Ceewa S1 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

CEEWA S1
User Manual
V1.03
2016/06/03 Revision
Please follow the user manual to finish flight procedures!
DO NOT disable Beginner Mode at first ten flights!
If errors occur, please refer to the user manual at first, and then ask customer
service. DO NOT violate any step in the user manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ceewa S1

  • Page 1 CEEWA S1 User Manual V1.03 2016/06/03 Revision Please follow the user manual to finish flight procedures! DO NOT disable Beginner Mode at first ten flights! If errors occur, please refer to the user manual at first, and then ask customer...

  • Page 2: Table Of Contents

    Step 7: Initialization Binding ..........................15 Step 8: Check Drone Working Condition ......................16 Step 9 ： Turn on CEEWA APP & Pair to Watch ....................17 Step 10: Calibration ............................17 III. Sports Watch Version: Flight Test ............21 Overview ................................
  • Page 3 Step 7: Initialization Binding ..........................48 Step 8: Check Drone Working Condition ......................49 Step 9 ： Turn on CEEWA APP & Pair to Remote Controller ................50 Step 10: Calibration ............................50 Step 11: Check Image Transmission ......................... 54 V.

  • Page 4: Package Contents

    Package Contents Before using the product, please make sure all the following checked items are included in the package. If any item is missing, please contact your local sellers. Standard: Gimbal*1 Propellers （ Pair ） Battery Charger （ With Sports Camera & Gimbal ）...

  • Page 5: Tips

    CEEWA Drone Firmware Upgrade Manual (1) Firmware Upgrade Kit CEEWA S1 Update Tool CEEWA S1 USB Driver (3 Video Watch the tutorial video below to learn how to use CEEWA S1 safely and correctly. Website: www.ceewa.com QR Code : (4) CEEWA APP Website: http://www.ceewa.com/index.php?case=archive&act=list&catid=15...

  • Page 6: Disclaimer

    2. Damage(s), injuries or any legal responsibilities caused by subjective intentional operations. 3. CEEWA takes no responsibility for any misuse due to you fail to follow the CEEWA S1 Disclaimer, Quick Start, User Manual and warnings found on www.ceewa.com.

  • Page 7: About Ceewa S1

    I. About CEEWA S1 1. About Drone...

  • Page 8: About Sports Watch

    2. About Sports Watch...

  • Page 9: About Remote Controller

    3. About Remote Controller Undefined With Image Transmission Ground System...

  • Page 10: About Follow Module

    4. About Follow Module...

  • Page 11: About Digital Image Transmission

    5. About Digital Image Transmission Image transmission of Limited Version has been mounted into the front hatch of Drone. If you purchase it separately, please refer to the detailed installation steps in the User Manual. How to install Image Transmission? Please refer to Chapter Appendix : Image Transmission→...

  • Page 12: Sports Watch Version: Check Before Flight

    II. Sports Watch Version: Check before Flight Overview Before doing the following steps, please ensure you have read user manual carefully and thoroughly. Download CEEWA APP Website: http://www.ceewa.com/index.php?case=archive&act=list&catid=15 QR Code: CEEWA APP requires: iOS 8.0 or later. Android OS4.3 or above with Bluetooth 4.0.

  • Page 13: Step 1: Check Drone

    Step 1: Check Drone Before using the drone, check its components and ensure they are not broken or aging. Step 2: Check Arms & Buckles Make sure the arms can fold and unfold smoothly, buckles can be turned on and off. If you find buckles cannot be fixed tightly and correctly, please ask to change new buckles from costumer service.
  • Page 14 12.5%~25% 0%~12.5% 2. Charging ① Connect Battery Charger to a power source (100V-240V , 50/60Hz;). ② Connect the Smart Battery to Battery Charger (when the battery is powered off). ③ The Battery Level LEDs will blink to indicate the current battery level.
  • Page 15 Sports Watch Battery Level Check & Charging 1. Check Battery Level When the Sports Watch is not powered on, just press the STOP button to check the current battery level and current time. When the Sports Watch is powered on, enter Flight Interface to check. High 2.

  • Page 16: Step 5: Check Av-Out Mode & Av Cable & Tf Card

    Camera Battery Level Check & Charging 1. Check Battery Level 4K Camera ： Refer to 4K Camera User Manual for details. (from Download Page of CEEWA.COM) 1080P Camera ： Refer to 1080P Camera User Manual for details. (from Download Page of CEEWA.COM) 2.
  • Page 17 Turn on/off Sports Watch Power ON: Press the Stop Button once, and then press this button for over 3s to enter Flight Interface. Power OFF: Toggle Nav. Button to the right & enter Menu Interface. Select "Power-off" option and choose "OK" in the pop-up window. Turn on/off Follow Module Power ON: Press the Power Button once, and then press this button for over 3s to turn on.

  • Page 18: Step 7: Initialization Binding

    Turn On/Off Camera Turn On ： 4K Camera：Press the Power Button until the LED Indicator on the screen side blinks. Camera turns on. 1080P Camera：Press the Power Button until the LED Indicators blink. Camera turns on. Turn Off ： 4K Camera：Press the Power Button until the LED Indicator on the screen side turns off. 1080P Camera：Press the Power Button until the LED Indicators turn off.

  • Page 19: Step 8: Check Drone Working Condition

    Devices OK Symbol Instructions If Bind is OK, Sports Watch will switch to Menu Interface. If binding fails, Sports Watch will stay in D r o n e & S p o r t s the “Binding…” Interface. You should press Watch STOP button to disable binding mode.

  • Page 20: Step 9 ： Turn On Ceewa App & Pair To Watch

    ③ Choose Sports Watch in the window and wait for connection. When the device name and Bluetooth icon on the upper right corner turn to blue, pairing finishes. All the above steps show when you pair them for the first time, and CEEWA APP will auto connect it since then.
  • Page 21 (2)Calibration Steps ① Turn on CEEWA APP and enter Flight Interface. Tap "Others" icon and choose Calibration icon to enter Calibration interface. ② Select "Calibrate Drone Sensor" option and choose "Calibrate Compass".
  • Page 22 ② Place Drone in the level ground. ③ Turn on CEEWA APP and enter Flight Interface. Tap “Others” icon and choose Calibration icon to enter Calibration interface. ④ Select “Calibrate Drone Sensor” option and choose “Check”. Drone will auto check its status. If calibration should be done, “Calibrate”...
  • Page 23 CEEWA APP: You could enter Calibration interface to do the calibration. ① Turn on CEEWA APP and enter Flight Interface. Tap “Others” icon and choose Calibration icon to enter Calibration interface. ② Put Drone and Follow Module at the same height.

  • Page 24: Sports Watch Version: Flight Test

    Before taking-off, put Drone on the ground for over 70 seconds and wait for GPS reach 10 satellites. All the flight procedures should follow the flow chart below! CEEWA APP enables Beginner Mode by default. Blue Rounds are required, while orange rounds are optional.

  • Page 25: Step 1: Finish Check Before Flight

    Refer to Chapter Sports Watch Version: Check before Flight → Step 10: Calibration → 5. Height Calibration for detailed calibration procedures. Step 4: Check GPS Status & Connection Status DO NOT INGORE THIS STEP! CEEWA APP: In Flight Interface, check whether or not over 10 satellites have been found and Sports Watch has connected to Smartphone.
  • Page 26 Click Follow Module Status to check the remaining power, satellite number and connection status of Follow Module. Sports Watch: In Flight Interface, icon blinks, there may be something wrong between Watch and Drone, including weak connection, GPS Positioning problem of Drone or low-voltage of Drone. icon is constantly on, Sports Watch has connected to Drone.

  • Page 27: Step 5: Switch To P Mode

    ③ Enable One-key land and check whether or not four motors can stop. Step 7: Attach / Detach Propellers Attach Propellers CEEWA Drone uses 10-inch propellers. White and Black nuts on the propellers indicate the rotation direction of propellers and where it should be attached.

  • Page 28: Step 8: One-Key Take-Off

    Drone will ascend to 5 meters and hover to wait for the next order. When Drone has NOT connected to Sports Watch: Drone cannot take off. CEEWA APP: In Flight Interface ( ), tap One-Key Take-off icon ( ) and slide the white slider to confirm take-off.

  • Page 29: Step 9: Check Status

    When Drone has connected to Sports Watch: Drone will ascend to 5 meters and hover to wait for the next order. When Drone has NOT connected to Sports Watch: Drone cannot take off. Step 9: Check Status If drone hover steadily after taking-off, over ten GPS Satellites have been found, connection between Smartphone & Sports Watch and Follow Module &...

  • Page 30: Step 11: Follow Mode

    Before Follow Mode, please put Drone & Follow Mode at the same height to calibrate! ) ， Hover-and-Aim ( ) ， Follow-Shadow( ) ， Follow- There are 8 Follow Mode supported by CEEWA Drone: Simple-Follow ( ) ， Orbit( ) ， Follow-Line( ) ， Freeze( ) .
  • Page 31 Drone will stay hovering, but its nose and camera will move with Follow Module to capture images. Keep a safe distance between Drone & Follow Module. How to activate? CEEWA APP ： ① Ensure Drone has taken-off. ② Click Follow Mode icon and enter Follow Mode menu.
  • Page 32 Hover-and-Aim Sports Watch: H o v e r - H o v e r - and-Aim and-Aim When connection is OK, press Mode Button repeatedly until Hover-and-Aim icon shows on the screen. After 3 times of beeps, Hover- and-Aim enables. How to deactivate? Sports Watch: When pressing STOP button, “Hovering…”...
  • Page 33 D: 13 When connection is OK, press Mode Button repeatedly until Follow-Shadow icon shows on the screen. After 3 times of beeps, Follow-Shadow enables. Please modify parameters through CEEWA APP. How to deactivate? Sports Watch: When pressing STOP button, “Hovering…” shows in the screen and Sports Watch vibrates once. At this moment, Follow Mode has been cancelled.
  • Page 34 D: 13 When connection is OK, press Mode Button repeatedly until Follow-Track icon shows on the screen. After 3 times of beeps, Follow- Track enables. Please modify parameters through CEEWA APP. How to deactivate? Sports Watch: When pressing STOP button, “Hovering…” shows in the screen and Sports Watch vibrates once. At this moment, Follow Mode has been cancelled.
  • Page 35 S: 1 S: 1 When connection is OK, press Mode Button repeatedly until Orbit icon shows on the screen. After 3 times of beeps, Orbit enables. Please modify parameters through CEEWA APP. How to deactivate? Sports Watch: When pressing STOP button, “Hovering…” shows in the screen and Sports Watch vibrates once. At this moment, Follow Mode has been cancelled.
  • Page 36 Follow Module. If Follow Module goes beyond the route range, Drone will stay and hover at the nearest waypoint with camera pointing to the direction of Follow Module. CEEWA APP will auto check the reliability of route. If the route is not reasonable, waypoints will turn to red. How to activate? CEEWA APP ：...
  • Page 37 Drone will hover in the sky, but its gimbal will point straight down to support the camera to shoot. In this mode, the position of Follow Module has nothing to do with Drone. How to activate? CEEWA APP ： ① Ensure Drone has taken-off and achieve your desired position. ② Click Follow Mode icon and enter Follow Mode menu.

  • Page 38: Step 12: Nav. Mode

    Step 12: Nav. Mode Please activate Nav. Mode in CEEWA APP. CEEWA Drone S1 supports three Nav. Mode : Single-Point Orbit( ) ， Pointing( ) ， Multiple-Points Nav.( Single-Point Orbit After finishing setting the waypoint in the map, Drone will orbit the waypoint constantly.
  • Page 39 In Multiple-Points Nav., Drone will fly along the route of waypoints. After reaching the last waypoint, it will fly to the first waypoint and repeat the route. How to activate? CEEWA APP ： Multiple-Points Nav. Please set waypoints in the map.

  • Page 40: Step 13: Go-Home

    CEEWA Drone supports three kinds of Go-Home, including Smart Go-Home, Low-Battery Go-Home, and Failsafe Go-Home. Before going-home, you should set Home Point through Sports Watch or CEEWA APP. Three are three kinds of Home Points, including “Set Take-off Position as Home Point” ( ), “Set Module Position as Home Point”(...
  • Page 41 New Home Point Smart Go-Home Enable Go-Home by Sports Watch / CEEWA APP. During Smart Go-Home procedures, you can control its orientation and height through Watch. It is suggested to enable Smart Go-Home in a safe and reliable environment to avoid obstacles.
  • Page 42 Hovering Low-Battery Go-Home In order to avoid dangers of low-battery, the main controller system will calculate the distance between Drone & Home Point and go- home time in real-time. When the remaining battery is ONLY enough for going-home, Low-Battery Go-Home is triggered. During the process, you could control Drone's attitude through Sports Watch and Remote Controller to avoid obstacles.

  • Page 43: Step 14: One-Key Land

    Sports Watch: Toggle Nav. Button to the right & enter Menu Interface. Select “Land” option and choose “OK” in the pop-up window. One-Key Land activates. CEEWA APP: In Flight Interface ( ), tap One-Key Land icon ( ) and slide the white slider to confirm landing.
  • Page 44 Camera 4K Camera：Press the Power Button until the LED Indicator on the screen side turns off. 1080P Camera：Press the Power Button until the LED Indicators turn off.

  • Page 45: Remote Controller Version: Check Before Flight

    IV. Remote Controller Version: Check before Flight Overview Before doing the following steps, please ensure you have read user manual carefully and thoroughly. Download CEEWA APP Website: http://www.ceewa.com/index.php?case=archive&act=list&catid=15 QR Code: CEEWA APP requires: iOS 8.0 or later. Android OS4.3 or above with Bluetooth 4.0.

  • Page 46: Step 1: Check Drone

    Step 1: Check Drone Before using the drone, check its components and ensure they are not broken or aging. Step 2: Check Arms & Buckles Make sure the arms can fold and unfold smoothly, buckles can be turned on and off. If you find buckles cannot be fixed tightly and correctly, please ask to change new buckles from costumer service.
  • Page 47 25%~37.5% 12.5%~25% 0%~12.5% 2. Charging ① Connect Battery Charger to a power source (100V-240V , 50/60Hz;). ② Connect the Smart Battery to Battery Charger (when the battery is powered off). ③ The Battery Level LEDs will blink to indicate the current battery level.
  • Page 48 Remote Controller Battery Level Check & Charging 1. Check Battery Level Press Power Button once to check battery level. Current Battery Level Full Charging Port 2. Charging Follow Module Battery Level Check & Charging 1. Check Battery Level After turning on, Red Power LED will blink to indicate the current battery level. Current Level Red Power LED blinks 4 times.

  • Page 49: Step 5: Check Av-Out Mode & Av Cable & Tf Card

    Camera Battery Level Check & Charging 1. Check Battery Level 4K Camera ： Refer to 4K Camera User Manual for details. (from Download Page of CEEWA.COM) 1080P Camera ： Refer to 1080P Camera User Manual for details. (from Download Page of CEEWA.COM) 2.
  • Page 50 Turn on/off Remote Controller Power ON: Press Power Button once, and then press this button for over 3s till all LEDs have blinked once. Power OFF: Press the Power Button once, and then press this button for over 3s till all LEDs turn off. Turn on/off Follow Module Power ON: Press the Power Button once, and then press this button for over 3s to turn on.

  • Page 51: Step 7: Initialization Binding

    Turn On/Off Camera Turn On ： 4K Camera：Press the Power Button until the LED Indicator on the screen side blinks. Camera turns on. 1080P Camera：Press the Power Button until the LED Indicators blink. Camera turns on. Turn Off ： 4K Camera：Press the Power Button until the LED Indicator on the screen side turns off. 1080P Camera：Press the Power Button until the LED Indicators turn off.

  • Page 52: Step 8: Check Drone Working Condition

    When should I bind Follow Module & Sports Watch? ① Turn on Follow Module and Remote Controller, and enter CEEWA APP. ② Enter Flight Interface of CEEWA APP, and wait for 60s. If Follow Module icon is shown as like the left diagram, binding should be done.

  • Page 53: Step 9 ： Turn On Ceewa App & Pair To Remote Controller

    ③ Choose Remote Controller in the window and wait for connection. When the device name and Bluetooth icon on the upper right corner turn to blue, pairing finishes. All the above steps show when you pair them for the first time, and CEEWA APP will auto connect it since then.
  • Page 54 (2)Calibration Steps ① Turn on CEEWA APP and enter Flight Interface. Tap "Others" icon and choose Calibration icon to enter Calibration interface. ② Select "Calibrate Drone Sensor" option and choose "Calibrate Compass".
  • Page 55 ② Place Drone in the level ground. ③ Turn on CEEWA APP and enter Flight Interface. Tap “Others” icon and choose Calibration icon to enter Calibration interface. ④ Select “Calibrate Drone Sensor” option and choose “Check”. Drone will auto check its status. If calibration should be done, “Calibrate”...
  • Page 56 CEEWA APP: You could enter Calibration interface to do the calibration. ① Turn on CEEWA APP and enter Flight Interface. Tap “Others” icon and choose Calibration icon to enter Calibration interface. ② Put Drone and Follow Module at the same height.

  • Page 57: Step 11: Check Image Transmission

    (2)Calibration Steps ① Ensure all the connection is OK. ② Turn on CEEWA APP and enter Flight Interface. Tap “Others” icon and choose Calibration icon to enter RC Setting interface. ③ Select “RC Calibration” option and tap “Calibrate”. ④ Push both sticks to 100% in every direction, and observe whether or not the value in the interface has reached 100%.
  • Page 58 3. AV-OUT Mode of Camera enables. 4. Exit CEEWA APP from iOS / Android background and re-enter CEEWA APP. 5. If none of the above solutions solve the problem, please check whether or not Power Safe Mode of camera enables. How to...

  • Page 59: Remote Controller Version: Flight Test

    Before taking-off, put Drone on the ground for over 70 seconds and wait for GPS reach 10 satellites. All the flight procedures should follow the flow chart below! CEEWA APP enables Beginner Mode by default. Blue Rounds are required, while orange rounds are optional.

  • Page 60: Step 1: Finish Check Before Flight

    Refer to Chapter Remote Controller Version: Check before Flight → Step 10: Calibration → 5. Height Calibration for detailed calibration procedures. Step 4: Check GPS Status & Connection Status DO NOT INGORE THIS STEP! CEEWA APP: In Flight Interface, check whether or not over 10 satellites have been found and Sports Watch has connected to Smartphone.

  • Page 61: Step 5: Switch To P Mode

    Please ensure there are more than 10 GPS satellites. Step 5: Switch to P Mode Remote Controller: Press P Button. When RC vibrates once P Button Status LED is constantly on, P Mode has been activated. You can also check P Mode in Status Bar of CEEWA APP:...

  • Page 62: Step 6: Drone Test

    ③ Enable One-key land (press and hold L Button for over 3s) and check whether or not four motors can stop. Step 7: Attach / Detach Propellers Attach Propellers CEEWA Drone uses 10-inch propellers. White and Black nuts on the propellers indicate the rotation direction of propellers and where it should be attached. Black Nut Please fix each propeller tightly before flight.

  • Page 63: Step 9: Check Status

    When Drone has connected to Remote Controller: When Drone has not connected to Remote Controller: One-key Take-off cannot be activated. ( In Beginner Mode CEEWA APP: In Flight Interface ( ), tap One-Key Take-off icon ( ) and slide the white slider to confirm take-off.

  • Page 64: Step 10: Adjust Drone's Attitude

    ① Ensure Remote Controller and CEEWA APP has been connected. ② Turn on CEEWA APP and enter Flight Interface. Tap “Others” icon and choose Calibration icon to enter RC Setting interface. ③ Select “Stick Mode” option and choose your preference mode.
  • Page 65 Control the drone If you have no experience in controlling the drone, you can refer to the table below to adjust drone's attitude. This table is based on the default control mode: Mode 2. Drone Operation Methods Move the left stick up and down to change the elevation of the drone.

  • Page 66: Step 11: Follow Mode

    Before Follow Mode, please put Drone & Follow Mode at the same height to calibrate! ) ， Hover-and-Aim ( ) ， Follow-Shadow( ) ， Follow- There are 8 Follow Mode supported by CEEWA Drone: Simple-Follow ( ) ， Orbit( ) ， Follow-Line( ) ， Freeze( ) .
  • Page 67 Drone will stay hovering, but its nose and camera will move with Follow Module to capture images. Keep a safe distance between Drone & Follow Module. How to activate? CEEWA APP ： ① Ensure Drone has taken-off. ② Click Follow Mode icon and enter Follow Mode menu.
  • Page 68 Module. The Blue Triangle represents Drone. How to activate? CEEWA APP ： ① Ensure Drone has taken-off. ② Click Follow Mode icon and enter Follow Mode menu. ③ Click Follow-Shadow icon and enter Follow-Shadow menu. ④ Drag Blue Drone icon to set the angle between Drone and Follow Module.
  • Page 69 How to activate? CEEWA APP ： ① Ensure Drone has taken-off. ② Click Follow Mode icon and enter Follow Mode menu. ③ Click Follow-Track icon and enter Follow-Track menu. ④ Drag Blue Drone icon to set the angle between Drone and Follow Module.
  • Page 70 Through Selfie, you can get the transitional footage from small scene to large scene, and from large scene to small scene. Set a reasonable distance, altitude and angle. How to activate? CEEWA APP ： ① Ensure Drone has taken-off. ② Click Follow Mode icon and enter Follow Mode menu.
  • Page 71 Follow Module. If Follow Module goes beyond the route range, Drone will stay and hover at the nearest waypoint with camera pointing to the direction of Follow Module. CEEWA APP will auto check the reliability of route. If the route is not reasonable, waypoints will turn to red. How to activate? CEEWA APP ：...

  • Page 72: Step 12: Nav. Mode

    Please activate Nav. Mode in CEEWA APP. ) ， Pointing( ) ， Multiple-Points Nav.( CEEWA Drone S1 supports three Nav. Mode : Single-Point Orbit( Single-Point Orbit After finishing setting the waypoint in the map, Drone will orbit the waypoint constantly.
  • Page 73 How to activate? CEEWA APP ： Pointing Please set a destination point in the map. Cancel Confirm Route Distance 32 Flight Velocity 5 Start Time Left 15 Cancel Tap the waypoint ( ) in the map to edit its altitude and velocity in the pop-up window. Also, delete this waypoint in this pop-up window.

  • Page 74: Step 13: Check Live Image

    CEEWA Drone supports three kinds of Go-Home, including Smart Go-Home, Low-Battery Go-Home, and Failsafe Go-Home. Before going-home, you should set Home Point through Sports Watch or CEEWA APP. Three are three kinds of Home Points, including “Set Take-off Position as Home Point” ( ), “Set Module Position as Home Point”(...
  • Page 75 New Home Point Smart Go-Home Enable Go-Home by Sports Watch / CEEWA APP. During Smart Go-Home procedures, you can control its orientation and height through Watch. It is suggested to enable Smart Go-Home in a safe and reliable environment to avoid obstacles.

  • Page 76: Step 15: One-Key Land

    Please land the drone on the level ground. Remote Controller: Press L Button, and One-Key Land activates. During landing, Remote Controller vibrates to alert. CEEWA APP: In Flight Interface ( ), tap One-Key Land icon ( ) and slide the white slider to confirm landing.

  • Page 77: Step 16: Turn Off All Devices

    Step 16: Turn Off All Devices Turn off Smart Battery, Sports Watch, Follow Module and Camera. Smart Battery: Press the Power Button once, and then press this button for over 3s till all LEDs turn off. Remote Controller: Press the Power Button once, and then press this button for over 3s till all LEDs turn off. Follow Module: Press the Power Button once, and then press this button for over 3s till all LEDs turn off.

  • Page 78: Specifications

    VI. Specifications Drone Drone Dimensions 44*35*15 mm Package Dimensions 50*31*18 mm Backpack Dimensions 48*32*18 mm Weight 1370 g Wheelbase 475 mm Maximum Speed 72 Km / h Vertical: ±0.5 m Hover Accuracy Horizontal: ± １ m Propellers 10-inch 　 Motor 2216 GPS &...
  • Page 79 Image Quality 1920*1440P 30FPS 1080 60FPS Pixel 16 million pixels Sensor Sony HD Image Sensor IMX206 Operation Method Smart Watch Support Remote Controller Support Follow Module Support CEEWA APP Support Image Transmission Digital Image Transmission Low Latency / 800 m...

  • Page 80: Led Indicators & Vibrations

    VII. LED Indicators & Vibrations 1. Drone Status LEDs Normal Yellow Lights Blink 3 times. Binding Yellow Lights Blink 4 times. Data Transmission is upgrading. Yellow Lights Blink slowly. A Mode(Attitude Mode) Green Lights Blink slowly. P Mode(Position Mode) Green Lights Blink 20 times. GPS is positioned.

  • Page 81: Remote Controller Leds

    Red Light blinks. Less than 10% Red Light blinks once. Red Light blinks twice. Red Light blinks 3 times. Red Light blinks 4 times. Full 3. Remote Controller LEDs Status LED Red Light is on. Drone Disconnects with RC. Green Light is on. Drone Connects with RC.

  • Page 82: Remote Controller Vibration

    Watch Second-Level Low Battery Alarm Vibrate once every 2s before battery runs out. Drone Low-Battery Alarm Prompts & Vibrate 3 times Drone Low-Battery Go-Home Prompts & Vibrate once every 2s Drone Low-Battery Land Prompts & Vibrate once every 2s Drone Battery Data Lost Prompts &...

  • Page 83: Faq

    Moreover, you should purchase a standard GoPro Connection Cable from own one? CEEWA. Be cautious during mounting procedures, CEEWA takes no responsibility of damages due to changing cameras. If I have more than one Sports Watch and Remote Controller, could I use them at the...
  • Page 84 Controller? * For starters, please select Position Mode. Attitude Mode is suitable for professionals. * CEEWA APP activates Beginner Mode by default. During this mode, A Mode disables. When Beginner Mode enables, users cannot switch to A Mode. Without What is Beginner Mode? GPS, motors cannot turn on.

  • Page 85: Appendix: Mount/Detach Image Transmission

    Appendix: Mount/Detach Image Transmission Mount If you purchase the Image Transmission separately, you need to mount it into Drone and install the ground system onto the back of Remote Controller. Steps: ① Detach two screws on the top and bottom side of Drone hatch. ②...

  • Page 86: Appendix: Mount Follow Module

    Appendix: Mount Follow Module Please mount Follow Module into armband. Please ensure the side with LED light faces up and do not be covered. Fix the armband onto the upper arm. Fix the Follow Module onto Multi-rotors and Fixed-Wings with Double-coated Foam Tapes. Please make sure it is far away from magnetic interference, such as motors and servo.
