Page 1: User Manual
User Manual XTREME OUTDOOR SOUNDBAR MODEL: SPK-060 www.peerless-av.com 2016-01-12 #:180-9069-D... - Page 2 WARNING ENG - This product was designed to be installed on wood stud walls and solid concrete (2000 psi density mini- mum) or cinder block walls. Before installing make sure the supporting surface will support the combined load of the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.
-
Page 3: Table Of Contents
CONTENTS Warnings and symbols ..........................2 General Safety Precautions ........................4 Parts list ...............................6 Installation Instructions ...........................8 Mounting to a Wall ..........................8 Mounting to a Display ........................14 Battery Installation and Replacement ....................16 Cable Managment and Soundbar Orientation ................17 Operating Instructions ..........................18 Using The Remote Control ......................18 Tips .. -
Page 4: General Safety Precautions
RISK OF ELECTRICAL SHOCK To reduce the risk of electric shock, do not disassemble the unit under any circumstances. No user serviceable parts inside. All product services should be done by the Peerless-AV certifi ed service personnel. Read before operating equipment Thank you for purchasing our product. - Page 5 16. Periodically clean dust off the power plug, to keep it clean and dry, ensuring proper and safe operation of the product. 17. Do NOT destroy, process, or place the product close to any heating device; do NOT bend or twist power cords, power plugs, cables, or wires with excessive force;...
-
Page 6: Fcc Statement
CAUTION: Please use the electrical cord provided with this display. If a electrical cord is not supplied with this equipment, please contact your supplier. Only plug equipment into receptacles with GFCI protection. IMPORTANT: Peerless-AV is not responsible for any issues created by water present at the plug/receptacle insertion point. Plug Type: North America... -
Page 7: Parts List
Parts List Description Part # soundbar soundbar hook-on bracket 180-0265 wall plate 180-0264 left mount bracket 180-0268 right mount bracket 180-0267 remote control remote #14 x 2.5" wood screw 520-D1033 8mm concrete anchor 590-0320 lock washer 540-3622 nylon washer 590-1231 M8 X 25mm socket pin screw 520-D1101 M8 x 40mm socket pin screw... - Page 8 G (2) H (2) #14 x 2-1/2" wood screw 8mm concrete anchor I (2) K (2) J (2) lock washer M8 x 25mm nylon washer M (2) O (2) Q ( 1 ) .5" spacer M5 x 10mm 4mm allen wrench L (2) M8 x 40mm N (2)
-
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS Mounting to a Wall Wood stud wall. Concrete/Cinder block. 1a-1 1b-1 1a-1 Use stud fi nder to locate and mark stud center lines. 1a-2 Level wallplate. Mark mounting holes on stud center lines. 2016-01-12 #:180-9069-D... - Page 10 1a-3 5/32" Drill mounting holes into supporting surface (4mm) (2.5" (64mm) minimum depth required). 2.5" (64mm) 5/32" (4mm) Mounting hole must center on stud. 1a-4 Level wallplate. Install using wood screws provided. 3/8" (10mm) Maximum 80 in. • lb (9 N.M.). G (4) 2016-01-12 #:180-9069-D...
- Page 11 1b-1 Level wallplate. Mark mounting holes. 1b-2 2.5" (64mm) 5/16" 5/16" (8mm) (8mm) Drill mounting holes into supporting surface (2.5" (64mm) minimum depth required). Do not drill into mortar joints. 2016-01-12 #:180-9069-D...
- Page 12 1b-3 H (2) Insert anchor fl ush to concrete. 1b-4 Level wallplate. Install using concrete anchors and wood screws provided. 3/8" (10mm) Maximum 80 in. • lb (9 N.M.). G (4) 2016-01-12 #:180-9069-D...
- Page 13 P (2) Do not fully tighten 2016-01-12 #:180-9069-D...
- Page 14 I (2) K (2) B (2) Hook brackets onto wall plate and tighten M5 screw SIDE VIEW B (2) tighten 2016-01-12 #:180-9069-D...
-
Page 15: Mounting To A Display
Mounting to a Display P (2) Position display screen-side down on a fl at, clean surface. Position soundbar grill-side down either above or below display. Determine which bracket confi guration below fi ts your display " 3 . 6 . 7 " . - Page 16 Determine which hardware to use based on the depth needed. *Hardware included for installing soundbar only. To attach display, use hardware included with display mount. 2016-01-12 #:180-9069-D...
-
Page 17: Battery Installation And Replacement
Snap the battery cover back onto the remote control. CAUTION Incorrect usage of batteries can result in leaks or bursting. Peerless-AV recommends the following battery use: Do not mix battery brands. Do not combine new and old batteries. This can shorten the battery life or cause liquid leakage of the batteries. -
Page 18: Operating Instructions
Treble + Treble - Treble + Bluetooth AUX Input peerless-AV Turn on the TV. Remote control functions Turn on the soundbar by aiming the included remote Discrete Off – Powers the soundbar Off at the front of the soundbar and pressing the ON Discrete On –... -
Page 19: Tips
• Complete a device scan on the device that is being connected and select "Peerless-AV" from the list of devices. • If "Peerless-AV" is not present on the list, turn the Bluetooth on the device off. Turn the Bluetooth on the soundbar off by switching to the Aux input. -
Page 20: Warranty
2. Labor – the warranty period for labor is: one (1) year from the date of original purchase. During the applicable Limited Warranty period for labor, Peerless-AV will provide the labor for warranty repair at no charge for a period of one (1) year from the date of original purchase.
