Summary of Contents for Eldes EWF1
- Page 1 EWF1 WIRELESS SMOKE DETECTOR EWF1CO WIRELESS SMOKE & CO DETECTOR USER GUIDE V2.0 COMPLIES WITH EN 14 604 2005...
- Page 2 (CO) inalámbrico combinado con el detector de humo. En caso de que se produzca la detección del aumento de humo o monóxido de carbo- no, EWF1/EWF1CO indicará la alarma y no i icará al sistema ELDES sobre el evento.
- Page 4 EN | FR | ES | PT EWF1-EWF1CO...
- Page 5 +5°C(41°F) +5°C(41°F) 0,9m 0,9m (2.95 t) (2.95 t) +45°C (113°F) +45°C (113°F) +5°C(41°F)
- Page 7 PRESSER PENDANT 2 SEC. PRESIONE DURANTE 2 SEG. PRESSIONE POR 2 SEG. 3 MIN. WAIT FOR 3 MIN. ELDES ATTENDRE 3 Con igura ion ESPERE POR 3 MIN. Tool AGUARDE 3 MIN. EWF1-EWF1CO EN | FR | ES | PT...
- Page 8 3. Place a detector in each room that is divided by a par ial wall. For best protec ion we recommend that you install a detector in every room. DO NOT place EWF1/EWF1CO in the following loca ions: • Near appliances or areas where normal combus ion regularly occurs (kitchens, near furnaces, hot water heaters).
- Page 9 • Get immediate medical assistance for anyone su fering the e fects of carbon mon- oxide poisoning (nausea, headache), and report that carbon monoxide inhala ion is suspected. Contact the gas or other fuel supplier on their emergency phone number in order to iden ify and eliminate the source of carbon monoxide emissions. EWF1-EWF1CO...
- Page 10 4) has been reached and decreased to 30-49ppm a terwards. Also, data messages no ifying about CO cri ical level 1 and gas fault detec ion are delivered to ELDES Cloud Services and added to both Event Log and Fault Log respec ively.
- Page 11 This level causes no zone alarm when reached. Also, data messages no ifying about CO cri ical level 3 and gas fault detec ion are delivered to ELDES Cloud Services and added to both Event Log and Fault Log respec ively.
-
Page 12: Maintenance
• DO NOT use an open lame to test this detector. You may ignite and damage the detector or your home. • If the detector does not sound, please check the ba tery and signal level using ELDES Con igu- ra ion Tool so tware. -
Page 13: Battery Replacement
EWF1/EWF1CO devices will con inue to sound in accordance with the set ime period (by default - 30 seconds) that can be managed by ELDES Con igura ion Tool so tware. Interconnec ion will commence when CO cri ical level 4 has been reached (see 2.2. CO Alarm/Restore and Fault Indica ions). - Page 14 The ba tery status can be monitored in real- ime using ELDES Con igura ion Tool so tware. The system sends an SMS message to the listed user phone number as soon as the ba tery level runs below 5%.
-
Page 15: Temperature Sensor
The device comes equipped with a built-in temperature sensor allowing to monitor the temperature of the area surrounding EWF1/EWF1CO device. When using the with EPIR3 alarm system, you may set the MIN and MAX temperature thresholds ranging from +5°C to +45°C resul ing in SMS text mes- sage delivery to the listed user phone number once exceeded. -
Page 16: Technical Specifications
See 4.2. Interconnec ion. ESIM264, EPIR2 and EPIR3 alarm systems support up to 16 EWF1 devices, while ESIM364 - up to 32 EWF1 devices. Up to 16 EWF1CO can be connected to EPIR3 alarm system, while ESIM364 supports up to 32 EWF1CO devices. - Page 17 The opera ion ime might vary in di ferent condi ions. Technical support If you experience di iculty during the installa ion or subsequent use of a ELDES UAB system, you may con- tact ELDES UAB distributor or dealer in your country/region.
- Page 19 Made in the European Union www.eldes.lt...
