Atlas PS24-2R Installation Instructions

REGULATED DC POWER SUPPLY
MODEL PS24-2R
PARTS LIST
REF DESCRIPTION
CB1 Circuit Breaker 1 AMP
L1 Pilot Lamp 117 VAC
T1 Transformer
D1, D2 Diode 10 AMP 50 V
C1, C2 Capacitor 4700 MF 50 V
F1 Fuse, AGC2
– PC Board Assembly
Q1 Transitor 2N3053
Q2 Transitor 2N3055
U1 Regulator LM723
D3 Zener Diode 36 V
C4 Capcitor 100 PF Dsic
C5 Capcitor 100 MF 35 V
R1 Resistor 220 ohm 1/2 Watt 186561
R2 Resistor 330 ohm 1/2 Watt 110795
R3 Resistor .12 ohm 5 Watt
R4 Trimpot 5K
R5 Resistor 4.7K 1/2 Watt
R6 Resistor 1.5K 1/2 Watt
MODEL INPUT OUTPUT
(NOMINAL)
PS24-2R 105-125 VAC
60 Hz, 110 W
Size (L x W x H):
19" x 8" x 5 1 ⁄
4
(483 x 203 x 133 )
mm mm mm
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. •
©2002 ATLAS SOUND LP
PART NO.
263562
113209
275577
111104
253715
111236
275675
111031
111023
275577
257667
110353
188401
275589
244370
110485
(Front View)
110515
RIPPLE @
FULL LOAD
24 VDC .5m
2 AMPS
RACK MOUNT ACCESSORY SHELF (MODEL PS-RK)
• Plug provided for viewing hole
when not mounting 13
Specifications are subject to change without notice
Printed in U.S.A.

INSTALLATION INSTRUCTIONS

REGULATION PILOT
0 – FULL LOAD LAMP
500mV X
1 ⁄ " L chassis
4
AtlasSound.com
TELEPHONE: (800) 876-3332 • FAX: (800) 765-3435
00402
(Rear View)
SIZE
FUSE L x W x H
Primary 13 1 ⁄ " x 6 1 ⁄ 4 " x 4 3
4
Secondary 337 x 159 x 121
mm mm
• Holds up to (4) 6 3 ⁄ " L chassis or
4
(1) 13 1 ⁄ " L chassis
4
ATS001212 Rev A 04/02
WEIGHT
⁄ " 15.5lbs.
4
mm
PN 263856
