  • Page 1 DIGITAL TO ANALOG BROADCAST DIGITAL TO ANALOG BROADCAST CONVERTER WITH REMOTE CONTROL CONVERTER WITH REMOTE CONTROL Owner's Manual PLEASE READ BEFORE OPERATING THIS EQUIPMENT. Model: CVD508 Size: 148.5(W) x 210(H)mm (A5)

  • Page 2: Fcc Notice

    FCC NOTICE: To assure continued compliance, follow the attached installation instructions and use only shielded cables when connecting to other d e v i c e s . M o d i f i c a t i o n s n o t authorized by the manufacturer m a y v o i d u s e r ` s a u t h o r i t y t o operate this...
  • Page 3 outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
  • Page 4 following: the power-supply cord or...

  • Page 5: Location Of Control

    LOCATION OF CONTROL Front View Rear View ( Power ) Button 2. POWER/STANDBY Indicator 3. CHANNEL Buttons 4. Remote Sensor 5. RF IN Jack 6. RF OUT Jack 7. VIDEO OUT Jack 8. AUDIO OUT Jacks 9. DC IN Jack ( DC 5V, 2A...

  • Page 6: Remote Control

    REMOTE CONTROL ( Power ) Button 2. EPG ( Electronic Program Guide ) Button 3. 0-9 Numeric Buttons 4. - ( Dash ) Button 5. AUDIO Button 6. SIGNAL Button 7. CH/ ( Channel/Direction Up ) Button 8. V-/ ( Volume Down/Direction Left Button ) 9.

  • Page 7: Effective Distance Of The Remote Control Transmitter

    EFFECTIVE DISTANCE OF THE REMOTE CONTROL TRANSMITTER Approx. 16 Feet NOTE: ~ When there is an obstacle between the unit and the transmitter, the transmitter may not operate. ~ When direct sunlight, an incandescent lamp, fluorescent lamp or any other strong light shines on the remote control of the unit, the remote operation may be unstable.
  • Page 8 CONNECTING THE CONVERTER BOX TO YOUR TV WITH RF JACK To Antenna Jack on external Television To AC Wall Outlet From RF Out Jack on the rear of unit. To RF In Jack on the rear of unit. To DC IN Jack on the rear of unit. From Antenna 1.
  • Page 9 CONNECTING THE CONVERTER BOX TO YOUR TV WITH AV JACKS To DC In jack on the rear of unit. To RF Jack on the rear of unit. From Antenna To AC Wall Outlet 1. Connect your existing antenna cable to the RF IN Jack of the converter box. 2.
  • Page 10 CONNECTING THE CONVERTER BOX TO YOUR VCR To Antenna Jack on the TV. From RF Out Jack on the VCR. To RF In Jack on the VCR. From RF Out of the unit. To DC In jack on the rear of unit. To the RF In Jack on the unit.

  • Page 11: Basic Operation

    Press the Direction button to select and highlight the function you need to set. Press the Direction button to set. When finished, press the OK button to confirm the settings and exit. 1. OSD Language: To select and set the On Screen Display language. 2.
  • Page 12 Program: If Program is selected, the follows screen will appear: 1. If program Edit is selected, use the Direction and OK buttons to Move, Skip, Lock, Delete or Rename the programs as the on screen instructions. (Note: Password is needed to enter.The default password is "000000"). 2.
  • Page 13 Channel Search If Picture is selected, the follows screen will appear: 1. If Auto Search is selected, press the Direction ► button to auto search and stored the available TV stations. 2. If Manual Search is selected, use the Direction and OK buttons to search and stored the available station one by one as the on screen instructions manually.
  • Page 14 1. If Country Region is selected, use the Direction and OK button to select and set the region you are. 2. If Sleep is selected, use the Direction and OK button to activate and set the sleep timer as desire. After settings, the TV will turn off as the sleep timer settings.
  • Page 15 SYSTEM If System is selected, the follows screen will appear: 1. If Parental Guidance is selected, use the Direction and OK button to select and set the rating level as on screen instructions. (Password is needed to enter; the default password is “000000”). 2.
  • Page 16 (The default setting of the RF Output is CH3). Make sure you have correctly selected the audio settings. ~ If no TV signal received over half hour, the TV will turn off automatically to saving energy. Press the (Power) button to turn it on again. ~ Auto Power off timer was set, Press the (Power) button to turn it on.

  • Page 17: General Specifications

    GENERAL SPECIFICATIONS Power Source: 5V, 2A RF Freq. Range: 57MHz-803MHz RF Channel Range: CH1-CH135 Input: ATSC and NTSC ACCESSORIES ( Input: AC 100-240V~, 50/60 Hz; Ouput: DC 5V, 2A ) x AV Connection Cable in RCA type x RF Cable...

  • Page 18: Limited Warranty
