Page 1: Table Of Contents
English, 9 Deutsch, 17 Technical characteristics, 10 Electrical connection, 11 Safety measures, 12 Nederlands, 25 Italiano, 33 Español, 41 Installation, 13 Operation, 14 External exhausting version Operation with recirculated air Use of the hood, 15 GFI 681 Lighting, 15 Cleaning, 16...
Page 2: Technical Characteristics
Technical characteristics Models GFI 681 Dimensions (in mm) Width (hole on the bottom side of the cabinet) 750 (696) depth (hole on the bottom side of the cabinet) height (min./max.) Ø of exhausting connection Weight (in kg) Absorption (in watts - 220-240 V ~)
Page 3: Electrical Connection
Electrical connection ! Warning: This appliance must be earthed. ! Attention: if the appliance is permanently connected Before installing the hood, it is vital to ensure that the to the mains, the plug supplied must be removed and mains voltage corresponds to the voltage indicated on safely disposed of.
Page 4: Safety Measures
Safety measures The cooker hood is designed to operate for extraction removes the ambient air required by the burner or to the outside. It is important therefore to ensure that fireplace for combustion. sufficient air enters the kitchen for correct operation. For secure operation and to prevent discharged gas The hood cannot be connected to flues of other from coming back in, the vacuum must not exceed...
Page 5: Installation
Installation This appliance is designed to be installed in a cabinet or other supporting structure. Make a hole in the bottom of the wall-hung cabinet, using the dimensions shown in diagram 1. To fix the hood, proceed as follows: a) Remove the filter or grease filters and the frame B (Diagram 1).
Page 6: Operation
Operation Operation with recirculated air • It is strongly recommended always to be in attendance when frying under the hood. • Food must not be flambeed under the hood Two charcoal filters, available from your local retailer, because of fire risk. should be used.
Page 7: Use Of The Hood
Use of Lighting the hood • The control panel (Diagram 4) is situated next to the Disconnect the hood from the electricity. lamp covers and has two control switches: one for • Remove the grease filter(s) and the frame. controlling the fan power and an ON-OFF switch for •...
Page 8: Cleaning
Cleaning Replacing the carbon filter: Before performing any maintenance operation disconnect the hood from the mains. These filters normally last about six months. However, To ensure that your hood works efficiently and they cannot be cleaned or recycled. Therefore, they constantly it is recommended that it should be must be replaced when no longer useable.
