Quick start guide:
Eltako GFVS-Touch II

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GFVS-touch II and is the answer not in the manual?

Questions and answers

Related Manuals for Eltako GFVS-touch II

Summary of Contents for Eltako GFVS-touch II

  • Page 1 Quick start guide: Eltako GFVS-Touch II...

  • Page 2: Table Of Contents

    Quick start guide Eltako GFVS-Touch II Index General ............................4 Scope of delivery ..........................4 Specifications ........................... 4 Connections of the Eltako GFVS-Touch II ..................5 First-start-up ............................ 8 Operation ..........................9 5.1.1 Right-mouse button ......................9 5.1.2 Onscreen keyboard ......................9 5.1.3...
  • Page 3 Quick start guide Eltako GFVS-Touch II Export log-files ........................25 Shuttle-tools .......................... 25 OSD-keyboard ........................25 Switch off Eltako GFVS-Touch II ....................26 Restore system backup ......................26 Instructions for permanent operation ..................28 Technical support ........................29...

  • Page 4: General

    Quick start guide Eltako GFVS-Touch II 1 General To ensure reliable function of the product please read this manual carefully. The liability of Eltako GmbH for defects shall be excluded if the defects are due to usage not according to the intended purpose or ignoring the operating instruction (incorrect installation, incorrect start-up, incorrect operation, etc.).

  • Page 5: Connections Of The Eltako Gfvs-Touch Ii

    Other integrated Components: FAM-USB 2.0 Megapixel Webcam 2 x 2 W loudspeakers compatible to 100x100mm VESA mounting Software and Applications: Eltako GFVS 3.0 PCT 14 Software Backup- and restore-function 4 Connections of the Eltako GFVS-Touch II Figure 1: Front view...
  • Page 6 Quick start guide Eltako GFVS-Touch II Figure 2: Backside Figure 3: connections left Figure 4: connections right...
  • Page 7 Quick start guide Eltako GFVS-Touch II Touchscreen LCD Display Webcam Microphone Operation display LED Hard-disk LED-display Stereo speakers VGA-output Input for power supply USB-2.0-connection Network connection USB-3.0 connection HDMI-connection Audio line output (headphones) Microphone input Foot/Handle Switch on-/off-button Touchscreen stylus-pen SD-card reader USB-2.0 connection...

  • Page 8: First-Start-Up

    Quick start guide Eltako GFVS-Touch II 5 First-start-up • Connect the external power supply to a 230V socket and the GFVS-Touch II, the blue LED shows power supply • To configure the software connect keyboard and mouse to the USB ports •...

  • Page 9: Operation

    Quick start guide Eltako GFVS-Touch II Eltako GFVS 3.0-Software is running: Figure 7: Eltako GFVS 3.0 software has been started The task bar is located on the bottom of the screen. Beside date and time the icon for the network connection is displayed.

  • Page 10: Volume Control

    The menu is invoked by a right-click on the background: Figure 10: Menu Eltako GFVS-Touch II 5.3 Eltako GFVS 3.0-Software Eltako GFVS 3.0-Software is launched via the menu item “GFVS 3.0“. A detailed manual is available under the menu item “manuals – Eltako GFVS 3.0 manual”. 5.4 PCT 14...

  • Page 11: Date/Time

    Quick start guide Eltako GFVS-Touch II 5.5 Date/Time Via the menu item “systems settings - date/time” you invoke the dialog to adjust date/time: Figure 11: Time and date settings 5.6 Language selection Via the menu item “system settings – language selection“ you invoke the dialog to change the language.

  • Page 12: Remote Settings

    Via the menu item “system settings – remote-settings“ further settings for remote access can be made. Figure 14: Remote settings If you connect another computer via crossover cable to the network port of the Eltako GFVS-Touch II, you can directly access with a remote client (e.g. TightVNC).

  • Page 13: Presets

    Figure 16: configuration menu 5.11 Presets 5.11.1 License The Eltako GFVS-Touch II is delivered with an activated Eltako GFVS 3.0 license. If re-activation is required, an Eltako GFVS 3.0 license key is attached. 5.11.2 Database For data storage a PostgreSQL database is established.

  • Page 14: Eltako Quickcon®-Technology

    Figure 17: GFVS-Update 6 Eltako quickcon®-technology Permits the set-up of a simple connection between the Eltako GFVS Server and a Mobile Client without any knowledge of changing IP addresses (e.g. DynDNS) or disable ports. Caution: Using the app generates data traffic, which may lead to additional costs, depending on the mobile phone contract.
  • Page 15 Quick start guide Eltako GFVS-Touch II Figure 19: profile manager Then create a new device in the Eltako GFVS 3.0 software using “configuration – security – client – Eltako GFVS 3.0 mobile“. Figure 20: create a mobile client...
  • Page 16 Note: The device name must be identical in the app and the GFVS server. (Please pay attention to the blanks!) Then assign a profile to the device. Without a profile the device has no rights in the Eltako GFVS 3.0 software.
  • Page 17 All generated profiles are displayed in the drop-down box: Figure 23: Assigning a profile Click on the button “key “ in the Eltako GFVS 3.0-Software to open the dialog for entering the password. You may enter any password without restrictions. Then also enter this password in the “password”...

  • Page 18: System Tools

    Quick start guide Eltako GFVS-Touch II Figure 25: IMEI of the GFVS server Click “save“ to complete the process. Note: Saving the device name and the IMEI of the mobile device, ensures that no unknown device can be connected. 7 System tools 7.1 GFVS-tools...

  • Page 19: Backup, Restore Or Delete Database

    Quick start guide Eltako GFVS-Touch II The following dialog appears: Figure 27: Eltako GFVS 3.0 system tools For a backup, absolutely make sure that the Eltako GFVS 3.0 software was finished. Otherwise, an error message appears: Figure 28: database in use 7.1.1 Backup, restore or delete database...
  • Page 20 As soon as the backup is finished, a new dialog appears. Confirm with “ok“. Figure 30: successful database backup After each restart of the Eltako GFVS II, an automatic backup of the database takes place. If you want to restore an older database select it from the drop-down box. Alternatively a database with the delivery status of Eltako GFVS-Touch II can be selected.

  • Page 21: System Backup

    Quick start guide Eltako GFVS-Touch II Figure 33: delete backup In the following dialog you are asked, if you want to delete the database. Confirm with “yes“ to delete the selected database or “no“ to cancel the operation. 7.1.2 System backup Click on the button “backup system“...

  • Page 22: Reset License For License Issues

    The button “delete license“ deletes your Eltako GFVS 3.0 license. A click opens a window for entering the password. Password: 0000 This option should only be used in case of an emergency by the Eltako GFVS 3.0 support. Note that the Eltako GFVS 3.0 software cannot be used without a valid license. Furthermore, an internet connection is required to activate the new license.

  • Page 23: Repair License

    Quick start guide Eltako GFVS-Touch II 7.2 Repair license The activated Eltako GFVS 3.0 license is saved in the background every hour. If the license has been damaged by a power failure or similar, it can be restored using this menu item: Figure 38: restore license 7.3 Code MeterCC...

  • Page 24: Techn. Support (Team Viewer)

    Figure 40:team viewer 8.2 Copy wallpapers You can copy your own background images and custom icons from an USB stick to the Eltako GVFS- Safe II. Note: The following folder structure has to be set up on an empty USB stick: /hc_import/pictures/*.*.

  • Page 25: Export Log-Files

    Quick start guide Eltako GFVS-Touch II 8.3 Export log-files System generated log files can be copied on an USB stick. Therefore put a check next to “export directory“ and then click “export”. Note: The following folder structure has to be set up on an empty USB stick: /hc_export/export/*.*.

  • Page 26: Switch Off Eltako Gfvs-Touch Ii

    Choose if you want to restart the pc in recovery mode, reboot or turn it off. 10 Restore system backup To restore a system backup, click on the menu “power – restart in recovery mode“. The Eltako GFVS II shuts down and starts in recovery mode.
  • Page 27 The button “restore factory default backup“ resets the Eltako GFVS-Touch II back to its factory condition. In this case all data will be lost. To restore a backup, select from the drop-down box and click on “recover user backup“. The Eltako GFVS-Touch II will restart.

  • Page 28: Instructions For Permanent Operation

    Eltako GFVS-Touch II is developed for 24-hours-continous operation (24/7) Requirement for continuous operation: • Ambient temperature in operation: 5-35°C • Humidity in operation: 10-80% (non-condensing) • free air circulation in the vicinity of the GFVS-Touch II • freely accessible ventilation holes...

  • Page 29: Technical Support

    Quick start guide Eltako GFVS-Touch II 12 Technical support For support please contact: ELTAKO GmbH Hofener Straße 54 70736 Fellbach Germany Tel. 0162 2575-124, -125, -126, -127 Fax +49711 5183740 or via E-Mail to: Technik-Beratung@eltako.de...
