Summary of Contents for danburn Laesø 6kW
- Page 1 Operation and Installation Manual Laesø 6kW Mandø 5kW Rømø 5kW Samsø 5kW Jan 2016 Page 1 /16...
- Page 2 Samsø 5kW Laesø 6kW Mandø 5kW Rømø 5kW Page 2 /16...
- Page 3 This manual refers to the stoves listed above, which are tested in accordance with EN 13240. Please read this manual carefully to ensure that you get maximum enjoyment and performance from your new stove and to prevent any potential operational problems. Please note that “all local regulations, including those referring to national and European Standards, need to be complied with when installing this appliance”.
- Page 4 Use of excellent raw materials assures you will have a long-lasting pleasant experience. But it is important that you contribute to the care of your new DANBURN STOVE by carefully reading this manual and following the instructions. In spite of the finest quality materials and workmanship, false fitting or connecting, overloading of the appliance or use of an unsuitable fuel can cause damage to the appliance itself or to the connecting pipe and the chimney.
- Page 5 2. Stove – cross section drawing Primary air Secondary air ”Cold” air of room Warm air Escaping gases Hot gases Grate Vermiculite lining Tertiary air Tertiary air Ash Grate 3. Heating capacity The heating capacity according to DIN 18893 standard is in m³, referring to buildings that do not comply with the Heat Insulation Regulation.
- Page 6 In such cases, we recommend the use of a feed pressure regulator (flow control valve in the flue or providing secondary air inside the chimney). DANBURN stoves comply with DIN 18891 (building category 1) and DIN EN 13240 standards. These fireplaces are fitted with automatically closing doors. DANBURN stoves are freestanding appliances that cannot be equipped with an individual cover or be built in as a fire chamber insert/cassette.
- Page 7 (e.g. an extractor fan) If it is possible, a solution must be found for turning off these appliances. Use of DANBURN stoves in buildings with hermetic insulation and mechanical airing systems is NOT allowed unless a independent air supply is supplied.
- Page 8 The Flue diameter of flue outlet is 150 mm. All DANBURN appliances are sold setup as a top flue outlet. We recommend this connection mode because of combustion technological reasons. In case you would like to connect the stove at the back (technical data sheet contains the connection height), remove the flue outlet from the top and the closing lid from the back.
- Page 9 If there is wallpaper it is recommended to remove from behind the stove and in case of a corner model from the side as well. Installation of the connecting pipe: connect the pipe to the flue outlet of the DANBURN appliance. Push the fireplace stove to the chosen location with consideration of the specified safety distances and install it in such way that the connecting pipe fits into the prepared chimney insert.
-
Page 10: Secondary Air Control
11. Suitable fuels (cont) Burning wood is recommended for operating the stove at its nominal capacity. Watch the heating value of the fuel you use. You can get the exact data at a fuel supplier. Load the fireplace with fuel according to heat demand. The heating value of 1 kg of dry wood is 4 –... - Page 11 13. Lighting the fire for the first time Follow the directions below when you light the fire for the first time. High burning temperature is necessary for the fuel to catch fire quickly, so put enough fire-starter on the grate at the lower part of the combustion chamber. Put 2 or 3 smaller pieces of wood or a similar quantity of wooden briquettes, on the grate.
- Page 12 14. Further use (cont) Do not restrain the fire, load less fuel instead, and never close the primary air regulator completely. Your stove is equipped with an automatically closing door. It can be operated only with a closed door. Open the door only if you want to load more fuel and only if the previous amount has burned down to embers. Remember that the stove heats up during use.
- Page 13 15. Trouble Shooting(cont) - What can you do? - Open the primary air regulator a bit more, and fully open the secondary air regulator. - Use only a small amount of fuel at first. - Use only a small amount of fuel when reloading. - Shake off the ash more often.
- Page 14 (as further described in the operation manual). 7. Damage caused by use of the wrong type of fuel. 8. Damage caused by modifications or repair other than as expressly authorised by Danburn or by the user or any other party other than Danburn.
- Page 15 Page 15 /16...
- Page 16 DANBURN Tømrervej 3 6800 Varde Denmark UK IMPORTER Eurostove Ltd Unit H1 Mendip Industrial Estate Rooksbridge Somerset BS26 2UG Tel: 01934 750500 e-mail: info@eurostove.co.uk web: www.eurostove.co.uk Ref : dbmv1.01.2016 Page 16 /16...
