HOME USE LOSSNAY
TYPE
VL-100U-E

Installation Instructions

Before proceeding with the installation work, be sure to read through these instructions.
The installation work should be done by an authorized dealer or qualified contractor.
Please ensure that the separate "Operating Instructions" are handed over to the customer.
Essential safety precautions
• Before proceeding with operation, please be sure to read
"
Essential Safety Precautions
the product properly and safely.
• The displays have the following significance.
WARNING
CAUTION
• The graphic symbols have the following significance.
Prohibited
Do NOT
disassemble.
Use is prohibited
wherever water is
present.
You must follow the
instructions given.
Disconnect the
power plug.
"
as it will tell you how to operate
This applies to mishandling or
misoperation of the product
which may lead to a fatal or
serious injury.
This applies to mishandling or
misoperation of the product
which will lead to an injury or
damage
to
your
home,
household effects, etc.
(For Dealer or Contractor)
Contents
Safety precautions ............... 2
Outline drawings .................. 2
· Unpacking ........................ 4
Test run
Test run .............................. 8
− 1 −
9701R870HH9001
300 mm thick .................. 6
the mounting plate ......... 6
Page

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi VL-100U-E

Summary of Contents for Mitsubishi VL-100U-E

  • Page 1: Table Of Contents

    9701R870HH9001 HOME USE LOSSNAY TYPE VL-100U-E Installation Instructions (For Dealer or Contractor) Before proceeding with the installation work, be sure to read through these instructions. The installation work should be done by an authorized dealer or qualified contractor. Please ensure that the separate “Operating Instructions” are handed over to the customer.

  • Page 2: Before Installation Safety Precautions

    Before installation Safety precautions WARNING • Do not alter the unit or disassemble it more than necessary. (Fire, electric shock or injury may result.) • Do not install the unit in a bathroom or other highly humid location. (Fire or electric shock may result.) •...

  • Page 3: Installation Positions

    Installation positions Edge of Require to Mounting hole Require to Mounting plate main unit be secured 36 –φ6 be secured (Min.) (Max.) (Adjustable) (Adjustable) Position of 267.5 screw for securing unit horizontally min. min. (Unit: mm) Position of screw for Air exhaust hole Air intake hole (φ80 to φ90 wall hole)

  • Page 4: Installing The Unit

    Installing the unit Unpacking Pipe mounting plates: 2 Weather covers: 2 Air supply/exhaust pipes: 2 Flange nuts: 2 Weather cover mounting plate: 2 Aluminum tape: 2 packets Screws for securing weather covers: 4 Wood screws: 10 Mounting plate (For attaching mounting plate/for securing main unit horizontally) Remove mounting plate.

  • Page 5: Wall Hole Construction

    Wall hole construction Determine the installation position. 1. Place the mounting plate on the wall. 2. Check that the reinforcement (indoor wall) is 44 mm min. positioned properly to secure the mounting plate. 83 mm min. 3. Attach the mounting plate loosely (with single wood Wood screw screw).

  • Page 6: If The Wall Is More Than 300 Mm Thick

    P-100PJ-E). Attach them to the pipes as shown below. (Each set can extend the pipes by 300 mm.) Quantity Requirement O-ring 2 sets of P-100P-E for 1 VL-100U-E 1 set of P-100PJ-E for 1 VL-100U-E 1. Screw the extension joints all the way into the air supply/exhaust pipes, making sure they fit securely.

  • Page 7: Outdoor Construction

    Outdoor construction Attach weather covers packed together with unit. Caulking Wall hole caulking Air supply/exhaust pipe • Fill in any gaps between the air supply/ exhaust pipes and the wall holes with caulking (commercially available). Attaching weather covers 1. Insert weather cover mounting plate into air supply/exhaust pipes.

  • Page 8: Test Run

    Test run Insert the power plug into the wall outlet. Knob Check the shutter’s open/close operation. • Slide the knob to check the shutter opens and closes normally. Open Closed Closed Open Check operating modes. 1. Slide the knob to the shutter open position. 2.
