Multitone RPR 563 Amendment Instruction

Radio paging transceiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AMENDMENT INSTRUCTION NO. 236
RPR 563/RPR 563K PAGING TRANSCEIVER
The attached amendment should be incorporated in the above Technical Manual
as soon as possible.
In line with the company policy of continued technical advancement, changes to
circuit diagrams and component layout diagrams are continually taking place. It is
not company policy that the technical manual should cover all previous issues of
products but only the latest design state.
changes either the circuit diagram or component layout diagram, it may be prudent
to archive the previous diagrams, particularly if your product is of old design.
AFFECTED
PAGES
(iii)/(iv)
AL2 amendments recorded.
1-7/1-8
New Rx frequency band and crystal information.
3-3/3-4
To add crystal frequency calculation for Band V.
3-7/3-8
Corrections to paragraphs 27 and 30.
5C-1/5C-2
Correction to part number for Test Probe.
6-1/6-2
Contents List updated. Addition of new frequency band.
6-3/6-4
Change to antenna information.
6-5/6-6
Component Change C306 (Band T).
6-7/6-8
Filter and inductor information for Band V.
6-9/6-10
Correction to part number for 560n inductor.
6-11/6-12
Adds R351 for Band V.
6-15/6-16
Para 24:
Para 26:
6-17/6-18
New pages with Parts List for new Decoder PCB.
7-1/7-2
Contents List updated.
AL2 TO TM1195 ISSUE 1
APRIL 1999
Alternative part number for Gate Array.
Adds Parts List for new Decoder PCB.
To this end, where an amendment
CHANGE
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RPR 563 and is the answer not in the manual?

Questions and answers

Related Manuals for Multitone RPR 563

Summary of Contents for Multitone RPR 563

  • Page 1 AMENDMENT INSTRUCTION NO. 236 AL2 TO TM1195 ISSUE 1 RPR 563/RPR 563K PAGING TRANSCEIVER APRIL 1999 The attached amendment should be incorporated in the above Technical Manual as soon as possible. In line with the company policy of continued technical advancement, changes to circuit diagrams and component layout diagrams are continually taking place.
  • Page 2 7-33/7-34 Adds Figure 16 (Decoder Component Location Sheet 1 of 2) 7-35 Adds Figure 17 (Decoder Component Location Sheet 2 of 2) With the compliments of Multitone Electronics plc PCN Nos. 4681, 4841, 4899, 5140, 5193 Page 2 TPF003-02 [10/98]...
