CamTron CTNC-5353H Instruction Manual

Ip camera cywatch
Hide thumbs Also See for CTNC-5353H:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Enlarged version
The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards:
◆ Do NOT use power sources other than those specified.
◆ Do NOT expose this appliance to rain or moisture.
This installation should be made by a qualified service person and
should conform to all local codes.
1
H.264 IP Camera Cywatch

Advertisement

Table of Contents
loading

Related Manuals for CamTron CTNC-5353H

Summary of Contents for CamTron CTNC-5353H

  • Page 1 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

  • Page 2: Table Of Contents

    ■ Contents Features How to Use the Camera ■ Function Menu Structure Precautions ■ How to Set up the Functions ㆍLENS Components ㆍSHUTTER Names and Functions of Parts ㆍWHITE BALANCE ■ Front View ㆍBLC (Back Light Compensation) ■ Bottom View ㆍAGC (Automatic Gain Control) ■...

  • Page 3: Features

    Do not use the camera close to a gas or oil leak. Audio It may result in a fire or other hazards. Multi-transmission mode: Uni-direction (CTNC-5353H -> PRIVACY Function Client PC or Decoder, Client PC or Decoder -> The PRIVACY function conceals the areas not CTNC-5353H), Bi-direction required to appear on the image.

  • Page 4: Precautions

    ■ Precautions Do not drop the camera and protect Never keep the camera pointed Do not install the camera in Do not install or use the camera in an it from physical shocks. directly at strong light. extreme temperature conditions. environment where the humidity is high.

  • Page 5: Components

    ■ Components Names and Functions of Parts ■ Front ① ② ③ 1. COLOR BOX CAMERA 2. AUTO IRIS LENS CONNECTION PLUG 3. L-WRENCH Lens protection cap ① Cover the lens when not using it. CS-Mount lens adaptor ② 4. C-MOUNT ADAPTOR Attach the CS-Mount lens here.

  • Page 7: Installation

    ■ Installation Installation ■ 3. Remove the cover of the auto iris lens connection plug and solder the ■ Lens lens cable to the connector pin in the plug. Lenses are sold separately. Lenses such as auto iris lens, CS-Mount lens LENS and C-Mount lens can be used.

  • Page 8: Connecting To A Monitor

    ■ Installation ■ Connecting to a monitor When using a CS-Mount lens Take off the lens protection cap and attach Connect the video output terminal located on the back of the camera to the CS-Mount lens to the camera by screwing it in the monitor.

  • Page 9: How To Use The Camera

    ■ How to Use the Camera Function Menu Structure How to Set up the Functions 1. Settings for analog part of the camera can be configured. Camera-specific menu is displayed using OSD on video display, and this menu can be SETUP menu operated with 5 buttons on the page.
  • Page 10 ■ How to Use the Camera ● DC/Video : Select Auto Iris Lens 3. Set up a selected item by using the Left and Right buttons. • When DC is selected, you can control screen brightness. The range 4. To finish the setting, select 'EXIT' and press the SET button. of brightness control is between 1 and 70 (40 in case of WDR mode).

  • Page 11: ㆍWhite Balance

    ■ How to Use the Camera SHUTTER (condition and speed control) WHITE BALANCE The screen colours can be adjusted using the WHITE BALANCE function. Auto or manual control can be selected. 1. Position the cursor to point to 'WHITE BAL' on the SETUP menu by using the 1.

  • Page 12: ㆍBlc (Back Light Compensation)

    ■ How to Use the Camera BLC (Back Light Compensation) AGC (Automatic Gain Control) When there is a strong backlight behind the object, clear images of the 1. Position the cursor to point to 'AGC' on the SETUP menu by using the background as well as the object can still be obtained by using the UP and DOWN buttons.

  • Page 13: ㆍDnr (Digital Noise Reduction)

    ■ How to Use the Camera DNR (Digital Noise Reduction) 1. Position the arrow to point to 'SENS UP' on the SETUP menu by using The level of background noise in low light decreases automatically as the the UP and DOWN buttons. level of gain changes.
  • Page 14 ■ How to Use the Camera CAM ID SPECIAL 1. Position the cursor to point to 'SPECIAL' on the SETUP menu by using OSD settings of this camera can be remote controlled by RS-485 communication. the UP and DOWN buttons. - Protocol : Exclusive Protoclo 2.
  • Page 15 ■ How to Use the Camera 3) Press the SET button. 5) When the camera TITLE is complete, select a position for the name to be displayed. ① Move the cursor onto 'POS' and then press the SET button. 4) Up to 15 characters can be used for the camera TITLE. ①...
  • Page 16 ■ How to Use the Camera ● COLOR ● Two sychronisation modes are available, INTERNAL and SYNC : EXTERNAL LINE-LOCK. In LINE-LOCK mode, it synchronises the - AUTO : This camera has an IR Cut Filter and automatically changes video signal between cameras without a synchronous generator. to the appropriate mode dependant on lighting levels.
  • Page 17 ■ How to Use the Camera ● MOTION DETECTION: ㆍPlease select the area you do not wish to appear from the 4 areas in This product has a feature that allows you to observe movements of objects AREA SEL mode. in 4 different areas on the screen, and the words 'MOTION DETECTED' ㆍPlease select ON mode for the chosen area.

  • Page 18: Troubleshooting

    ■ Troubleshooting Specification ■ If there are problems with the camera operation, check the tables below. If the problem persists, please contact the agent who supplied the product. NETWORK Interface Ethernet 10/100 Base-T Problems Troubleshooting Connector RJ-45 Nothing appears on the ㆍCheck the power connection.

  • Page 19: Specifications

    ■ Specification CAMERA Effective Pixels 380K(NTSC), 440K(PAL) Resolution 540TVL Min. Illumination Color - 0.3Lux, B/W - 0.002Lux (Sense-up) at F1.2 Shutter Speeds 1/60(N) or 1/50(P) ~ 1/120,000sec. S/N Ratio More than 50dB (AGC off) OSD Functions Main Mode Lens (Manual, DC/Video) , Shutter, White Balance, BLC, AGC, DNR, Sense-Up (Auto 2X~128X,Off) Special Mode Camera ID, Color(On, Auto), SYNC, Sharpness(0~31),...

  • Page 20: Ip Camera Cywatch

    H.264 IP Camera Cywatch Instruction Guide H.264 IP Camera Cywatch Printed in KOREA...
