Summary of Contents for Runtastic TP00270
-
Page 2: Electromagnetic Compatibility
SCOPE OF DELIVERY 1 Receiver (Art.no. RUNDC2, Model: TP00270) incl. lithium battery (3V, CR1220) Remove the isolator within the case of the receiver, for this purpose open the case. 1 Chest strap (consisting of a sensor and elastic strap) (Art.no. RUNDC2, model: TD00380) incl. - Page 3 RISKS FOR CHILDREN AND INDIVIDUALS REQUIRING ASSISTANCE This device is not intended for use by individuals (including children) with limited physical, sensorial or emotional capacities or limited experience and / or knowledge unless they supervised individual responsible their safety receive instructions from the latter as to how the device should be used.
- Page 4 BATTERY OPERATION Your receiver and chest strap are each powered by a lithium battery (receiver: 3V, CR1220; chest strap: 3V, CR2032). The following section provides you with information about using batteries: Always replace a battery with a battery of the same type. Batteries should not be charged or re- ...
- Page 5 unit. Keep the operating instructions safe so that you can refer to the relevant battery information. Ignoring this information result in damage and possibly even to the batteries exploding. You can find information on replacing the battery for the receiver and the chest strap under the sections entitled "Changing the battery for the receiver"...
- Page 6 1. Installation Runtastic app/activation code Insert the below mentioned link in the address bar of your browser to get to Runtastic.com. The descriptions on this site will help you to finish the activation of the code step by step. http://www.runtastic.com/activate Alternatively, you can also scan the QR-code with your smartphone, to get to this site.
- Page 7 2. Attaching the chest strap Front of sensor: Mounting for soft strap Rear of sensor: Sensor contact surfaces Connect the elastic strap to the sensor. Adjust the strap so that the sensor rests firmly against your chest below your pectoral muscles.
- Page 8 3. Connect your Runtastic hardware Plug the receiver into the headphone jack on your smartphone. Observe the correct positioning receiver: also connect your smartphone's headphones to the receiver (the receiver features a connection socket at the top). NOTE: Should there be no heart rate reading, it...
- Page 9 The receiver will be turned on and consume battery when it is plugged into the phone, even if the Runtastic app is activated. Please take off receiver when it is not in use. The battery life of the receiver is around 2.5 years if it is used 1 hour per day.
- Page 10 Select the option "Heart Rate Monitoring" and then the setting "enabled", followed by the option "Heart Rate Sensor" and the setting "Runtastic". Should there be no heart rate reading, please refer to the point 1. of NOTE on page 8.
- Page 11 the screen you can see on which channel the chest strap is sending. Should you wish to change the channel, press the button on the chest strap as described above to switch to the next coded channel, and then press the button “Re-Pair” and your smartphone will establish a connection to the chest strap again.
- Page 12 the next encoded channel, select "Connect Sensor" again and your smartphone will establish a connection to the chest strap again. Windows Phone: Go to "Settings" and select "Heart Rate", under point "Sensor Channel" you can see on which channel the chest strap is sending. If it is using a coded channel, it shows a digit.
- Page 13 CHANGING BATTERY RECEIVER Open the housing of the receiver as shown in the illustration. SWITCH B↔A Remove the old battery and insert a new CR1220 3V battery. When doing this please ensure that the positive terminal (+) is facing upwards and that the battery touches the contact in the housing.
- Page 14 CHANGING THE BATTERY FOR THE CHEST STRAP Open the battery compartment cover by inserting coin turning counterclockwise. Remove the old battery and insert a new CR2032 3V battery. When doing this please ensure that the positive terminal (+) is facing upwards. Replace the battery compartment cover and secure it in place by turning it clockwise.
-
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY EMC Directive 2004/108/EC: Summary of the declaration of conformity: Krippl-Watches hereby declares that the receiver (art. no. RUNDC2, model: TP00270) and chest strap (art. no. RUNDC2, model: TD00380) conform to the basic requirements and other relevant provisions of Directive 2004/108/EC. - Page 16 Page 16 of 16...
