AutoSat GPS-GPRS Video Instruction Manual

Satellite car alarm
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
ENGLISH
9
.0. LEGEND OF PARAMETERS AND COMMANDS
PARAMETER
ID
System identification number. Assigned by user.
Numerical string 8 digits. Fty Setting: 99999999
USERID
Parameters of recognition for connection to the internet.
Supplied by SIM card provider.
APN
Parameter for configuration of SIM to allow e-mail transmission.
SMTP_Server
Supplied by SIM card provider.
E-MAIL_SIM
E-mail address associated to SIM card
Supplied by SIM card provider.
PSW
User password for access to system.
Alphanumerical string from 0 to 8 characters. Fty setting: 1234
INT_PASSW
Recognition password for connection to the internet.
Supplied by SIM card provider.
COMMAND
!PASS
To change password for access to system (PSW)
!PARA
Memorization of the parameters of the SIM card
!MAIL
The memorization of e-mail addresses
!NTEL
The memorization of telephone numbers
!APSM
To start-up the AutoSat SIM card for e-mail messages
!RISF
To set resolution of cameras
!IDAS
To give the AutoSat an identification number (ID)
!POSI
To request last GPS position
!STAT
To request the status of the installation and additional information
!DELI
Request to cancel image memory
!DELG
To cancel the GPS data in memory and memorized new data
!MEMO
To check memorized telephone numbers and e-mail addresses
!RPAR
Control of the parameters memorized in the SIM card
!RAPS
To request the memorized APN and SMTP parameters of the AutoSat SIM card
!LGPS
Request e-mail showing the vehicle co-ordinates and the speed
!LASN
Request e-mail with last 3 photos memorized, the GPS position
!SNAP
Request e-mail in real time photos, GPS position and the vehicle speed
Page 16
DESCRIPTION
DESCRIPTION
and the vehicle speed
AutoSat GPS - GPRS video instruction manual
SATELLITE CAR ALARM AND
Index
1.0. Description .......................................................................................................2
2.0. Installation and power-up ................................................................................3
3.0. Message programming..................................................................................... 5
3.1. SMS message programming....................................................................5
To memorize the parameters of the SIM card ............................................5
To memorize and cancel up to 3 telephone numbers.................................6
To enable the AutoSat for e-mail transmission ..........................................6
Regulating of the resolution installed cameras ...........................................7
To give the AutoSat an identification number (ID) .....................................7
3.2. SMS remote command with only SMS reply ..........................................7
To change password ..................................................................................7
To request the last GPS position ................................................................8
To request the status of the installation ......................................................8
Request to cancel memorized images .......................................................8
3.3. Request by SMS with SMS and e-mail replay ........................................10
Request for e-mail with pre-programmed file showing the vehicle
co-ordinates and the speed ........................................................................ 10
Request for e-mail with the last photos memorized (up to 3), the GPS
position and the speed of the vehicle .........................................................11
Requesting e-mail with real time photos, GPS position and the
speed of the vehicle ....................................................................................11
4.0. How AutoSat functions with an alarm trigger ........................................12
5.0. Characteristics of the Master telephone number ..................................13
6.0. SMS warning message in case of e-mail message failure ...................13
7.0. Cable assembly ........................................................................................14
8.0. Technical characteristics .........................................................................15
9.0. Legend of parameters and commands ..................................................16
AutoSat GPS - GPRS video instruction manual
ENGLISH
Page
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GPS-GPRS Video and is the answer not in the manual?

Questions and answers

Summary of Contents for AutoSat GPS-GPRS Video

  • Page 1: Table Of Contents

    Control of the parameters memorized in the SIM card speed of the vehicle ..................11 !RAPS To request the memorized APN and SMTP parameters of the AutoSat SIM card 4.0. How AutoSat functions with an alarm trigger ........12 5.0. Characteristics of the Master telephone number ........13...

  • Page 2: Description

    • The e-mail addresses to which AutoSat will communicate • The ring and SMS telephone numbers that the AutoSat must call in case of alarm trigger • Digital camera resolution • AutoSat identification number if managed by a monitoring station (indicated as ID) •...

  • Page 3: Installation And Power-Up

    .0. CABLE ASSEMBLY .0. INSTALLATION AND POWER-UP Included with the AutoSat kit is a 12 pole cable assembly for easy installation of the system. Before proceeding to install the AutoSat, it is necessary to purchase a SIM card capable of handling GPRS traffic.
  • Page 4 Phase 1. Start-up of the digital camera installed By sending a ring to the AutoSat (system in active mode), a reply will be received by the number calling, giving an SMS message, with information on the status of the installation.

  • Page 5: Message Programming

    To transmit and receive e-mails, it is necessary to open an e-mail account for the SIM card 99999999-Attention, alarm X! Info GPS: speed 2 km/h; inserted in the AutoSat. To do this, you must contact the SIM card GSM company and latitude 41,7112 north; longitude 12,6284 east request an e-mail account to be assigned to the SIM card.

  • Page 6: To Memorize And Cancel Up To 3 Telephone Numbers

    GPS position and the speed of the vehicle (command "!LASN") To memorize in the AutoSat the telephone numbers to which the SMS and ring will be sent during alarm trigger, it is necessary to send an SMS command message to the AutoSat...

  • Page 7: Regulating Of The Resolution Installed Cameras

    If it is not possible to send an e-mail, the requesting telephone number will receive an SMS message which indicates the reason of the e-mail failure To create this ID, you must send an SMS message to the SIM card of the AutoSat using (see paragraph 6.0. on Page 13).

  • Page 8: To Request The Last Gps Position

    Request to cancel memorized images (command "!DELI") AutoSat replies: RPAR: brown@xyz.com, brown, test It is possible to cancel the AutoSat image memory by sending an SMS message to the SIM card inserted in the unit with the following format: Control of the APN and SMTP memorized parameters related to the SIM card (command "! !DELI#PSW# RAPS")
