Service Jacks
Operating Instructions & Parts Manual
Model Number
HW93642
HW93652
-Before using this product, read this manual and follow all its Safety Rules and Operating Instructions
HW93642-M0
Capacity
2 Ton
3 Ton
10939 N. Pomona Ave. Kansas City, MO 64153
customerservices@heinwerner-automotive.com
Made in the USA
SFA Companies ©2005
816-891-6390

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HW93642 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hein-werner HW93642

  • Page 1 Service Jacks Operating Instructions & Parts Manual Model Number Capacity HW93642 2 Ton HW93652 3 Ton Made in the USA SFA Companies ©2005 10939 N. Pomona Ave. Kansas City, MO 64153 816-891-6390 customerservices@heinwerner-automotive.com -Before using this product, read this manual and follow all its Safety Rules and Operating Instructions...
  • Page 2: Two Year Limited Warranty

    Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. HW93642-M0...
  • Page 3: Product Description

    (a load dropped suddenly, unexpectedly upon it), immediately discontinue to use until jack has been checked by a Hein-Werner authorized service center. It is recommended that an annual inspection be done by qualified personnel. Labels and Operator's Manual are available from manufacturer.
  • Page 4: Operation

    Using the other jack, lower the load by turning the operating handle counterclockwise, but no more than 1/2 turn. 3. After removing jack from under the load, push saddle down to reduce ram exposure to rust and contamination. HW93642-M0...
  • Page 5: Maintenance

    When ordering parts, give Model number, parts number and description on page 6 and 7. Call or write for current pricing: Phone:(816) 891-6390 or contact Hein-Werner Customer Support, customerservices@heinwerner-automotive.com or 10939 N. Pomona Ave. Kansas City, MO 64153...
  • Page 6 Frame Section Hydraulic Unit Cross Section Handle Cross Section Hydraulic Unit Base Figure 2: Parts Illustration for HW93642 and HW93652 HW93642-M0...
  • Page 7 Replacement Parts List Item# Part# for HW93642 Part# for HW93652 Qty. Description ο 231583 231583 Caster, 2.5"x1.25" ο 201115 201115 Lock Washer, 3/4" ο 219451 219451 Hex Nut, 3/4"-10 231584 231584 Caster Assembly (includes item# 1-3) 201801 201801 Retaining Ring...
