AudioArts Engineering adr-32 Technical Manual

Digital audio router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ADR-32
Digital Audio Router
T echnical
Manual
D
2002
ECEMBER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the adr-32 and is the answer not in the manual?

Questions and answers

Summary of Contents for AudioArts Engineering adr-32

  • Page 1 ADR-32 Digital Audio Router T echnical Manual 2002 ECEMBER...
  • Page 2 ADR-32 Digital Audio Router Technical Manual - 1st Edition ADR-32 Digital Audio Router Technical Manual - 1st Edition ADR-32 Digital Audio Router Technical Manual - 1st Edition ADR-32 Digital Audio Router Technical Manual - 1st Edition ADR-32 Digital Audio Router Technical Manual - 1st Edition ®...
  • Page 3 Wheatstone Corporation could void the user's authority to operate this Wheatstone Corporation could void the user's authority to operate this equipment. equipment. equipment. equipment. equipment. R R R R R M M M M M ! ! ! ! ! ADR-32 / Dec 2002 E E E E E...

  • Page 4: Table Of Contents

    Analog Input Card (ADC-4) Overview ..................2-9 Analog Input Interface ............... 2-9 Internal Programming Options ............ 2-9 Hook-Ups ................... 2-10 Analog Audio Connections .................. 2-10 Mono Inputs ......................2-10 DB Pinout Drawing ..............2-11 page Contents – 1 ADR-32 / Dec 2002...
  • Page 5 “CONSOLE I/O” DB-9 - Serial Interface Port Connections ......... 2-25 “XYC I/O” DB-9 - Serial Interface Port Connections ........... 2-25 RJ-45 - Ethernet Connections ................2-25 Typical Ethernet Cable ............. 2-26 Typical Crossover Cable ............2-26 DB Pinout Drawing ..............2-27 page Contents – 2 ADR-32 / Dec 2002...
  • Page 6 Getting Started ................4-4 GUI Log-In ..................4-4 Passwords ........................ 4-4 Tier Configuration ................. 4-5 Connection Between the Configuration GUI and ADR-32 ..4-6 Signal Definition ................4-9 Important Signal Definition Notes ..........4-9a Signal Locking ................4-10 Salvo Definition ................4-11 XY Rack or Console XY Controller Configuration ....
  • Page 7 XY GUI Controller Configuration ..........4-14 Saving and Loading Configurations ........4-14a Off-line Editing ....................4-14a Sending a Configuration to the ADR-32 ............. 4-14a Main Menu Summary ............... 4-15 Chapter 5 - I/O Schematic Drawings 4 Analog Inputs Card Schematic (ADC-4) ............5-2 4 Analog Inputs Card Load Sheet (ADC-4) ............
  • Page 8 Introduction ................... 1-2 Power Supply ................1-3 Audio Connections ............... 1-3 Digital Audio Connections ..................1-3 Unbalanced Analog Connections ................1-4 Unbalanced Digital Connections (SPDIF) ..............1-4 Hand Crimp Tool Wiring Instructions ......... 1-5 page 1 – 1 ADR-32 / Dec 2002...

  • Page 9: General Information

    Audio Engineering Society (AES) format, and switches them to any of 32 stereo analog or digital outputs. The ADR-32 cage may be fitted with up to 8 input and 8 output cards. page 1 – 2 ADR-32 / Dec 2002...

  • Page 10: Power Supply

    Under no circumstances should the metal cover be removed! If you have a problem with the power supply, the ADR-32 unit must be returned to Wheatstone Corporation for repair.

  • Page 11: Unbalanced Analog Connections

    SPDIF center conductor (HOT) to the HI input pin and SPDIF shell (ground) to the LO input. Connect SH at the ADR-32 router end only. To correctly match the SPDIF signal level of approximately 500mV and 75 ohm impedance to the ADR-32 AES inputs, be sure to set the appropriate internal 75Ω...

  • Page 12: Hand Crimp Tool Wiring Instructions

    (see next page). Note that metallized plastic hoods for each connector are also supplied with the router. (4) Final step: jaws fully closed; the insulation tabs have been crimped. page 1 – 5 ADR-32 / Jun 2004 ADR-32 / Dec 2002...
  • Page 13 Then pull out the terminal pin from Housing. It should never be necessary to discard a con- nector due to a wiring error. (5) Place extractor tip over pin terminal to be removed. page 1 – 6 ADR-32 / Jun 2004 ADR-32 / Dec 2002...
  • Page 14 Analog Output Interface ............2-16 Internal Programming Options ..........2-16 Hook-Ups ................... 2-16 Analog Audio Connections .................. 2-17 Mono Outputs ...................... 2-17 External Mono Summing ..................2-18 DB Pinout Drawing ..............2-19 page 2 – 1 ADR-32 / Dec 2002...
  • Page 15 “CONSOLE I/O” DB-9 - Serial Interface Port Connections ......... 2-25 “XYC I/O” DB-9 - Serial Interface Port Connections ........... 2-25 RJ-45 - Ethernet Connections ................2-25 Typical Ethernet Cable ............. 2-26 Typical Crossover Cable ............2-26 DB Pinout Drawing ..............2-27 page 2 – 2 ADR-32 / Dec 2002...

  • Page 16: Overview

    H A R D W A R E Hardware Overview The ADR-32 may be configured for a variety of I/O card complements using various combinations of analog and digital audio input and output cards. All audio input and output signal connections are made via multipin DB-25 connectors located on the cage rear and mounted on the input/output daughter cards.

  • Page 17: Configuration Guidelines

    9 through 16. Digital input and output cards each handle eight inputs/outputs, while analog input and output cards each handle four inputs/outputs. The ADR-32 can support up to four digital input cards and four digital output cards, or up to eight analog input cards and eight analog output cards.
  • Page 18 Failure to do so will damage the expansion card, ribbon cable, and/or motherboard. • Configuring the software - The ADR-32 software has been pre-configured to automatically recognize a newly installed audio I/O card. You may run the X-Point application to edit the pre-configured I/O names to match your new sources or destinations.

  • Page 19: Digital Input Card (Src-8)

    Digital Input Card (SRC-8) Overview The SRC-8 digital audio input cards for the ADR-32 accept up to 8 AES-3 formatted stereo sources (i.e. 16 mono channels). A Signal Defini- tions form in the supplied X-Point software allows the user to set attributes for the input channels including signal name, type, circuit #, etc.

  • Page 20: Internal Programming Options

    Pin 5 – SH Pin 15 – HI Pin 3 – LO AES 7 In Pin 16 – SH Pin 1 – HI Pin 14 – LO AES 8 In Pin 2 – SH page 2 – 7 ADR-32 / Dec 2002...
  • Page 21 AES 6 IN LO AES 6 IN HI AES 7 IN SH AES 7 IN LO AES 7 IN HI AES 8 IN SH AES 8 IN LO AES 8 IN HI page 2 – 8 ADR-32 / Dec 2002...

  • Page 22: Analog Input Card (Adc-4)

    Reference Notes: 0dBu = .7746 V RMS, +4dBu = 1.23V RMS dBFS = dB Full Scale Digital -20dBFS = +4dBu Internal Programming Options There are no internal programming options on the ADC-4 card. page 2 – 9 ADR-32 / Dec 2002...

  • Page 23: Hook-Ups

    Optionally, you may reconfigure stereo inputs for 2 channel mono operation in software. Please see “Signal Definition” section in the “X-Point Software Setup Guide”. page 2 – 10 ADR-32 / Dec 2002...
  • Page 24 CHANNEL 7 (STEREO 4 LT) IN LO CHANNEL 7 (STEREO 4 LT) IN HI CHANNEL 8 (STEREO 4 RT) IN SH CHANNEL 8 (STEREO 4 RT) IN LO CHANNEL 8 (STEREO 4 RT) IN HI page 2 – 11 ADR-32 / Dec 2002...

  • Page 25: Digital Output Card (Do-8)

    The digital output signal reference level is -20dBFS. A +4dBu analog input signal yields a -20dBFS digital output signal. Channel Status imple- mentation complies with rules for “Standard implementation” as described in the AES-3 1992 specification. page 2 – 12 ADR-32 / Dec 2002...

  • Page 26: Aes Channel Status Implementation

    Pin 11 – SH Pin 21 – HI Pin 9 – LO AES 3 Out Pin 22 – SH Pin 7 – HI Pin 20 – LO AES 4 Out Pin 8 – SH page 2 – 13 ADR-32 / Dec 2002...
  • Page 27 Pin 5 – SH Pin 15 – HI Pin 3 – LO AES 7 Out Pin 16 – SH Pin 1 – HI Pin 14 – LO AES 8 Out Pin 2 – SH page 2 – 14 ADR-32 / Dec 2002...
  • Page 28 AES 6 OUT LO AES 6 OUT HI AES 7 OUT SH AES 7 OUT LO AES 7 OUT HI AES 8 OUT SH AES 8 OUT LO AES 8 OUT HI page 2 – 15 ADR-32 / Dec 2002...

  • Page 29: Analog Output Card (Ao-4)

    50Ω and a nominal output signal level of +4dBu for an analog input signal of +4dBu (-20dBFs digital) . Internal Programming Options There are no internal programming options on the AO-4 card. page 2 – 16 ADR-32 / Dec 2002...

  • Page 30: Hook-Ups

    Channel 8 Out Pin 2 – SH Mono Outputs There are two ways to adapt the ADR-32 for mono operation. Externally sum a stereo output using 1kΩ resistors, or reconfigure the output in software for mono operation. Please see the “X-Point Software Setup Guide”...

  • Page 31: External Mono Summing

    H A R D W A R E External Mono Summing To sum an ADR-32 stereo analog output add a 1kΩ resistor in series with each leg of the balanced output. Add resistors as close as possible to the mono input.
  • Page 32 CHANNEL 7 (STEREO 4 LT) OUT LO CHANNEL 7 (STEREO 4 LT) OUT HI CHANNEL 8 (STEREO 4 RT) OUT SH CHANNEL 8 (STEREO 4 RT) OUT LO CHANNEL 8 (STEREO 4 RT) OUT HI page 2 – 19 ADR-32 / Dec 2002...

  • Page 33: Overview

    ADR-32’s internal speaker destination. The mono monitor output is electronically balanced, and operates at line level. A speaker mute function is included for applications where the ADR-32 is mounted in an ON-AIR or Production control room. A contact closure across pins 1 and 6 will mute the ADR-32’s internal speaker.
  • Page 34 H A R D W A R E Monitor Connections MONITOR SH MONITOR LO MONITOR HI PORTS (DB-9) SPKR MUTE page 2 – 21 ADR-32 / Dec 2002...

  • Page 35: Overview

    Wheatstone ADR-32 digital audio routers ship with the CPU IP address set for 192.168.1.160. Peer to peer connections between a PC and the ADR-32 only require you to set the PC IP address to live on the same subnet as the ADR-32.

  • Page 36: Ethernet Interface Wiring

    H A R D W A R E Ethernet Interface Wiring Stand-alone systems are defined as the ADR-32 connected to an X-Point configuration PC and not interfaced to a station’s existing network. Stand- alone systems are “point to point” configurations and are connected by a CAT-5 crossover cable.

  • Page 37: Jumper Settings

    Note: Each ADR-32 XY Controller ID# is set using jumpers J3-J10. These jumpers are read as an 8 bit field with Bit Ø mapped to J10 and Bit 7 mapped to J3. This ID# is read by the CPU at boot up and is required by the ADR-32 serial communications software.

  • Page 38: Serial Interface Ports

    6 – TX2 LO (RS-485) RJ-45—E THERNET ONNECTIONS 1 – TXD + 2 – TXD - 3 – RXD + 4 – N/C 5 – N/C 6 – RXD - 7 – N/C 8 – N/C page 2 – 25 ADR-32 / Dec 2002...
  • Page 39 RXD - TXD - Green Orange White/Brown White/Brown Brown Brown “ ” SED FOR SIMPLE POINT TO POINT CONNECTIONS BETWEEN THE SUPPLIED PC’ CPU. ONFIGURATION CARD AND THE page 2 – 26 ADR-32 / Nov 02 ADR-32 / Dec 2002...

  • Page 40: Ethernet Connections

    RX1 HI (RS-485) RX (RS-232) TX (RS-232) TX1 LO (RS-485) TX2 LO (RS-485) TX1 HI (RS-485) TX2 HI (RS-485) Ethernet Connections (RJ-45) TXD + TXD - RXD + RXD - page 2 – 27 ADR-32 / Nov 02 ADR-32 / Dec 2002...
  • Page 41 Wheatstone Console Interface ..........3-8 Wheatstone Console RS-485 Connections ......3-8 Console RS-485 Cable Pinouts ..........3-8 Console CPU Module Settings ..........3-9 Console Address ....................3-9 RS-485 Select / Termination .................. 3-9 page 3 – 1 ADR-32 / Dec 2002...

  • Page 42: Xp Configuration Gui

    C O N T R O L L E R D E V I C E S Controller Devices The ADR-32 audio router has provisions for two levels of software control and also two dedicated hardware controllers. Software configuration and control of the system is handled by the X-Point Configuration GUI described below.

  • Page 43: Xy Controller Gui

    The X-Point application running in XY Controller mode is also known as a “Crosspoint GUI”. Like the Configuration GUI, this device communicates to the ADR-32 over Ethernet. However, it uses a UDP broadcast interface, which allows multiple XYC GUI’s to communicate to the switch simulta- neously.

  • Page 44: Console Xy Controller

    Below are the tables of switch positions and their weights. XY RACK/XYC PANEL (D-70, ALM-12d & D-16) DIPSWITCH # POSITION WEIGHT page 3 – 4 ADR-32 / May 2003 ADR-32 / Dec 2002...

  • Page 45: Xy Controller Signal Visibility

    Overview The XY Rack and console mount controllers communicate with the ADR-32 router via an RS-485 serial interface bus. The cable should be a low capacitance computer communications cable. Depending on the type of XY Controller, there are two type of cables: •...

  • Page 46: Serial Port Note

    Typical RS-485 Cable Specifications Conductors 4 conductor plus shield (2 twisted pairs) Conductor Gauge 24 AWG (7 x 32 AWG) TC Nom. Capacitance 12.8 pF/ft 41.9 pF/m @ 1 MHz Impedance 125 ohms, Nominal page 3 – 6 ADR-32 / Dec 2002...

  • Page 47: Xy Controller Rs-485 Cable Pinouts

    TX + Console End ADR-32 End Pair 1 Pair 1 TX - XY-4/8 module XYC I/O RX + Connector Type Connector Type Upper/Lower Pair 2 Pair 2 DB-9 Male RX - DB-25 Male page 3 – 7 ADR-32 / Dec 2002...

  • Page 48: Wheatstone Console Interface

    C O N T R O L L E R D E V I C E S Wheatstone Console Interface The ADR-32 has a powerful level of integration designed into the system which allows the user to map specific Wheatstone console input channel alpha-numeric displays to router destinations.

  • Page 49: Console Cpu Module Settings

    Console CPU Module Settings Certain dipswitch settings must be made on the connected Wheatstone consoles in order for them to be recognized by the ADR-32 system software. These settings are the console address, serial port mode, and RS-485 termina- tion.
  • Page 50 Getting Started ................4-4 GUI Log-In ..................4-4 Passwords ........................ 4-4 Tier Configuration ................. 4-5 Connection Between the Configuration GUI and ADR-32 ..4-6 Signal Definition ................4-9 Important Signal Definition Notes ..........4-9a Signal Locking ................4-10 Salvo Definition ................4-11 XY Rack or Console XY Controller Configuration ....

  • Page 51: Adr-32 Ethernet/Ip Address Quick Start

    Ethernet Cabling • Use a CAT 5 crossover ethernet cable to connect a PC directly to the ADR-32. • Use a standard CAT5 ethernet cable to connect the ADR-32 to your network hub. Default IP Address The ADR-32 router IP Address is set to 192.168.1.160 at the factory. In order to connect using the X-Point software, the PC must have a matching network prefix (i.e 192.168.1.xxx).

  • Page 52: Configuring Ip Address In X-Point Software

    • If you changed your PC's IP Address, enter the parameters exactly as displayed above. • If you changed the ADR-32's IP Address, enter the parameters you entered using the Network Configuration Utility program. If you are connected to the router, you should see a "Connecting to..."...

  • Page 53: Getting Started

    XY controller mapping, and optional Wheatstone console input channel mapping. Ethernet - The default IP Address of the ADR-32 is 192.168.1.160. Please see the Ethernet Quick Start preceding this section for details on changing the ADR-32’s IP Address.

  • Page 54: Tier Configuration

    1 for an ADR-32. Number of Tiers, IP Address, Switch Port, and Broadcast Port values must match the current settings of the ADR-32's CPU in order to connect. The Switch Port will normally be related to the tier using the formula 50NN2, where NN is the two digit tier ID (i.e.

  • Page 55: Connection Between The Configuration Gui And Adr-32

    Assuming the default configuration files start the Configuration GUI in ONLINE mode, a TCP connection to the ADR-32's CPU will be attempted, as indicated via the status message and yellow status indicator shown below.
  • Page 56 CPU and go to OFF- LINE mode, select the View / Mode / Offline menu option. The status indicator on the screen will then change shown to the left: Status Status Message Indicator page 4 – 7 ADR-32 / Dec 2002...
  • Page 57 X - P O I N T S O F T W A R E S E T U P G U I D E To connect to the ADR-32's CPU while in OFFLINE mode, select the View / Mode / Online menu option. The status indicator on the screen will then change to CONNECTING as discussed above.

  • Page 58: Signal Definition

    • Audio Signal Location Tab: Defines the signal’s physical location. • Tier ID & Rack ID will always be 1 for ADR-32 systems • Card # - valid input slots are 1,2,3 or 4, valid output slots are 5,6,7,8* •...

  • Page 59: Important Signal Definition Notes

    When configuring the ADR-32 it is important to remember that the ADR-32 is limited to a maximum of 4 virtual input cards and 4 virtual output cards. A fully loaded all digital box would have 4 physical input cards and 4 physical output cards.

  • Page 60: Signal Locking

    That crosspoint output signal becomes locked as indicated by red line through the signal on the GUI display and shown on form below: To Unlock a connection, right click on the destination and select “Unlock Connection”. page 4 – 10 ADR-32 / Dec 2002...

  • Page 61: Salvo Definition

    X - P O I N T S O F T W A R E S E T U P G U I D E Salvo Definition Macro control of the ADR-32 router is accomplished by creating and firing Salvos. A Salvo is simply a group of cross connects, disconnects and “do nothings”...

  • Page 62: Xy Rack Or Console Xy Controller Configuration

    (>>) box found between the columns. The left arrow but- tons are to remove signal(s) or salvo(s) from the visible list found in the right column. page 4 – 13 page 4 – 12 ADR-32 / Dec 2002...

  • Page 63: Console Configuration

    If the user changes the crosspoint-output-signal-to-console mapping, the Presets for that console may be invalidated. The user should go through and re- save the presets on that console after changing the console map! page 4 – 14 page 4 – 13 ADR-32 / Dec 2002...

  • Page 64: Xy Gui Controller Configuration

    (>>) box found between the columns. The left arrow buttons are to remove signal(s) or salvo(s) from the visible list found in the right column. Clicking the Apply button will save the visibility options. page 4 – 15 page 4 – 14 ADR-32 / Dec 2002...

  • Page 65: Saving And Loading Configurations

    Off-line Editing To Load a previously saved configuration while in OFFLINE mode (not connected to the ADR-32), select File•Open from the menu bar and select the appropriate folder. Click on the Apply button and the configuration is now loaded in to the X-Point software for review or editing.

  • Page 66: Main Menu Summary

    Save : Opens the Save Configuration form. Saves any or all changes. Send Cfg To Switch : Initiates download of currently loaded configuration to the ADR-32's CPU module. Use this to update the system hardware with config changes. Exit : Exits the X-Point program.
  • Page 67 View Switch Status : Lists all active installed hardware, card firmware revisions. Reset Switch : Initiates an ADR-32's CPU reboot. Use this function with caution! page 4 – 16 ADR-32 / Dec 2002...

  • Page 68: Analog Inputs Card Schematic (Adc-4)

    8 Digital Outputs Card Load Sheet (SRC-8) ............5-10 8 Digital Outputs Card Schematic (DO-8) .............. 5-11 8 Digital Outputs Card Load Sheet (DO-8) ............5-12 Processor Board Schematic (PR-32) ..............5-13 Processor Board Load Sheet (PR-32)..............5-18 page 5 – 1 ADR-32 / Dec 2002...
  • Page 69 5 - 2 ADR-32/May 2003...
  • Page 70 5 - 3 ADR-32/May 2003...
  • Page 71 S C H E M A T I C D R A W I N G S 4 Analog Inputs Card (ADC-4) - Load Sheet page 5 – 2 page 5 – 4 ADR-32 / Dec 2002...
  • Page 72 AGND New Bern, NC 28562 UDB3 DACSDATA3 CHECKED LINE4LTHI UDB15 AGND UDB2 DACSDATA2 LINE4RTLO ISSUED SIZE FSCM NO. DWG. NO. 80S00xx UDB14 LINE4RTHI UDB1 DACSDATA1 W# 700736 SCALE AO-4A PCB SHEET 1 OF 1 page 5 - 5 ADR-32/May 2003...
  • Page 73 CONTRACT NO. - Sergey Averin - APPROVALS DATE DRAWN 5-30-03 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 80S00xx W# 700736 SCALE AO-4A PCB SHEET 2 OF 2 page 5 - 6 ADR-32/May 2003...
  • Page 74 S C H E M A T I C D R A W I N G S 4 Analog Outputs Card (AO-4) - Load Sheet page 5 – 3 page 5 – 7 ADR-32 / Dec 2002...
  • Page 75 AGND New Bern, NC 28562 UDB3 SRCSDATA3 CHECKED LINE7_D_HI UDB15 AGND UDB2 SRCSDATA2 LINE8_D_LO ISSUED SIZE FSCM NO. DWG. NO. 80S0022 UDB14 LINE8_D_HI UDB1 SRCSDATA1 W# 700733 SCALE SRC-8A PCB SHEET 1 OF 2 page 5 - 8 ADR-32/May 2003...
  • Page 76 New Bern, NC 28562 CHECKED 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF ISSUED SIZE FSCM NO. DWG. NO. 80S0023 W# 700733 SCALE SRC-8A PCB SHEET 2 OF 2 page 5 - 9 ADR-32/May 2003...
  • Page 77 S C H E M A T I C D R A W I N G S 8 Digital Inputs Card (SRC-8) - Load Sheet page 5 – 4 page 5 – 10 ADR-32 / Dec 2002...
  • Page 78 AGND New Bern, NC 28562 UDB3 DOSDATA3 CHECKED LINE7_D_HI UDB15 AGND UDB2 DOSDATA2 LINE8_D_LO ISSUED SIZE FSCM NO. DWG. NO. 14S00xx UDB14 LINE8_D_HI UDB1 DOSDATA1 W# 700735 SCALE DO-8A PCB SHEET 1 OF 1 page 5 - 11 ADR-32/May 2003...
  • Page 79 S C H E M A T I C D R A W I N G S 8 Digital Outputs Card (DO-8) - Load Sheet page 5 – 5 page 5 – 12 ADR-32 / Dec 2002...
  • Page 80 5 - 13 ADR-32/Jun 2003...
  • Page 81 5 - 14 ADR-32/Jun 2003...
  • Page 82 5 - 15 ADR-32/Jun 2003...
  • Page 83 5 - 16 ADR-32/Jun 2003...
  • Page 84 5 - 17 ADR-32/Jun 2003...
  • Page 85 Processor Board (PR-32) - Load Sheet page 5 – 18 ADR-32 / Jun 2003...

  • Page 86: Glossary

    Output Channel IDs are assigned directly to the output devices. • Signal Type - Each input and output in the ADR-32 is associated with a type of signal. These include mono, stereo, or surround sound. The importance of this information at configuration time is the number of channels each signal consumes.

  • Page 87: Appendices

    A P P E N D I C E S Appendices Appendix 1 Configuring the ADR-32 Network Parameters ......A-3 Appendix 2 Replacement Parts List ............... A-6 page A – 1 ADR-32 / Dec 2002...
  • Page 88 A P P E N D I C E S Appendix 1 Contents Configuring the ADR-32 Router Network Parameters ....A-3 page A – 2 ADR-32 / Dec 2002...
  • Page 89 *Default Values Enter Number of Tiers [1]....: 1 Enter “1” for the total number of tiers in the system (ADR-32 is always 1 Tier). 3. Enter Tier #1 address [192.168.0.160]..: 192.168.1.160 Enter the IP address reserved for the router on your network. This address must be unique within the network.
  • Page 90 If a debug terminal is attached to the router, a confirmation message is printed. 9. Reboot the ADR-32 - power it down and then power it back up. The new network parameters now should be in effect. page A – 4...
  • Page 91 Contents Replacement Parts List ............... A-6 For the most part there are no user-replaceable parts in the ADR-32 Router. A complete list of available components is shown on the next page. Contact Wheatstone technical support for further informa- tion. Wheatstone Corporation (600 Industrial Drive, New Bern, North Carolina, USA 28562) may be reached by phone at 252-638-7000, fax 252-637-1285, electronic mail “email@wheatstone.com”.
  • Page 92 A P P E N D I C E S REPLACEMENT PARTS — ADR-32 ROUTER COMPONENT DESCRIPTION WS P/N SRC-8 DIGITAL INPUT CARD "008454" ADC-4 ANALOG INPUT CARD "008455" DO-8 DIGITAL OUTPUT CARD "008456" AO-4 ANALOG OUTPUT CARD "008457" PR-32 CARD MAIN PROCESSOR LOADED CARD "008453"...
