Summary of Contents for eQ-3 PS 50
- Page 1 Wireless Pool Thermometer PS 50 Operating Manual...
- Page 2 English edition 02/2010 Documentation © 2007 eQ-3 Ltd, Hongkong All rights reserved. This handbook must not be reproduced in any form, even in ex- cerpts, or duplicated or processed using electronic, mechanical or chemical proce- dures without written permission of the publisher.
-
Page 3: Table Of Contents
Content General information and function ..........4 Indended usage ................4 Safety instructions ................. 5 Battery and environment instructions ..........5 Preparing for operation ..............6 5.1. Open the housing ................6 5.2. Inserting batteries ................6 5.3. Setting address and measuring unit ..........8 Operation .................. -
Page 4: General Information And Function
(˚C) or degrees Fahrenheit (˚F). The thermometer indued with a transmitter for send the temperatur data to the wireless poolthermometer basic station PS 50. Also it is possible to receive the data with many weather stations. The following weather... -
Page 5: Safety Instructions
3. Safety Instructions We shall not assume any liability for damage to items or persons caused by improper handling or non-observance of the safety instructions! In such cases, any guarantee claims shall become null and void. - Do not use this product in hospitals or medical institutions. Although the outdoor sensor only emits relatively weak radio signals, these may cause interference to life-support systems. -
Page 6: Preparing For Operation
5. Preparing for operation 5.1. Open the housing - Rotate the unit and unscrew the 6 screws (see below) - Lift up the upper part carefully. 5.2. Inserting the batteries - The unit is operated with 3 x 1,5 V AA batteries. You should take alkaline batteries (LR6) for longer using and better safety against leaking. - Page 7 4. Insert and tighten all screws in a crossover pattern (see figure below) until you feel an increase in resistance 5. Double check the seal to insure proper fitting 6. Tighten first screw (1) one full turn 7. Tighten screw across from the first screw (2) one full turn 8.
-
Page 8: Setting Address And Measuring Unit
5.3. Setting address and measuring unit - If you have take the unit out of the lower part, you can see the DIP- Switch on the lower side of the electronic part (see below). - The DIP-Switches 1-3 are used for addressing, the switch 4 ist used for choosing the measuring unit. -
Page 9: Operation
6. Operation - Set the accurately closed unit on the water surface. - Wait some seconds, till the temperature display shows a stable value. The housing and the inner of the thermometer needs some time till they has the same temperatur as the water. Caution! - Do not pitch the unit into the water and use it not as a toy or sport equipment. -
Page 10: Maintenance
8. Maintenance 8.1. Changing the batteries - If the flat battery symbol appears in the display (Lo Bat) all batteries must be changed for ones of the same type Lo-Bat as described in Section 5.2 (p. 6). Always change all 3 batteries and use only high-quality alkaline cells. 8.2. -
Page 11: Technical Data
10. Technical Data Measurement range: ........32˚F to 158˚F (0˚C to 70˚C) Resolution: .................. 0.1˚F/˚C Accuracy: ................±1.8˚F/±1˚C Display updating: ..............every 5 sec. Data transmission interval: ...........about 3 min. Transmission frequency: ............868.35 MHz Free field range: ..............max. 300 ft. Voltage supply: .........3 x 1.5 V/AA battery (LR 6/Mignon) Battery service life: ..............2-3 years Dim.
