INTRODUCTION INTRODUCTION Congratulations on purchasing the SuperHalo, the finest cellular booster available! The SuperHalo adjustable cellular boosters and kits remove the frustration over dropped calls, limited range, and slow data rates by amplifying incoming and outgoing cellular signals in watercraft of all sizes. The SuperHalo is designed with leading-edge technology to detect and amplify weak incoming signals your cellular device would otherwise miss and to broadcast a significantly stronger signal back to the cell tower.
INTRODUCTION INTRODUCTION INTRODUCTION SuperHalo Package Unpack all package contents, compare them against the package contents list, and check for damage. For missing or damaged items, contact your retailer. Keep the carton and packing material to store the product or if you need to return it. booster outside antenna inside antenna...
INSTALLATION Mount outside antenna in an elevated area with a 12” radius clear of obstructions Install CM240 Low coax cable from outside antenna to cellular booster Quick Using provided cable, connect booster to inside antenna Install Install inside antenna in location where increased Guide cell reception desired most Using power cord, plug booster into power source...
INSTALLATION INTRODUCTION Configuring Gain Settings 1. Facing the front of your booster, find the following dials starting from the top: A. LTE-A (AT&T 4G) B. LTE-U (Verizon 4G) C. Cellular-800 (All Carriers 2G/3G) D. PCS-1900 (All Carriers 2G/3G) E. AWS (T-Mobile 4G) 2.
INSTALLATION Installation Steps The SuperHalo booster kit is specially designed for installation on watercraft. Can be used in other applications with appropriate mounting hardware. Step 1. Connect the Outside Antenna -Galaxy 5239 Galaxy 5239 is a full-band antenna, built specifically for marine use, it is weather resistant.
Page 7
INSTALLATION INTRODUCTION OPTION 2 1. When location of outside antenna has been determined, remove cap from ferrule side hole. 2. Feed FME connector (small end) and cable through side hole on the ferrule as shown in figure below. 3. Feed remainder of cable through ferrule hole until approx. 1” of cable remains. 4.
Page 8
INSTALLATION Step 3. Connect the interior Antenna A : Standard Wireless Usage - ( Recommended ) - CM248W-M This CM248W full band panel antenna is a compact directional antenna designed to cover 2G/3G/4G and WLAN systems for Cellular, PCS, AWS and LTE frequencies. It’s a high gain indoor antenna suited for places where the signal needs to be broadcast over a wide area.
Page 9
INSTALLATION INTRODUCTION Step 4. Booster Mount If mounting booster, mount on vertical location using booster screw fittings. Step 5. Connect to DC Power 1. The positive red and negative black wired end will connect to watercraft’s power supply-either battery, ignition or fusebox – whichever is located most conveniently. 2.
TROUBLESHOOTING Record the model and serial number for your products: Serial #: Purchase Date: Avoiding Interference If the booster interferes with your radio or other electronic receivers, move the booster further away from those devices. Frequently Asked Questions For a list of Frequently Asked Questions and a comprehensive, up-to-date Troubleshooting Guide, please visit our website at: www.surecall.com.
Page 11
TROUBLESHOOTING INTRODUCTION 1. Verify that the rocker switch on the power supply is turned on and red LED is ON. 2. Connect the power supply to an alternate power source. 3. Be sure the power source is not controlled by a switch Booster has no power that can remove power from the outlet.
WARRANTY Three-Year Product Warranty SureCall warrants its products for three years from the date of purchase against defects in workmanship and/or materials. Specifications are subject to change. The three-year warranty only applies to products meeting the latest FCC Certification Guidelines stated on 2/20/2013 and going into effect April 30, 2014.
Page 13
Booster Technical Specs CA-VAT-10-R Model No. Uplink: 698-716, Downlink: 728-746 Uplink: 1850-1915, Downlink: 1930-1995 Uplink: 776-787, Downlink: 746-757 Uplink: 1710-1755, Downlink: 2110-2155 Frequency Uplink: 824-849, Downlink: 869-894 50ohm Input / Output Impedance 50dB Maximum Gain ≤ 2.0 VSWR CDMA, WCDMA, GSM, EDGE, HSPA+, EVDO, LTE and all cellular standards Standard Supported 100+ Mbps Throughput...
