Status Display - Logitech QuickCam Setup

3

Status Display

1. Camera modes
• Picture mode. Takes a single picture.
• Video mode. Captures video.
2. Power save
• Enable (on by default)
• Disable (when AC adapter is connected)
3. Channel indicator (Select a channel, 1 through 4.)
4. Battery level indicator
4
Selecting Camera Functions
1. Press the Mode button to choose camera function.
2. Camera function flashes when selected.
3. Press Select button to choose function.
4. Use Select button to select choices within function (e.g., Channel indicator, channels 1
through 4, or Power save, on or off).
4
English
1
2
3
4
