TVIP83900 / TVIP86900
gb
User manual
Version 12/2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TVIP83900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Abus TVIP83900

Summary of Contents for Abus TVIP83900

  • Page 1 TVIP83900 / TVIP86900 User manual Version 12/2014...
  • Page 2 English These user manual contains important information for installation and operation. This should be also noted when this product is passed on to a third party. Therefore look after these operating instructions for future reference! A list of contents with the corresponding page number can be found in the index on page 73.
  • Page 3 TVIP83900/TVIP86900 User manual Version 12/2014 English translation of the original German user manual. Retain for future reference.
  • Page 4 ABUS Security-Center GmbH & Co. KG does not accept any liability for technical and typographical errors, and reserves the right to make changes to the product and user manuals at any time and without prior warning.
  • Page 5 Explanation of symbols The triangular high voltage symbol is used to warn of the risk of injury or health hazards (e.g. caused by electric shock). The triangular warning symbol indicates important notes in this user manual which must be observed. This symbol indicates special tips and notes on the operation of the unit.
  • Page 6 Safety information Power supply: Power supply unit 100–240 V AC, 50/60 Hz / 12 V DC, 1 A (included in the scope of delivery). Only operate this device through a power source which supplies the mains power specified on the type plate.

  • Page 7: Table Of Contents

    Contents Intended use ............................75 Scope of delivery ..........................75 Features and functions ........................75 Device description ..........................75 Description of the connections ......................76 Initial start-up ............................77 Accessing the network camera for the first time ................78 Password prompt ..........................79 User functions ............................
  • Page 8 10.3.5.3 IP Address Filter..........................120 10.3.6 Basic event ............................121 10.3.6.1 Motion detection ........................... 121 10.3.6.2 Video tampering ..........................123 10.3.6.3 Alarm input (TVIP83900 only) ...................... 125 10.3.6.4 Alarm output (TVIP83900 only) ....................127 10.3.8 Storage .............................. 129 10.3.8.1 Record schedule ........................... 129 10.3.8.2 Storage management ........................

  • Page 9: Intended Use

    Digital, stageless panning, tilting or zooming without mechanical camera movement  Freely configurable patrols (panning/tilting)  Power over Ethernet (PoE)  Up to 25 fps real-time video 4. Device description Model number TVIP83900 TVIP86900 Resolution 3 MPx 6 MPx √ Audio √ √...

  • Page 10: Description Of The Connections

    Microphone (only in TVIP83900) Loudspeaker (only in TVIP83900) Description Micro SD card slot Reset button RS485 connection (not used) Audio input (TVIP83900 only) Power supply 12 V DC RJ45 connection Alarm input and output (TVIP83900 only) Audio output (TVIP83900 only)

  • Page 11: Initial Start-Up

    6. Initial start-up The network camera automatically detects whether a direct connection between the PC and camera should be established. A crossover network cable is not required for this. You can use the supplied patch cable for direct connection for initial start-up. Connecting the network camera directly to a PC/laptop 1.

  • Page 12: Accessing The Network Camera For The First Time

    7. Accessing the network camera for the first time The network camera is accessed for the first time using the ABUS IP Installer. After the installation wizard is started, it searches for all connected ABUS network cameras and video servers on your network.

  • Page 13: Password Prompt

    8. Password prompt An administrator password is defined for the network camera prior to delivery. For reasons of security, however, the administrator should select a new password immediately. After the new administrator password has been saved, the network camera asks for the user name and password every time it is accessed.

  • Page 14: User Functions

    9. User functions Open the network camera home page. The interface is divided into the following main areas: Menu bar Live image display Audio/video control 9.1 Menu bar Select the appropriate tab: 'Live View', 'Playback', 'Configuration' and Log. (Log function is only possible with built in micro SD card).

  • Page 15: Live Image Display

    Automatically adjust view to browser 9.3 Audio/video control Button Description Disable live view Enable live view Disable/enable audio, adjust volume (TVIP83900) Microphone on/off (TVIP83900) Instant image (snapshot) Start/stop manual recording Digital zoom 9.4 Live view mode The availability of the options in the live view differs according to whether real-time mode is enabled or disabled (Configuration/System/Fisheye Parameters).

  • Page 16: Ptz Control

    9.5 PTZ control To display the PTZ control, click on the field in the live view. Button Description Arrow buttons: Control the swivel/tilt motions Start/stop 360° rotation Zoom in/out Adjust the PTZ speed 9.5.1 Preset settings Select the Preset tab to be able to call up, set and delete up to 256 preset positions.

  • Page 17: Patrol Settings

    9.6 Patrol settings A patrol consists of a series of presets. You can create up to 8 patrols, each with up to 32 presets. Please note that the presets that should be added to a patrol are predefined. To create a new patrol, proceed as follows: Select the Patrol tab .

  • Page 18: Configuration

    10. Configuration 10.1 Local configuration Under the 'Local Configuration' menu item, you can select settings for the live view, file paths of the recordings and snapshots. Live view parameters Here you can set the protocol type and the live view performance of the camera. Protocol Complete provision of streaming data and high video quality;...
  • Page 19 Recording file settings You can define the file size for recordings, the recording path and the path for downloaded files here. To apply the changes, click 'Save'. Recording file size You can choose between 256 MB, 512 MB and 1 GB as the file size for recordings and downloaded videos. Save record files to You can determine the file path that is to be used for manual recordings here.

  • Page 20: Basic Configuration

    10.2 Basic configuration All settings located under 'Basic Configuration' can also be found under the menu item 'Advanced Configuration'. Please note the 'Available in mode' column in the descriptions of the 'Advanced Configuration'. 10.3 Advanced configuration 10.3.1 System Menu item Description Available in mode Display of device information...

  • Page 21: Device Information

    10.3.1.1 Device information Basic Information Device Name: You can specify a device name for the Speed Dome here. Click on 'Save' to apply the change. Model: Model number display Serial Number: Serial number display Firmware Version: Firmware version display Encoding Version: Encoding version display Number of Channels: Display of the number of channels...

  • Page 22: Time Settings

    10.3.1.2 Time settings Time Zone Time zone selection (GMT). Time Sync. Using the Network Time Protocol (NTP) it is possible to synchronise the time of the Speed Dome with a time server. Enable NTP to use this function. Server Address IP server address of the NTP server.

  • Page 23: Maintenance

    10.3.1.3 Maintenance Reboot Click 'Reboot' to restart the device. Default Restore Click 'Restore' to restore all the parameters to default settings, except the IP parameters and user information. Default Select this item to restore all parameters to default settings. Import Config. File Config File Select a file path to import a configuration file here.

  • Page 24: Daylight Saving Time

    10.3.1.4 Daylight saving time Daylight saving time Enable DST Activate the 'Enable DST' checkbox to adjust the system time automatically to daylight saving time. Start Time Specify the time for switching to daylight saving time. End Time Specify the time for switching to standard time. Apply the settings by clicking 'Save'.

  • Page 25: Fisheye Parameters

    When Real-time Mode is enabled, the Fisheye View can be displayed with up to 25 frames/second (when Real-time Mode is disabled, this is known as Normal Mode). However, when Real-time Mode is enabled, not all live view options are available. TVIP83900 Resolutions available: Real-time Mode: Fisheye (2048x2048, 1280x1280), PTZ (1024x768, 704x576, 640x480, 320x240)

  • Page 26: Network

    10.3.2 Network Available in Menu item Description mode Settings for the TCP/IP data Basic TCP/IP Configuration, Advanced Configuration Settings for the used ports Basic Port Configuration, Advanced Configuration Settings for the DDNS data Advanced DDNS Configuration Settings for Point-to-Point Protocol (PPP) Advanced PPPoE Configuration...

  • Page 27: Tcp/Ip

    10.3.2.1 TCP/IP To be able to operate the Speed Dome via a network, the TCP/IP settings must be configured correctly. NIC Settings NIC Type Select the setting for your network adapter. You can choose from the following values: 10M Half-dup; 10M Full-dup; 100M Half-dup; 100M Full-dup;...
  • Page 28 IPv6 Address Display of the IPv6 address. The address can be configured in the IPv6 'manual' mode. IPv6 Subnet Mask Display of the IPv6 subnet mask. IPv6 Default Gateway Display of the IPv6 default gateway (default router). MAC Address The IPv4 hardware address of the camera is displayed here. This cannot be changed. Setting of the transmission unit.

  • Page 29: Port

    10.3.2.2 Port If you wish to enable external access to the Speed Dome, the following ports must be configured. HTTP Port The standard port for HTTP transmission is 80. This port can alternatively be assigned a value in the range of 1024~65535.

  • Page 30: Ddns

    10.3.2.3 DDNS DDNS DynDNS or DDNS (dynamic domain name system entry) is a system that can update domain name entries in real time. The network camera is equipped with an integrated DynDNS client that updates the IP address independently via a DynDNS provider. If the network camera is located behind a router, we recommend using the DynDNS function of the router.
  • Page 31 Select a DDNS service provider. You must have registered access to this DDNS service provider (e.g. www.dyndns.org). If you select 'ABUS DDNS' as the DDNS type, the server address is stored automatically. Domain Enter the registered domain name (host service) here (e.g. myIPcamera.dyndns.org).
  • Page 32 (System/Maintenance/Reboot). ABUS DDNS To be able to use the ABUS DDNS function, you first need to set up an account at www.abus- server.com. Please read the FAQs on this topic on the website. Select the 'Enable DDNS' checkbox and select 'ABUS DDNS' as the DDNS type.

  • Page 33: Pppoe

    10.3.2.4 PPPoE Enable PPPoE: Check this box to enable this function Dynamic IP: The IP address is automatically determined User name: User name of the service provider Password: Password for access Confirm: Password confirmation 10.3.2.5 SNMP SNMP v1/2 Enable SNMPv1: Enabling of SNMPv1 Enable SNMPv2: Enabling of SNMPv2...
  • Page 34 Authentication Password: Password assignment Private-key Algorithm: Select encryption algorithm: DES, AES Private-key password: Password assignment Write UserName: Allocate user name Security Level: Auth, priv: No authentication, no encryption Auth, no priv: Authentication, no encryption no auth, no priv: No authentication, encryption Auth.

  • Page 35: Qos

    10.3.2.6 802.1X Enable IEEE 802.1X: Enable 802.1X authentication Protocol: Protocol type EAP-MD5 (only) EAPOL version: Extensible Authentication Protocol over LAN, choice between version 1 or 2 User name: Enter the user name Password: Enter the password Confirm: Password confirmation 10.3.2.7 QoS Video/Audio DSCP: (Differentiated Service Code Point) (0~63): Priority for video/audio IP packages.

  • Page 36: Ftp

    10.3.2.8 FTP To upload recorded videos or images onto an FTP server, the following settings must be selected. Server Address Enter the IP address of the FTP server here. Port Enter the port number of the FTP server here. The standard port for FTP servers is 21. User name User name of the account that was configured in the FTP server.

  • Page 37: Upnp

    10.3.2.9 UPnP™ The UPnP (Universal Plug and Play) function makes it easy to control network devices in an IP network. This allows the network camera to be seen in the Windows network environment (e.g. as a network device). Enable UPnP™ For enabling or disabling the UPnP function.

  • Page 38: Email

    10.3.2.10 Email You can apply the settings for sending emails here. Sender Sender Enter a name here to be displayed as the sender. Sender's Address Enter the email address of the sender here. SMTP Server Enter the IP address or host name of the SMTP server here (for example: smtp.googlemail.com). SMTP Port Enter the SMTP port here.

  • Page 39: Nat

    Authentication If the email server in use requires authentication, enable this function to be able to log onto the server with authentication. User names and passwords can only be entered once this function has been enabled. User name Enter the user name of the email account here. This is the part before the @ symbol. Password Enter the password of the email account here.
  • Page 40 RTSP The standard port for RTSP transmission is 554. This port can alternatively be assigned a value in the range of 1025~65535. If several IP cameras are located on the same subnetwork, each camera should have its own unique RTSP port. Server Port (control port) The standard port for SDK transmission is 8000.

  • Page 41: Video/Audio

    10.3.3 Video/Audio Menu item Description Available in mode Settings for video output Basic Configuration, Video Advanced Configuration Settings for audio output Basic Configuration, Audio Advanced Configuration (TVIP83900 only) 'Region of Interest' Basic Configuration, Advanced Configuration...

  • Page 42: Video

    The camera has one stream per channel ('Main Stream (Normal)'). There are no other options available. Video Type Select either 'Video' or 'Video&Audio' for the stream type (TVIP83900 only). The audio signal is only recorded if 'Video&Audio' is selected as the stream type.
  • Page 43 TVIP83900 Resolutions available: Real-time Mode: Fisheye (2048x2048, 1280x1280), PTZ (1024x768, 704x576, 640x480, 320x240) Normal Mode: Fisheye (1536x1536), PTZ (800x600, 704x576, 640x480, 320x240), Panorama (1600x1200, 1280x720) TVIP86900 Resolutions available: Real-time Mode: Fisheye (3072x2048, 2048x2048, 1280x1280), PTZ (1024x768, 704x576, 640x480, 320x240) Normal Mode: Fisheye (1280x1280), PTZ (1024x768, 704x576, 640x480, 320x240), Panorama (2048x1536,...

  • Page 44: Audio

    10.3.3.2 Audio (only TVIP83900) Audio Encoding Select the encoding for audio transmission here. You can choose between 'G.711ulaw', 'G.711alaw' and 'G.726'. Audio Input MicIn: The settings for the audio input on the back of the camera are customised to a microphone (unamplified source).

  • Page 45: Roi 'Region Of Interest

    10.3.3.3 ROI 'Region of Interest' The 'Region of Interest (ROI)' function defines areas in the video image which are transmitted at a higher bitrate than the surrounding areas. Channel Number: selection of the channel number for adding ROIs. Draw Area: Depiction of up to four ROI areas per channel (the region number must be changed below for a new area).

  • Page 46: Image

    10.3.4 Image Menu item Description Available in mode Displaying parameter settings Basic Configuration, Display Settings Advanced Configuration Setting the date and time format Advanced OSD Settings Configuration Adding privacy masking Advanced Privacy Masking Configuration...

  • Page 47: Display Settings

    10.3.4.1 Display settings You can use this menu item to set the picture quality of the Speed Dome, for example brightness, sharpness, contrast. Click on 'Default' to restore the default values. Please note: The display setting parameters can vary depending on the model. Image Adjustment Brightness Image brightness settings.
  • Page 48 Exposure Settings Exposure Mode Automatic or manual setting of exposure parameters. Exposure Time Setting the maximum exposure time. This setting is dependent on iris mode. Gain Setting the gain value for the video image. Day/Night Switching Day/Night Switch Day/Night Switch provides options for 'Auto', 'Day' and 'Night'. Auto Depending on the light conditions, the camera switches between day and night mode automatically.
  • Page 49 White Balance Here you select the lighting conditions in which the camera is installed. You can choose from the following options: 'MWB', 'AWB1', 'WB Locked', 'Florescent Lamp', 'Incandescent Lamp', 'Warm Light Lamp', 'Natural Light'. You can adjust the white balance with the following values manually. WB Locked The white balance is performed once and saved.

  • Page 50: Osd Settings

    10.3.4.2 OSD Settings You can use this menu item to select which date and time format are displayed in the live picture. Display Name Activate this checkbox if you wish to display the camera name. Display Date Activate this checkbox if you wish to display the date in the camera image. Display Week Activate this checkbox if you wish to display the day of the week.

  • Page 51: Privacy Mask

    10.3.4.3 Privacy Mask You can use privacy masks to hide certain areas in the live view to prevent these areas from being recorded and viewed in the live view. A maximum of four rectangular privacy masks can be set up in the video image. To set up a privacy mask, proceed as follows.

  • Page 52: Security

    10.3.5 Security Menu item Description Available in mode User administration Basic Configuration, User Advanced Configuration Setting the date and time format Advanced RTSP Configuration Authentication Filtering IP addresses to gain access for controlling the Advanced IP Address camera Configuration Filter 10.3.5.1 User With this menu item, you can add, edit or delete users.
  • Page 53 To add further functions, select the corresponding checkbox. Password Here you assign the password that the corresponding user must enter to access the camera. Confirm Confirm the password by entering it again. Apply the settings by clicking 'OK'. Click 'Cancel' to discard the data.

  • Page 54: Rtsp Authentication

    10.3.5.2 RTSP Authentication You can secure the video stream of the live view with this function. Select 'Disable' to deactivate this function. To activate this function, select 'Basic'. Apply the settings by clicking 'Save'. 10.3.5.3 IP Address Filter Enable IP Address Filter Ticking the selection box enables the filter function.

  • Page 55: Basic Event

    10.3.6 Basic event Menu item Description Available in mode Settings for motion detection Advanced Motion Detection Configuration Settings for video tampering Advanced Video Tampering Configuration Setting for the alarm input Advanced Alarm Input Configuration Setting for the alarm output Advanced Alarm Output Configuration 10.3.6.1 Motion detection...
  • Page 56 To select an area, click on the 'Draw Area' button. The entire area is selected by default. To discard this selection, click on 'Clear All'. Drag the mouse pointer over the desired area. Set the sensitivity using the regulation control bar. To apply the setting for the area, click on 'Stop Drawing'.

  • Page 57: Video Tampering

    10.3.6.2 Video tampering With this menu item you can configure the Speed Dome so that video tampering is triggered as soon as the lens is covered. Area Settings Activate video tampering by clicking the 'Enable Video Tampering' checkbox. To select an area, click on the 'Draw Area' button. The entire area is selected by default. To discard this selection, click on 'Clear All'.
  • Page 58 Now select a day of the week for the video tampering. To store particular time periods, enter a start and end time. To set up all-day video tampering, select 00:00 as the start time and 24:00 as the end time. To activate video tampering for all days of the week, click the 'Select All' checkbox.

  • Page 59: Alarm Input (Tvip83900 Only)

    10.3.6.3 Alarm input (TVIP83900 only) You can configure the alarm inputs of the Speed Dome with this menu item. Alarm Input No. Here you can select the alarm input that you wish to configure. Alarm Name You can specify a device name for the alarm input here. Please do not use the alarm input number or any special characters.
  • Page 60 A new window appears. Specify here on which days of the week and at which times the alarm input should be enabled. Now select a day of the week for the alarm input. To store particular time periods, enter a start and end time. To activate the alarm input all day, select 00:00 as the start time and 24:00 as the end time.

  • Page 61: Alarm Output (Tvip83900 Only)

    10.3.6.4 Alarm output (TVIP83900 only) You can configure the two alarm outputs here. Alarm Output No. Here, select the alarm output that you wish to configure. Alarm Name You can specify a name for the relevant alarm output here. Please do not use the alarm output number or any special characters.
  • Page 62 Now select a day of the week for the alarm output. To store particular time periods, enter a start and end time. To activate the alarm input all day, select 00:00 as the start time and 24:00 as the end time. To apply the settings for all days of the week, click the 'Select All' checkbox.

  • Page 63: Storage

    10.3.8 Storage 10.3.8.1 Record schedule Here, you can set the configuration for time and event-triggered recordings in order to be able to save them to an SD card. Pre-record Set the duration for recording of the image data before a basic event here. Post-record Set the duration for recording of the image data after a basic event here.
  • Page 64 Now select a day of the week for the recording to take place. To store particular time periods, enter a start and end time. To activate the alarm input all day, select 00:00 as the start time and 24:00 as the end time. To apply the settings for all days of the week, click the 'Select All' checkbox.

  • Page 65: Storage Management

    10.3.8.2 Storage management Here you can format the inserted micro SD card and display its properties. Please format the SD card before using it for the first time.
  • Page 66 10.3.8.3 NAS This menu can be used to set the NAS storage locations; these are then available in the camera as a drive (HDD) for storage. Server Address IP address of the NAS drive File Path: path on the NAS drive...

  • Page 67: Snapshot

    10.3.8.4 Snapshot You can configure time and event-triggered snapshots here in order to set them to be uploaded to an FTP server. Timing Enable Timing Snapshot Enable this function to save pictures at certain intervals. Format The format for the pictures is preconfigured as JPEG. Resolution Set the resolution of the picture here.

  • Page 68: Maintenance And Cleaning

    11. Maintenance and cleaning 11.1 Maintenance Regularly check the technical safety of the product, e.g. check the housing for damage. If it seems that it may no longer be possible to operate the device safely, stop using the product and secure it to prevent unintentional use.

  • Page 69: Technical Data

    Email/FTP/alarm output Mozilla Firefox, Safari or Internet Mozilla Firefox, Safari or Internet Supported browsers Explorer 6.x and higher Explorer 6.x and higher ABUS VMS, TVVR35011, ABUS VMS, TVVR35011, Supported software/NVR TVVR450x1, TVVR600x1 TVVR450x1, TVVR600x1 Network connector RJ-45 Ethernet 10/100 Base-T...

  • Page 70: Gpl License Information

    14. GPL license information Here we wish to inform you that the network surveillance cameras TVIP83900 and TVIP86900, amongst others, include open source software licensed exclusively under the GNU General Public License (GPL). To ensure that your use of the programs conforms with GPL, please refer to the GPL license conditions.
  • Page 71 We reserve the right to change the technical or physical specifications. Note de l’éditeur Cette notice est une publication de la société ABUS Security-Center GmbH & Co. KG, Linker Kreuthweg 5, 86444 Affing, Germany. Tour droits réservés, y compris traduction. Toute reproduction, quel que soit le type, par exemple photocopies, microfilms ou saisie dans des traitements de texte electronique est soumise à...
