OWNER'S MANUAL
Model MH1100-01
Monster Wagon
Read, understand and follow ALL instructions before using this product
RMM Corporation
7677 Equitable Drive
Minneapolis, MN 55344
800-304-1316
www.black-cat-products.com
• Warning: Not for recreational use -
persons should never ride in cart
• Warning: Do not tow cart in excess
of 15 mph - never tow behind car
or truck
• Warning: Not for high speed or
highway use
CAUTION:
REV 3/05
Advertisement
Table of Contents
Related Manuals for Black cat MH1100-1
Summary of Contents for Black cat MH1100-1
- Page 1 OWNER’S MANUAL Model MH1100-01 • Warning: Not for recreational use - persons should never ride in cart • Warning: Do not tow cart in excess of 15 mph - never tow behind car or truck • Warning: Not for high speed or highway use Monster Wagon CAUTION:...
-
Page 2: Base
IMPORTANT SAFETY INSTRUCTIONS 1. READ ALL INSTRUCTIONS CAREFULLY BEFORE USE. If you do not understand these instructions, need clarification or further explanation, please call our toll free answer line for assistance at 1-800-304-1316 Monday through Friday 8:00 a.m. until 5:00 p.m. CST. 2. - Page 3 STEP 4 Lay the Lower Frame Assembly on top of the Straight and Angled Support Brackets positioned in the previous 2 steps. Align all of the holes between the Lower Frame Assembly and the Bed. Once all of the holes are aligned, connect the Lower Frame Assembly to the Bed using the (8) 10 x 60mm bolts, 10 mm washers, and 10 mm lock nuts (finger tighten only).
-
Page 4: Side Panel Brackets
STEP 8 Attach the (2) Side Panel Brackets to the Base using (2) 8 x 20mm bolts, 8 mm washers, and 8 mm lock nuts. The circular tube at the top of the Bracket should face the inside of the wagon. STEP 9 Assemble the four Side Panels by inserting the stakes on the Panels into the brackets on the... -
Page 5: Table Of Contents
EXPLODED DRAWING FOR ASSEMBLY MAIN FRAME PARTS Straight Support Brackets(Center) – (4) Base – (1) Angled Support Brackets (Right) – (2) Side Panels – (2) Angled Support Brackets (Left) – (2) Side Panels – (2) (10) 16” Wheels – (4) Front Panel –... -
Page 6: Angled Support Brackets (Right)
PARTS AND HARDWARE IDENTIFICATION ASSEMBLY HARDWARE (13) Bolts 10 x 20mm – (4) pre-assembled to angled support brackets (14) Bolts 10 x 35mm – (4) for straight support brackets (15) Bolts 10 x 60mm – (8) for straight and angled support brackets (16) Bolts 8 x 20mm –... -
Page 7: Trailer Hitch
PARTS AND HARDWARE IDENTIFICATION (24) Fence Assembly Pins – (2) Used on the front and rear fence assembly (25) Washers 12mm – (2) 1 for installing pull handle, 1 is pre- assembled to lower frame assembly (26) Washers 20mm – (6) 4 used on wheels, 2 pre-assembled to lower frame assembly (27) Pins 100mm –...
