to you recommending us to others and hope you enjoy us- no liability for consequen- tial damage! ing this device from TYPHOON. The information contained in this instruction manual Your TYPHOON Team is subject to change without notice.
- Page 5 For customers in North and South America For customers in the USA This device complies with the criteria specified in section15 according to FCC standards and regulations. Device operation is permissible, provided both of the following menti- oned regulations have been fulfilled: 1.
-
Page 6: Intended Use
Intended use The TYPHOON DF-600 Slide & Film Scanner can be used to digitize negative films and slides. The scanner can be operated via USB 2.0 connection to a Note ® ® ® PC or notebook that uses a Windows... -
Page 7: Safety Information
Safety information The following safety and hazard warnings are not only for the protection of your device, but also serve as a protection against potential health hazards. Please take time to read the following instructions carefully. We assume no liability for personal or property damage resulting from the failure to comply with the safety instructions, improper operation and handling. - Page 8 This device is not suitable for children under 14 years of age. Small children are unaware of the serious and immediate dangers involved when exposing themselves to or handling electronic devices. Furthermore, this product contains small parts that could be swallowed. Never leave packaging material lying around unsu- pervised.
- Page 9 Make sure the device is placed on a firm and stable surface. Unstable devices could fall down and lead to serious injury or cause damage to the device. Never place any sources of fire on top of or near the device and power supply plug (e.g. ligh- ted candle).
-
Page 10: Features
Features · Scans slides and negative films · Scans in colour or black & white · Create JPG or TIF images · Up to 48-bit colour depth and 3600 dpi resolution · Extensive image editing software The device 1 Power LED displays operational status 2 Copy button captures an image during a scan... -
Page 11: Chapter 5 Installation And Connection
Installation and connection You will need to carry out the respective driver and soft- ware installation before commencing operation. Please proceed in the following order: · Install the driver · Connect the scanner ® · Install the ArcSoft PhotoImpression 6 software ·... - Page 12 Windows XP Follow the instructions as displayed on screen: 1. Click on „Next“. 2. Click on „Install”. Chapter 5 Installation and connection...
- Page 13 3. Now a progress bar will be displayed on screen indicating the current status of installation. Please wait until the installation program changes to the next window. 4. Click on „Finish“ to complete the installation process. Chapter 5 Installation and connection...
- Page 14 Windows Vista Follow the instructions as displayed on screen: 1. Click on „Next“. 2. Click on „Install“. Chapter 5 Installation and connection...
- Page 15 3. Now a progress bar will be displayed on screen indicating the current status of installation. Please wait until the installation program changes to the next window. 4. Click on „Finish“ to complete the installation process. Chapter 5 Installation and connection...
-
Page 16: Connecting The Scanner
5.2 Connecting the scanner Do not insert the CD into the drive. If necessary, remove the CD beforehand. · Ensure that no holder has been inserted first, before connecting the scanner to an available USB 2.0 port on your computer. This connection will also supply power to the device. - Page 17 Windows Vista · Select the first option available in the installation assistant. · The device will be automatically installed once the dialogue „Found New Hardware“ appears on display. · Device driver installation has been successfully completed. Chapter 5 Installation and connection...
-
Page 18: 18 5.3 Installing Photoimpression
5.3 Installing PhotoImpression software The ArcSoft PhotoImpression ® 6 software lets you scan your slides and negative films. Furthermore, you also have the opportunity of using an extensive program that helps you archive and edit your image files. The installation process for Windows XP and Windows Vista is the same. - Page 19 · You will have to agree to the licence agreement terms in order to use the software. · Click on „Next“ to install the software to the displayed folder. Chapter 5 Installation and connection...
- Page 20 · Click on „Next“ to add the displayed folder to the start menu. · Program installation will be carried out. Chapter 5 Installation and connection...
- Page 21 · Select the file types to be linked to the software. Associated files will automatically be opened with ArcSoft PhotoImpression ® Click on „Next” to continue. · Click on „Finish“. Remove the installation CD and reboot your computer before using the software. The software will create a „PhotoImpression 6“...
-
Page 22: Chapter 6 Scanning Pictures
Scanning pictures The following step by step information describes how you will be able to digitize (scan) your slides and negatives. 6.1 How to start PhotoImpression · You can start this program via the start menu or by clicking on the icon found on your desktop. ·... - Page 23 6.2 Inserting/Removing slides/negative strips · You can open the holder by carefully pressing the small lever on the front in an upwards direction. · Pay attention to both supports found on the inside left and right when opening the lid on the holder. ·...
- Page 24 · To remove a holder, carefully slide the holder out of the device in the direction of the arrow. Note TYPHOON assumes no liability for any damages caused to negative films or slides arising from the use of this pro- duct.
-
Page 25: Basic Settings
6.3 Basic settings · In the main menu, click on the icon „Get Photos“ and select „Acquire from Film Scanner”. A dialogue for available basic settings will appear on screen. · Select a scanner under „Select the device“. · Select either a „JPG“ (recommended) or „TIF“ file format. ·... -
Page 26: Copy
Note The device must be calibrated before using it for the first time. Nothing should be inserted into the scanner during this procedure. Therefore, all holders are to be removed before carrying out this process. Click on the button „Cali- brate”... - Page 27 · The option „Colour/Brightness“ lets you adjust the preview. The plus and minus icons can be used to change the colour and brightness levels of a snapshot. · Click on the icon „Snap Shot“ or the „COPY” button on the device to scan the image. The time required to take a snapshot all depends on system performance.
-
Page 28: Chapter 7 Other Software Options
· You will be able to view captured snapshots by selecting the respective directory. Note Different amounts of sto- Always close the scanner screen to view captured images, do not minimize it. rage capacity may be requi- To edit an image, select the desired photo in the main screen. red when storing images, Click on „Edit”... -
Page 29: Photo Editing Tools
7.2 Photo Editing Tools The image editing tools option offers you various opportunities for editing images. Basic functions Apply: Actual changes to an image will be carried out. Cancel: Cancels the actual selected action. Balance slider: Click on the slider to the desired position or keep the mouse button depressed to drag the slider to the desired position. - Page 30 Retouch Touch-up images with the following options Healing brush: Improve an image detail with an image detail. Clone: Cover an image detail with another image detail. Lighten/Darken: Lighten/Darken certain sections of an image. Smudge: Creates a smear effect within a certain range. Sharpen: Increase the sharpness level within a certain range.
-
Page 31: Creativity
Blend: If you highlight this box, the image detail to be added will be worked into the colour scheme of the picture being used. Delete: Deletes the selected picture section. 7.3 Creativity This option lets you add text, clipart graphics or borders to your images. 7.4 Playback You will be able to play image, music and video files with the software. - Page 32 Below is a toolbar of the buttons available for slide show operation on your PC: 1 Best Fit: Select this button to adjust the size of an image if it is larger than your screen’s resolution. 2 Actual size: Displays an image in its original size. 3 Zoom Out/In: Enlarge/Reduce an image in size.
-
Page 33: Chapter 8 Troubleshooting
Troubleshooting Note Before contacting a service technician, refer to the following possible solutions: The device you have just purchased is equipped with The slide scanner is not recognized state-of-the-art technology · Check that all connections have been made properly. and is safe to operate. ·... -
Page 34: Chapter 9 Maintenance And Handling The Device
Maintenance and handling the device Before cleaning or maintaining the device, please adhere to the following information: · The device must be disconnected from the power supply source prior to service, maintenance or repairs. · Capacitors within the device may still carry voltage even though they have been disconnected from all power supply sources. - Page 35 Removing dust from the lens We recommended that the film scanner slot and glass surface be cleaned on a regular basis. Doing so will ensure clear and high quality images. Use the included cleaning brush to clean. Alternatively, you can also use a fuzz-free, cotton cleaning cloth, brush or cotton swab.
- Page 36 Maintenance Carry out a technical safety inspection on a regular basis, e.g. check if the power cable or housing may have become damaged. If there is reason to believe that the device can no longer be operated safely, then disconnect it immediately from the power supply and secure it against any unintentional operation.
-
Page 37: Typhoon Df-600
512 g Note The actual requirements may differ due to system configuration. Delivery contents · TYPHOON DF-600 Slide Film Scanner Technical data · Two holders (1 x positive slide, 1 x negative film) · Cleaning brush · ArcSoft PhotoImpression ®... - Page 38 We reserve the right to alter specifications and information contained in this manual without notice. Original TYPHOON spare parts and accessories can be found on the TYPOON pages under www.x-spares.de All brands mentioned are property of PC live or of their respective owners.
