  • Page 1 USER MANUAL...

  • Page 2: Table Of Contents

    CONTENTS: INTRODUCTION AND SETTING UP SPECIFICATIONS AND PARTS LISTING PARTS DESCRIPTION OPERATING WIRELESS DEVICES - WIRELESS MODULE DESCRIPTION - WIRELESS MICROPHONE MAIN CONTROLS - PANEL DESCRIPTION GENERAL USAGE: 6 - 7 - TURNING ON - ATTACHING AN MP3 DEVICE - CHARGING THE UNIT - WIRELESS MIC PRIORITY - LINE IN/LINE OUT - CHANGING THE BATTERIES...

  • Page 3: Introduction And Setting Up

    INTRODUCTION: Ashton is designed in Australia by a team of industry experts that have years of experience in the development, design and production of musical instruments and equipment. Ashton’s range of instruments are a result of years of development and careful testing. Every Ashton product is designed with value in mind and features the highest quality materials available.

  • Page 4: Specifications And Parts Listing

    SPECIFICATIONS: RECEIVER SPECIFICATIONS: GENERAL SPECIFICATIONS: FREQ. RANGE SPEAKER 8” Full range at 4ohm UHF 600 - 960Mhz STABILITY ± 0.005% RECEIVER UHF PLL 16-channel true- MODULE diversity single receiver DYNAMIC RANGE ± 40KHz w/level limiting circuit FREQ. BAND UHF 600 - 960 MHz S/N RATIO >110dB (801 - 825 MHz)

  • Page 5: Parts Description

    PARTS DESCRIPTION: A. CARRY HANDLE B. WIRELESS RECEIVER MODULE: Turn to page 4 for panel description. C/ D: MAIN CONTROL PANELS: Turn to page 5 for panel descriptions. E. AC POWER INPUT F. POWER SWITCH: Switch to turn power to unit ON and OFF. G.

  • Page 6: Operating Wireless Devices

    OPERATING WIRELESS DEVICES WIRELESS MODULE DESCRIPTION: A. RF SIGNAL INDICATOR: Lights up when wireless RF signal is received. B. LED DISPLAY: Displays selected channel, to change use D. C: AF SIGNAL INDICATOR: Lights up when microphone audio signal is received. D: CHANNEL SELECTOR KNOB: Turn to set wireless channel (up to 16).

  • Page 7: Main Controls

    MAIN CONTROLS PANEL DESCRIPTIONS: A. LINE OUT JACK: Attach to output sound to an external device. B. ECHO LEVEL KNOB: Controls the level of echo (delay) on both the wireless & wired mics. C: LINE IN VOLUME KNOB: Volume control for external audio input. D: MIC 1/2 VOLUME KNOB: Volume control for wired microphone (see F).

  • Page 8: General Usage

    Note: Most MP3 players have a 1/8” jack connection, you will need to purchase an RCA to 1/8” adaptor lead (Ashton RCA28S). These can also be found at most music or hi-fi stores. CHARGING THE UNIT: When the unit is plugged into your mains power outlet, the unit automatically charges.

  • Page 9: Line In/Line Out

    GENERAL USAGE LINE OUT: This output can be used to link the device to a mixing or recording desk. It can also be used to link a second Transporta Lite unit (line out to line in), for applications where higher volume levels are required.

  • Page 10: Safety Information

    SAFETY INFORMATION: INSTRUCTIONS RELATING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS. WARNING! When using any electronic product, basic precautions should always be followed, including the following: Read all the safety and installation instructions and explanations of graphic symbols and set-up/controls before using the products.
