INSTRUCTION MANUAL
PRODUCT TYPE
DIGITAL SCREWDRIVER

DEAR USER

Thank you for purchasing this digital screwdriver.
This manual will help you use the many features of
your new digital screwdriver.
Before operating the screwdriver, please read this
manual completely, and keep it nearby for future
reference.
MAIN FEATURES
Digital torque value readout.
■
+/- 2.5% or 3% accuracy.
■
CW and CCW operation.
■
Peak and hold track mode selectable.
■
Buzzer and LED indicator for the 9 pre-settable
■
target torques.
Engineering units (cNm, in-lb, kg-cm)
■
selectable.
50 data memories for recall and joint torque
■
auditing.
Auto Power Off after about 5 minutes idle.
■
Rechargeable batteries are compatible.
■
MODEL
7514-0050
7514-0200
7514-0400

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7514-0050 and is the answer not in the manual?

Questions and answers

Summary of Contents for Polar Electro 7514-0050

  • Page 1 INSTRUCTION MANUAL PRODUCT TYPE MODEL DIGITAL SCREWDRIVER 7514-0050 7514-0200 7514-0400 MAIN FEATURES Digital torque value readout. ■ +/- 2.5% or 3% accuracy. ■ DEAR USER CW and CCW operation. ■ Thank you for purchasing this digital screwdriver. Peak and hold track mode selectable.
  • Page 2 NAMES AND FUNCTIONS OF PARTS MODEL 7514-0050 Communication port LCD readout Anti-slip handle Autolock bit holder Torque value Buttons Units Battery cover Memory number LED indicator Buzzer Peak/Track mode Calibration mark MODEL 7514-0200 7514-0400 Communication port LCD readout Anti-slip handle...

  • Page 3: Specifications

    (1 year). ALL MODELS *2: Use a special designed cable (accessory) to upload record data to PC. 7514-0050: CW: ±3% CCW: ±4% Accuracy *1 7514-0200: CW: ±2.5% CCW: ±3.5% *3: One AAA batteries (Toshiba carbon-zinc 7514-0400: CW: ±2.5% CCW: ±3.5%...
  • Page 4 2. The maximum capacity for “Pre-setting no.” loosen the battery cap then tighten it to re-start. is 9 sets. 3. The “Pre-setting no.” is cyclic. SETUP 2. Unit selection MODEL 7514-0050 Power on/clear Pre-setting no. Pre-setting unit: cNm Press Unit selection/setting Adjust torque value...
  • Page 5 TRACK MODE OPERATION 3. Set target torque START Pre-setting torque value (System initial) Press *Note 1 Increase torque value Setting target torque Press Apply torque Decrease torque value Current torque value Note: Reach 90% of target torque The “Unit selection” is cyclic. 4.
  • Page 6 PEAK HOLD MODE OPERATION PEAK HOLD MODE RECORDED VALUE REVIEW START *Note 1 (System indicate) *Note 1 Peak hold/track mode Long press Setting target torque *Note 2 *Note 2 Recording Apply torque Set peak/track mode Released Press Apply torque Flashing Current max.
  • Page 7 COMMUNICATION MAINTENANCE AND STORAGE Precaution: Attention! 1. Communication function is only supported One-year periodic recalibration is necessary to maintain on some models. Check the model no. and accuracy. Please contact your local dealer for calibrations. its specification before using communication function.
  • Page 8 POLAR TOOLS A/S SOLDALEN 9 . 7100 VEJLE . DENMARK . INFO@POLARTOOLS.COM . WWW.POLARTOOLS.COM...
