Summary of Contents for Europort EPA900
- Page 1 User Manual EUROPORT EPA900 Ultra-Compact 900-Watt 8-Channel Portable PA System with Digital Effects and FBQ Feedback Detection...
-
Page 2: Table Of Contents
5. Specifications ............. 9 6. Effects Table ............. 10 Thank you Thank you for purchasing the EUROPORT EPA900. The EPA900 is a portable, ultra-compact powered mixer/loudspeaker combination with enormous power, unbelievable sound, and an extremely low weight. The mixer unit has 8 input channels (4 mono and 2 stereo channels), an internal 24-bit studio-quality... -
Page 3: Important Safety Instructions
EUROPORT EPA900 User Manual 9. Do not defeat the safety purpose of the polarized TO BIND MUSIC GROUP BY ANY EXPRESS OR IMPLIED Important Safety or grounding-type plug. A polarized plug has two blades UNDERTAKING OR REPRESENTATION. THIS MANUAL Instructions with one wider than the other. A grounding-type plug IS COPYRIGHTED. -
Page 4: Before You Get Started
Be sure that there is enough space around the unit for cooling. To avoid overheating, please do not place the EPA900 near radiators and other equipment The EPA900 mobile PA system consists of two loudspeakers and a powered mixer emanating heat. -
Page 5: Setup
Connections Channels 5/6-7/8 are designed as stereo channels and are used to connect stereo The EPA900 mixer is equipped with 4 mono and 2 stereo inputs and an additional line-level sources. AUX input. The input signals are internally distributed to a stereo bus. It is also possible to use its channels separately (mono), such as when used for FOH/PA and 3.2.1 Line Inputs... -
Page 6: Channel Strips
The LEVEL control is used to set the volume of the channel signal. If the CLIP LED is lit up, the level has to be reduced using this control. 3.4 Additional connections The EPA900 is equipped with additional inputs and outputs as well as a footswitch connector. Fig. 3.3: Channel strip for a mono channel TREBLE/BASS The equalizer section comprises these two controls. -
Page 7: Speaker Outputs
3.7 Effects unit The SPEAKER OUTPUTS connectors on the back of the unit are used to connect the The EPA900 is equipped with an internal stereo effects processor, which offers supplied loudspeakers. 100 different standard effects, including reverb, chorus, flanger, and echo, as well as various multieffects. -
Page 8: Power Supply And Serial Number
4. Applications POWER Switch The EPA900 can be used for simple sound tasks, e.g., amplification of the Use the POWER switch to start up the unit. The POWER switch should be in the presenter’s voice, playback sound, or karaoke applications, as well as for “Off”... -
Page 9: Specifications
EUROPORT EPA900 User Manual 5. Specifications Inputs 1-4 Effects Type 4 x XLR, electronically balanced, Converter 24-bit delta-sigma 4 x ¼" TRS jack, electronically balanced Sampling frequency 40 kHz Impedance approx. 2.2 kΩ , balanced, Display 2-digit, 7-segment approx. 1.1 kΩ , unbalanced... -
Page 10: Effects Table
EUROPORT EPA900 User Manual 6. Effects Table EFFECT PRESETS EFFECT Description EFFECT Description HALL 00-09 DELAY 50-59 SMALL HALL 1 approx. 1.0s reverb decay SHORT DELAY 1 Like a short shattering SMALL HALL 2 approx. 1.2s reverb decay SHORT DELAY 2... - Page 11 EUROPORT EPA900 User Manual FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE INFORMATION EUROPORT EPA900 MUSIC Group Services US Inc. Responsible Party Name: 18912 North Creek Parkway, Address: Suite 200 Bothell, WA 98011, Phone: +1 425 672 0816 Phone/Fax No.: Fax: +1 425 673 7647 EUROPORT EPA900 complies with the FCC rules as mentioned in the following paragraph:...
- Page 12 We Hear You...
