Summary of Contents for MegaCell MBF-GG60 BiSoN Series
- Page 1 SAFETY AND INSTALLATION MANUAL BIFACIAL SOLAR MODULES Document name: MCELL_PV_Modules_Installation_Manual_EN_v1.2_20150715 Revision date: V1.2 July 2015 www.megacell.it...
-
Page 3: Table Of Contents
Installation guide solar modules MODULES MBF-GG60 BiSoN series – with frame ....................5 MBA-GG60 BiSoN series – frameless ....................5 INTRODUCTION ..........................6 Disclaimer of liability ......................... 6 IEC 61215 & 61730 certifications ...................... 6 Limited Warranty ..........................6 Module specification ......................... 7 Product identification ........................ - Page 4 Installation guide solar modules V1 – April 2015 4 - 19...
-
Page 5: Modules
Installation guide solar modules 1. MODULES MBF-GG60 BiSoN series – with frame MBA-GG60 BiSoN series – frameless V1 – April 2015 5 - 19... -
Page 6: Introduction
MegaCell does not assume responsibility and expressly disclaims liability, for loss, damage or expense resulting from improper installation, handling or use. The information in this manual is based on MegaCell’s knowledge and experience and it is believed to be reliable. Nevertheless, such information including product specification (without limitations) and suggestions do not constitute a warranty, expressed or implied. -
Page 7: Module Specification
Installation guide solar modules Module specification Please refer to the appropriate MegaCell MBF or MBA datasheet for electrical performance data and mechanical installation information. Product identification Each module can be identified by means of the following embedded information: Nameplate: it is located on the reverse side of the module or on the frame. It gives information about the main... -
Page 8: Warning: Extreme Danger Due To Electrical Shock
FRONT plus REAR surface with cloth, cardboard, or other completely opaque non-marking material, or by working with them face down on a smooth, flat surface. IMPORTANT : MegaCell bifacial modules produce voltage when exposed to light also on back side o Do not expose the modules to artificially concentrated sunlight o Do not stand on, drop, scratch, or allow objects to fall on the modules. -
Page 9: Warning: Danger Due To High Voltage
Installation guide solar modules Warning: Danger due to high voltage Even in disconnected condition the inverter can retain high voltages, which is a major shock hazard. Therefore: • Be very cautious when working with the inverter and wires. • After switching off the inverter as well as before working on the inverter, make sure to regulate the time intervals as recommended by the manufacturer so that the high voltage components can be discharged Make sure to adhere to the assembly regulations of the inverter manufacturer. -
Page 10: Installing The Module
Installation guide solar modules Installing the module Make sure that the installation is carried out safely. Protect yourself and other persons from falling, do not carry out the installation in heavy winds and eliminate the risk of falling objects as much as possible. Secure the work area in order to avoid the endangerment or injury of persons. -
Page 11: Install The Module In An Area Free Of Shade
Under the terms of MegaCell, grounding of the module frame (if present) is not required for fault-free operation. To reduce the risk of electric shock (e.g. due to static charge) as far as possible, MegaCell recommends to ask an experienced installer to carry out a proper grounding. If an external lightning protection system has been already installed, the PV system has to be integrated in the existing lightning protection concept by a specialist. - Page 12 Installation guide solar modules Mounting of grounding terminal on frame The grounding terminal must be placed on the frame in such a way that the screw touches the grounding hole. Using a screwdriver, install the screw into the grounding hole until its head is flush with the base and the base is flush with the frame.
-
Page 13: Ensure Comprehensive Fire Protection
MegaCell PV modules are suitable for mechanical mounting both in portrait and landscape orientation. In choosing the orientation, please keep in mind the internal PV module by-pass diode configuration to ensure the optimum electrical behavior from any potential shading over the modules. -
Page 14: Frameless Modules
Newton meter [Nm], but refer to the clamp manufacturer for specific hardware and torque requirements. For a safe and effective installation of MegaCell framed modules, the lengths for the pressure clamps are strongly recommended is not less than 50 mm for 60 - 156 x 156 mm cell modules. -
Page 15: Clamping Areas And Maximum Load Applicable
(more than 120 V DC in accordance with EN 61730) and power. PV modules of this application class are approved for operation in installations with unrestricted access. BiSon series modules from MegaCell, which are qualified under EN 61730 and have been properly installed, meet the requirements of protection class II. -
Page 16: Electrical Connections
Installation guide solar modules Electrical Connections Never open the connection box! The modules are already fitted with all necessary wires and connectors. CAUTION: System design should consider the potential increased power output (Pmax) and current (Isc) due to the modules bifacial abilities. Additional power and currents beyond the STC rating are possible. See the Electrical Specifications on the data sheet for electrical parameters in presence of albedo. -
Page 17: Protect The Wires From Adverse Environmental Effects
PV module output 7. MAINTENANCE OF MODULES MegaCell recommends to inspect the installation on a regular basis with following minimum maintenance: o Check the electrical and mechanical connections to verify that they are clean, secure and undamaged;... -
Page 18: Cleaning Modules
LIABILITY AND REVISION LEVEL OF THE INSTRUCTIONS If any of the instructions given in the user information are not adhered to, MegaCell will not guarantee the availability and functionality of the modules. Since the compliance with the said safety instructions as well... - Page 19 To download a copy of this installation manual scan the QR-Code below or go to: www.megacell.it MegaCell S.r.l. a socio unico A coordinated company part of Mega Group S.r.l. Registered office: Via Postumia, 9/B 35010 Carmignano di Brenta (PD) - IT Share capital fully paid: 500.000 euro VAT number &...
