AM21 Quick Setup
TM
Installing Your AM21
1. Place your DIRECTV USB OFF-AIR TUNER on top of or underneath your DIRECTV® Receiver.
2. Disconnect the power cable from the back of the receiver.
3. Connect the USB cable from the AM21 to the Receiver.
4. Connect the off-air antenna to the AM21.
5. Connect the power cable that comes with the AM21 to the Receiver.
6. Connect the power cable that was removed from the receiver to the AM21.
Satellite
Antenna
Cables
ATSC
Off-Air
Antenna
Main Power
Cable
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN!
1 meter
USB
Power
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN!
Cable
ETHERNET
HDMI
Be Aware
Note: The following DIRECTV® Receiver models are
compatible with the USB Off-Air Tuner: DIRECTV Plus®
HD DVR (models HR21 and above, DIRECTV Plus®
DVR (R22 model only), DIRECTV® HD (models H21 and
above) or DIRECTV Advanced Whole-Home DVR.
Quick Setup Guide
Version 1.0.0 - 02/21/2013
1
1

Advertisement

loading

Summary of Contents for DirecTV am21

  • Page 1 Quick Setup Guide Installing Your AM21 1. Place your DIRECTV USB OFF-AIR TUNER on top of or underneath your DIRECTV® Receiver. 2. Disconnect the power cable from the back of the receiver. 3. Connect the USB cable from the AM21 to the Receiver.
  • Page 2 AM21 Quick Setup Quick Setup Guide Setting Up Your AM21 1. Go to 3. Select Menu Settings & Help Settings Antenna Setup 2. Select Sat & Antenna 4. Select Initial Setup Version 1.0.0 - 02/21/2013...
  • Page 3 If there is a secondary market to add, select Local. If not, select Done. Secondary 6. The AM21 and receiver will scan for local channels. 8. The receiver will re-acquire satellite data with the new channels. Select Continue when prompted.
  • Page 4 AM21 Quick Setup Quick Setup Guide Finalizing AM21 Setup To change what channels will appear in the guide, or view screen will display the signal ∎ ∎ Antenna Signal Strength the antenna signal strength, select on each channel the off-air antenna is picking up.
