Philips HP6516/00 Service Manual

Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
General
Epilator for Wet and Dry application
Safety
• This product meets the requirements regarding interference
suppression on radio and TV.
• After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
Watertight housing concept
On/off button (push button)
Switching sequence
Operation Modes
Charging Time
Run Time
Charging indication
Shelf Lite Time battery
Battery concept
Published by Philips Consumer Lifestyle
13/01
HP6516 HP6519
HP6520
Tubular body housing (3k(soft-touch) + 1k)
Front panel: Layer 1 colored bases material, Layer 2 transparent colored front panel,
Layer 3 rubber (SEBS) for switch seal, + 1k tubular housing
Click on switch holder and crystal lenses onto in molded switch plate on housing
OFF ON (speed 2) ON (speed 1) OFF
Charging Mode, OFF Mode (battery full), Motor Mode
1 h quick charge
Up to 30 minutes for standard epilation
Dual color LED (white, red)
Charging indication and Battery full indication (white)
Battery low and overload indication (red)
12 months
Li-Ion cell technology
Printed in the Netherlands
HP6521 HP6522
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
• No specific issues.
REPAIR INSTRUCTION
• For this Epilator only the parts shown in the exploded view will
be supplied.
OPTIONAL (accessories)
• No specific issues.
© Copyright reserved
Epilator
HP6516/00
HP6519/01
HP6520/01
HP6520/50
HP6521/01
HP6521/30
HP6522/01
Version A
Subject to modification
