ZIPAMINI

USER

GUIDE

v1.2b

How can I

manage all

security issues

with one

easy, intuitive

and efficient

solution?

This guide

describes

how to install,

program and

operate Zipato's

Zipamini.

Table of Contents

Need help?

Do you have a question about the Zipamini and is the answer not in the manual?

Questions and answers

Summary of Contents for Zipato Zipamini

Page 1 USER GUIDE ZIPAMINI v1.2b How can I manage all security issues with one easy, intuitive and efficient solution? This guide describes how to install, program and operate Zipato’s Zipamini.
Page 2 NOTICE Although Zipato has attempted to ensure the accuracy of the content of this manual, it is possible that this document may contain technical inaccuracies, typographical, or other errors. Zipato assumes no liability for any error in this publication, and for damages, whether direct, indirect, incidental, and consequential or otherwise, that may result from such error, including, but not limited to loss of data or profits.
Page 3 ZIPAMINI www.zipato.com QUICK INSTALLATION GUIDE IMPORTANT SAFETY INFORMATION To avoid contact with electrical current: Never install an Ethernet connection in wet locations unless that connector is specifically designed for wet locations. Do not place Ethernet wiring or connections in any conduit, outlet or junction box containing electrical wiring.
Page 4: Table Of Contents
ZIPAMINI QUICK INSTALLATION GUIDE www.zipato.com CONTENTS INTRODUCTION PACKAGE CONTENTS CONNECT THE ZIPAMINI ACCOUNT CREATION AND REGISTRATION ADDING DEVICES REMOVING DEVICES TROUBLESHOOTING SPECIFICATIONS LIMITED PRODUCT WARRANTY DECLARATION OF CONFORMITY...
Page 5: Introduction
QUICK INSTALLATION GUIDE INTRODUCTION Thank you for purchasing Zipamini. This guide describes how to install, program and operate your Zipamini. Zipamini makes every home smart by using advanced technology to hide the complexity of home networking - delivering a simple smart home.
Page 6 (in case of missing actions during particular time e.g. motion, door opening, laying on bed...) remote arm/disarm and status-info with any smartphone vandal proof - Zipamini is 24/7 monitored by central station which triggers alarm in case of connection loss include arm/disarm commands in automation scenes...
Page 7 ZIPAMINI www.zipato.com QUICK INSTALLATION GUIDE LIGHTING easy installation of wireless modules Z-Wave lighting module pre-configured for even easier setup support remote dimming and on/off switching with any smartphone automatically turn lights on at sunset and off at sunrise unlimited number of scenes supported...
Page 8 ZIPAMINI QUICK INSTALLATION GUIDE www.zipato.com environmental and home events include climate control in automation scenes together with alarm, lighting, etc. Notification and automated actions in case of overtemperature events, power outages, and other incidents… SHADING control blinds, roller-shutters, curtains and pergolas using any smartphone...
Page 9 ZIPAMINI www.zipato.com QUICK INSTALLATION GUIDE integrate your irrigation scheme together with your complete home automation scenarios ACCESS remotely lock/unlock your door with any smartphone remotely open/close your garage door or gate over any smartphone get video notification when door is open...
Page 10 ZIPAMINI QUICK INSTALLATION GUIDE www.zipato.com VIDEO MONITORING access live and recorded video via the web and from any smartphone support for most of the available IP cameras – ONVIF support get email and SMS notifications with pictures and live video attached...
Page 11 QUICK INSTALLATION GUIDE TECHNICAL SUPPORT HAVING TROUBLE INSTALLING YOUR NEW PRODUCT? Zipato’s website contains the latest user documentation and software updates for Zipato products and services. www.zipato.com You can also find answers in the Zipato Community at: community.zipato.com Zipato Support: support@zipato.com...
Page 12: Package Contents
PLACEMENT Make sure you place Zipamini on flat, non-metalic, non-slim surface. Also make sure Zipamini is located at least 15 cm away from other electronic equipment, such as WiFi routers, plasma and LED TV’s, set-up boxes, etc. IMPORTANT: Failure to comply will result in poor Z-Wave range, inability to join Z-Wave...
Page 13: Connect The Zipamini
The Ethernet port is located on the back of the Zipamini. Zipamini queries your DHCP server for an IP address. If you do not have a DHCP server in your local network, after 60 seconds Zipamini will auto configure itself with link-local IPv4 address (in 169.254.0.0/16 range).
Page 14 QUICK INSTALLATION GUIDE www.zipato.com Serial number POWER UP Plug the power adaptor into mains supply wall socket and the other end into control unit. 01 | PLUG IN POWER ADAPTOR 02 | ZIPAMINI READY: steady green light Green LED Indicator...
Page 15: Account Creation And Registration
ACCOUNT CREATION AND REGISTRATION ACCOUNT CREATION To benefit from the Zipato monitoring and control service you will need to set up your Zipato account and register your Zipamini. Upon registration you will automatically get the basic free level of monitoring service.
Page 16 Once email is verified, login to Zipato by filing out credentials. REGISTER YOUR ZIPAMINI When you first time log in to your account, you need to enter serial number of your Zipamini. Serial number is located on the back of Zipamini and in “Zipabox” application (see picture on next page).
Page 17 ZIPAMINI www.zipato.com QUICK INSTALLATION GUIDE In “Zipabox” application on your Android Zipato controller you will find: Serial number Indication strip (steady Green strip indication means that controller is online and ready) Firmware version which installed on your controllerready) IP address...
Page 18 FINALIZE YOUR ACCOUNT Your account is set up and you are able to use Zipato cloud system. Anyway, you need to ensure that your account is fully set up so you get the most from your Zipato account. Make sure that you have fully completed your profile. To check and verify account details please see Users and Zipabox settings section in Zipato Control Center.
Page 19: Adding Devices
ADDING DEVICES ADDING NEW Z-WAVE DEVICES Before adding new device, it is recommended to bring device closer to Zipamini, so that no obstacle can interfere with operating range of device. Recommended distance between sensors and Zipamini is less than one meter. Read device instructions regarding inclusion/join mode.
Page 20: Troubleshooting
Zipamini inside. What should I do if I am having trouble installing my device? If you are having difficulty with the physical installation of non-Zipato branded devices (Thermostats, GE switches, Blueline meter reader, etc.), please contact the...
Page 21 Zipamini, check the videos or other content on Zipato website for assistance. Error “Allowed registration time elapsed” Serial number must be entered within 2 min after turning on Zipamini. If not, message will appear saying “Allowed registration time elapsed”. This is done because security precaution.
Page 22 PLACEMENT Make sure you place Zipamini on flat, non-metalic, non-slim interface. Also make sure Zipamini is located at least 15 cm away from other electronic equipment, such as WiFi routers, plasma and LED TV’s, set-up boxes, etc. IMPORTANT: Failure to comply will result in poor Z-Wave range, inability to join...
Page 23: Specifications
Two USB ports Home Automation AV out Energy Monitoring LAN port Home remote control TF card slot Video surveillance and more… DC-in OPERATING SYSTEM USER INTERFACE Android 4.2 Zipato Cloud automation API Linux Kernel - 3.0.8+ Free iOS and Android applications...
Page 24 ZIPAMINI QUICK INSTALLATION GUIDE www.zipato.com REGULATORY COMPLIANCE WARRANTY (PENDING 1 year standard Safety: UL Specifications are subject to change EMC: FCC, CE without prior notice RoHS POTENTIAL APPLICATIONS Home Automation Energy Monitoring Home remote control Video surveillance and more…...
Page 25: Limited Product Warranty
STATEMENT ARE CUSTOMER’S SOLE AND EXCLUSIVE REMEDIES AGAINST ZIPATO. THEY DO NOT, HOWEVER, AFFECT OR RESTRICT THE RIGHTS YOU HAVE AGAINST THE BUSINESS YOU BOUGHT A ZIPATO PRODUCT FROM. IN NO EVENT WILL ZIPATO BE LIABLE FOR LOSS OF DATA OR FOR INDIRECT, SPECIAL,...
Page 26 European subsidiaries, affiliates, authorized resellers, or country distributors (collectively referred to as “ZIPATO Resellers”) with this Limited Product Warranty. The term “ZIPATO Hardware Product” is limited to the hardware components and all its internal components including firmware. The term “ZIPATO Hardware Product”...
Page 27 (or as amended from time to time). ZIPATO does not warrant that the products will operate uninterrupted or error-free or that all deficiencies, errors, defects or non-conformities will be corrected.
Page 28 QUICK INSTALLATION GUIDE www.zipato.com product if any ZIPATO serial number has been removed or defaced in any way. ZIPATO IS NOT RESPONSIBLE FOR DAMAGE THAT OCCURS AS A RESULT OF YOUR FAILURE TO FOLLOW THE INSTRUCTIONS FOR THE ZIPATO HARDWARE PRODUCT.
Page 29 QUICK INSTALLATION GUIDE PERFORMANCE OF THE LIMITED PRODUCT WARRANTY If a product defect occurs, ZIPATO’s sole obligation shall be to repair or replace any defective Zipato Hardware Product free of charge provided it is returned to an Authorized ZIPATO Service Centre during the Limited Warranty Period. Such repair or replacement will be rendered by ZIPATO at an Authorized ZIPATO Service Centre.
Page 30: Declaration Of Conformity
DECLARATION OF CONFORMITY The Manufacturer Tri plus grupa d.o.o. hereby declares that the product: Marketing model: Zipamini Regulatory model: zbminitv.zweu.g Trade/Brand name: Zipato is in conformity with the Low Voltage Directive 2006/95/EC, EMC Directive 2004/108/ EC and R&TTE Directive 1995/5/EC and carries the CE marking accordingly.
Page 31 (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: Changes or modifications not expressly approved by Zipato for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 32 ZIPAMINI QUICK INSTALLATION GUIDE www.zipato.com generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
Page 33 Zipato re-seller store. By recycling the product and its packaging in this manner you help to conserve the environment and protect human health.
Page 34 ZIPAMINI QUICK INSTALLATION GUIDE www.zipato.com NOTES...
Page 35 ZIPAMINI www.zipato.com QUICK INSTALLATION GUIDE...
Page 36 ZIPAMINI QUICK INSTALLATION GUIDE www.zipato.com make your home smart www.zipato.com...
