OPERATING INSTRUCTIONS
Version 05/10
Media Player HD
Item no.: 97 36 97

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 97 36 97 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Conrad 97 36 97

  • Page 1 OPERATING INSTRUCTIONS Version 05/10 Media Player HD Item no.: 97 36 97...

  • Page 2: Table Of Contents

    Table of Contents Page 1. Introduction ........................4 2. Scope of delivery ......................5 3. Intended use ........................5 4. Symbols ........................... 6 5. Safety instructions ......................6 6. Product overview ......................9 Media Player ......................9 IR Remote Control ....................10 7.
  • Page 3 Page 13. Playing audio ......................... 24 14. Displaying pictures ......................25 15. Copying fi les ........................26 16. Media from the Internet ....................27 BitTorrent function ....................27 Flickr (Online picture platform) ................28 17. Maintenance and care ....................29 18.

  • Page 4: Introduction

    All company names and product names are trademarks of their respective owners. All rights reserved. In case of any technical inquiries, contact or consult: Germany: Tel. no.: +49 9604 / 40 88 80 Fax. no.: +49 9604 / 40 88 48 e-mail: tkb@conrad.de Mon. to Thur. 8.00am to 4.30pm Fri. 8.00am to 2.00pm...

  • Page 5: Scope Of Delivery

    2. Scope of delivery • Media Player HD • Mains adapter • IR Remote Control • HDMI cable • 2 Micro / AAA type batteries • Operating instructions 3. Intended use The product is intended to play multimedia fi les (videos, MP3s, pictures). You can also connect USB hard disks / USB sticks and eSATA hard disks.

  • Page 6: Symbols

    4. Symbols Hazard warnings and signs are clearly marked in the operating instructions. The following sym- bols are used: The symbol with lightning inside the triangle is used to indicate a health haz- ard, e.g. by electric shock. The symbol with the exclamation mark inside the triangle indicates particular hazards during handling, operation or control.
  • Page 7 • If you sell or pass on this product to a third party, always include these Direc- tions for Use. • Observe also the safety instructions in the individual sections of these Operat- ing Instructions. • The product must not be exposed to extreme temperatures, direct sunlight, humidity, intense vibration or heavy mechanical strain.
  • Page 8 • Use the product only with the mains adapter supplied. If the housing of the mains adapter or of the product exhibits a defect, disconnect the mains adapt- er from the power supply immediately and contact your dealer. • Never install the device close to heat sources that generate heat, such as radiators, ovens or other devices (e.g.

  • Page 9: Product Overview

    6. Product overview a) Media Player 1. USB connections 2. Network status LED 3. On/off switch 4. Electrical connection 5. Audio outputs 6. Video output 7. HDMI connection 8. Ethernet port 9. eSATA connection 10. Optical audio con- nection...

  • Page 10: B) Ir Remote Control

    b) IR Remote Control 1. On / Off (Stand-by) 2. Number keys 3. Video chapter selection 4. Volume 5. Back to previous menu 6. Repeat 7. Navigation keys 8. Settings Menu 9. Image ratio 10. forward/Rewind 11. Stop 12. forward / Rewind or to next File/Chapter/Title 13.

  • Page 11: Commissioning

    7. Commissioning a) Inserting / replacing batteries in the IR remote control • Open the battery compartment on the bottom side of the IR remote control and insert two Micro / AAA type batteries observing correct polarity. • Replace the lid of the battery compartment. The battery needs to be replaced when the range reduces decreases sharply or the media player no longer reacts to the IR remote control.

  • Page 12: C) Connecting External Memory

    Composite connection If your television has no HDMI interface, you can send video and audio data via a composite AV cable. Proceed as follows: • Connect the product to your television with an AV cable. • Select the appropriate input source on the television. When using the composite connection, the product cannot reproduce the full resolution of 1080p.

  • Page 13: Setting Up The Product

    8. Setting up the product After switching on the product, the main menu is displayed on the television. You can customize the product with the ‘Setup’ menu item. Main functions of the IR remote control in the main menu: Navigate through the individual menus with these keys. Confi...

  • Page 14: B) Video

    b) Video • Select ‘Setup’ → ‘Video’. Here you have the following setting options: ‘Aspect ratio’ The aspect ratio of the video signal on the player can be adjusted. You can choose between ‘Pan Scan 4:3’, ‘Letter Box 4:3’, ‘Wide screen 16:9’ and ‘Full screen’.

  • Page 15: C) System

    c) System Select ‘Setup’ → ‘System’. Here you have the following setting options: ‘Menu language’ You can choose from 14 different languages. ‘Subtitle coding’ You can choose from 11 different subtitle codes. ‘System information’ The system information of your product is dis- played here.

  • Page 16: Connecting To A Network

    ‘Transition effects’ You can defi ne which transition effects to use during a slideshow. You can choose from nine effects. ‘Background music’ You can defi ne whether to use background music during a slideshow. ‘Screensaver’ You can defi ne whether to activate the screensaver after a short while. ‘Film preview’...
  • Page 17 • Use the navigation keys (7) to select ‘Set- up’ → ‘Network’ → ‘LAN setup’ → ‘DHCP’ in the main menu. In DHCP mode (Dynamic Host Confi guration Protocol), the product automati- cally sets up a network connection. As soon as a network connection is estab- lished, ‘DHCP ready’...

  • Page 18: B) Connecting A Wlan Network (Wireless)

    b) Connecting a WLAN network (wireless) • Connect a WLAN-USB stick (not supplied) to the product via a USB connection. • Use the navigation keys (7) to select ‘Set- up’ → ‘Network’ → ‘Wireless setup’ → ‘Infra- structure (AP)’ in the main menu. •...

  • Page 19: Network Services (File Sharing)

    10. Network services (File Sharing) If there is an active network connection, the product can access media content on computers in the same network. To access the media content, you must share the corresponding folders on your computer. Instructions to share folders on your computer are given in Windows Help. Sharing folders on the network is possible from Windows XP onwards.

  • Page 20: Playing Media

    11. Playing media After switching on the product, the main menu is displayed on the television. You can access your media from the ‘Music’, ‘Video’ and ‘Picture’ menu items. The playable and displayable fi le formats are given in the Technical Data. Main functions of the IR remote control in the main menu: Navigate through the individual menus with these keys.

  • Page 21: D) Upnp

    d) UPnP From this menu, you can access the content of shared UPnP devices in the network. The product supports UPnP-capable (Universal Plug and Play) devices for play- back or display of media content. As soon as you select the ‘UPnP’ function, the product detects all devices integrated in the network.

  • Page 22: Playing Video

    12. Playing video To play a video fi le, proceed as follows: • With the navigation keys (7) select ‘Video’ in the main menu. Main functions of the IR remote control for playing video: Navigate through the individual video fi les and folders with these keys.
  • Page 23 Full screen mode Main functions of the IR remote control in full screen mode for video playback: With this key, start or interrupt (Pause) the playback. With these keys, fast forward or rewind the video. With this key activate the slow motion mode. With these keys switch between chapters.

  • Page 24: Playing Audio

    13. Playing audio To play an audio fi le, proceed as follows: • With the navigation keys (7) select ‘Music’ in the main menu. Main functions of the IR remote control for audio playback: Navigate through the individual audio fi les with these keys.

  • Page 25: Displaying Pictures

    When you exit the ‘Music’ menu, the audio continues to play as background music. To stop audio playback, press the STOP (11) key. 14. Displaying pictures To display the picture fi les, proceed as follows: With the navigation keys (7) select ‘Picture’ in the main menu.

  • Page 26: Copying Fi Les

    Full screen mode Main functions of the IR remote control in full screen mode for picture display: With these keys switch between pictures. With this key rotate the picture counter-clockwise. With this key rotate the picture clockwise. With this key exit the full screen mode. You can defi...

  • Page 27: Media From The Internet

    Main functions of the IR remote control for copying fi les: With these keys select the fi les in the ‘Source’ window. With these keys select the destination in the ‘Destina- tion’ window. With this key start copying. 16. Media from the Internet a) BitTorrent function With the BitTorrent function, you can save media content from the Internet to the connected external memory or shared folder in the network.

  • Page 28: B) Flickr (Online Picture Platform)

    Main functions of the IR remote control for the BitTorrent function: With this key start saving. With this key delete the BitTorrent fi le. With these keys select the sequence of the BitTorrent fi les to save. With these keys switch between pages. •...

  • Page 29: Maintenance And Care

    17. Maintenance and care Clean the device with a soft, clean and dry cloth. Do not use aggressive detergents or chemicals as these can damage the housing (discolouration). 18. Disposal Never dispose of devices bearing the symbol opposite in the household waste. You are obliged to dispose of these used electrical and electronic devices sepa- rately.

  • Page 30: Troubleshooting

    19. Troubleshooting Status Possible cause Remedy Television screen HDMI or composite cable is not Insert the cable again cor- black. connected correctly. rectly. Wrong input inserted in the tel- Select right input. evision. No power connection. Insert plug into power socket.

  • Page 31: Technical Data

    20. Technical data Mains adapter Input voltage (power pack) ........100~240 V/50 - 60 Hz Output voltage (power pack) ......... 5 VDC/3 A Media Player Dimensions (B×D×H) ..........approx. 140 × 103 × 36 mm Weight ..............223 g Video output ............HDMI or Composite Audio output ............
  • Page 32 © Copyright 2010 by Conrad Electronic SE. Information légales Ce mode d'emploi est une publication de la société Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). Tous droits réservés, y compris de traduction. Toute reproduction, quelle qu'elle soit (p. ex. photocopie, microfilm, saisie dans des installations de traitement de données) nécessite une autorisation écrite de l'éditeur.
