- Page 1 SATURN 17LS3-SS, 17LS3-BK 20LS3-SS, 20LS3-BK 20DS3-SS 17LS4-Bk, 20LS4-BK LOW SPEED AND DUAL SPEED FLOOR MACHINE OWNER’S/OPERATOR’S MANUAL WWW.EDIC-USA.COM...
- Page 2 Do not operate the machine unless trained and au- cartons carefully for signs of rough handling. If the thorized. SATURN is damaged, notify the carrier immediately • Do not leave the machine unattended when plugged and request an inspection. Be sure to keep the cartons, in.
-
Page 3: Grounding Instructions
Servicing: formed by an EDIC authorized service center. • Keep hair, loose clothing, fingers and all parts of In the event that your SATURN requires service, please body away from openings and moving parts. contact EDIC at: • Use extra care when cleaning near stairs. -
Page 4: Pad Installation
TO REMOVE PAD DRIVER: ning. Always wait until motor has stopped completely Tip the machine back so it rests on the before changing speeds. handle and wheels. Turn the brush or pad driver clockwise until it disengages and lifts off. Do not store Storage: the machine with the brush or pad drivers installed. - Page 5 NOTES...
-
Page 6: Low Speed
LOW SPEED WIRING... - Page 8 20DS3-SS 10-9-07...
- Page 9 QTY. B11487 Power Cord, 14-3, 50 FT, SJTW K11498 Grip C11528 Screw, 10-32 X .25 in H12066 Label, 0.5 HP, Saturn H11831 Label, EDIC, Black-Silver D11496B Switch Box Cover, Black H11493 Label, Safety, Floor Machine C11529 Screw, 10-32 X .375 in...
- Page 10 10 11 12 17LS3-BK 10-19-07...
- Page 11 QTY. B11487 Power Cord, 14-3, 50 FT, SJTW K11498 Grip C11528 Screw, 10-32 X .25 in H12066 Label, 1.5 HP, Saturn H11831 Label, EDIC, Black-Silver D11496B Switch Box Cover, Black H11493 Label, Safety, Floor Machine C11529 Screw, 10-32 X .375 in...
- Page 12 10 11 12 13 14 17 18 17LS3-SS 10-30-07...
- Page 13 QTY. B11487 Power Cord, 14-3, 50 FT, SJTW K11498 Grip C11528 Screw, 10-32 X .25 in H12066 Label, 1.5 HP, Saturn H11831 Label, EDIC, Black-Silver D11496B Switch Box Cover, Black H11493 Label, Safety, Floor Machine C11529 Screw, 10-32 X .375 in...
- Page 14 58 57 56 20LS3-BK 10-20-07...
- Page 15 34 D11482 Handle Brace, Right, Black 35 C00240 Washer, Shoulder, Nylon 36 C11559 Washer, .515 X .875 X .032 37 G11943 Wheel, 5 in Saturn 38 C02305 Cap Nut, .5in Push-on 39 C11501 Socket Cap Screw, .31 - 18 40 C00251 Lockwasher, .31, Split...
- Page 16 58 57 56 20LS3-SS 10-20-07...
- Page 17 34 D11482 Handle Brace, Right, Black 35 C00240 Washer, Shoulder, Nylon 36 C11559 Washer, .515 X .875 X .032 37 G11943 Wheel, 5 in Saturn 38 C02305 Cap Nut, .5in Push-on 39 C11501 Socket Cap Screw, .31 - 18 40 C00251 Lockwasher, .31, Split...
- Page 18 17LS4-BK...
- Page 19 17LS4-BK...
- Page 20 17LS4-BK...
- Page 21 17LS4-BK...
