SERVICE
LED TV
UA**F5500A*
LED TV
Chassis : U85A
Model
: UA32F45*0A*
UA**F53*0A*
UA**F55**A*
Manual
1. Precautions

Contents

Advertisement

Table of Contents
loading

Related Manuals for Samsung UA32F45 Series

Summary of Contents for Samsung UA32F45 Series

  • Page 1 LED TV Chassis : U85A Model : UA32F45*0A* UA**F53*0A* UA**F55**A* SERVICE Manual LED TV Contents 1. Precautions 2. Product specifications 3. Disassembly and Reassembly 4. Troubleshooting 5. Wiring Diagram UA**F5500A*...

  • Page 2: Table Of Contents

    Contents 1. Precautions ........................1-1 1-1. Safety Precautions ......................1-1 1-2. Servicing Precautions ......................1-3 1-3. Static Electricity Precautions ....................1-4 1-4. Installation Precautions .......................1-5 2. Product Specifications....................2-1 2-1. Product Information ......................2-1 2-2. Accessories .........................2-8 3. Disassembly and Reassembly ..................3-1 3-1. Disassembly and Reassembly ....................3-1 3-2.
  • Page 3 This Service Manual is a property of Samsung Electronics Co.,Ltd. © 2013 Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable All rights reserved. International and/or domestic law. Printed in Korea...

  • Page 4: Precautions

    1. Precautions 1. Precautions 1-1. Safety Precautions Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as electrical shock. 1-1-1. Warnings For continued safety, do not attempt to modify the circuit board. Disconnect the AC power and DC power jack before servicing.
  • Page 5 1. Precautions 1-1-4. Product Safety Notices Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage, wattage, etc.

  • Page 6: Servicing Precautions

    1. Precautions 1-2. Servicing Precautions An electrolytic capacitor installed with the wrong polarity might explode. WARNING Before servicing units covered by this service manual, read and follow the Safety Precautions section of this manual. CAUTION If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions, always follow the safety precautions.

  • Page 7: Static Electricity Precautions

    1. Precautions 1-3. Static Electricity Precautions Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some field-effect transistors. The following techniques will reduce the incidence of component damage caused by static electricity. Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your body by touching a known earth ground.

  • Page 8: Installation Precautions

    1. Precautions 1-4. Installation Precautions For safety reasons, more than a people are required for carrying the product. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature may cause fire.

  • Page 9: Product Specifications

    2. Product specifications 2. Product Specifications 2-1. Product Information 2-1-1. Model Comparison Model UE**F5500 Front View * W : Width H : High D : Depth Detail View Front Color Black (Panel) Set with 750.9 x 476.9 x 207.8 mm / 29.6 x 18.8 x 8.2 inches Stand 32F45 Set without...
  • Page 10 2. Product specifications Set with 5.6 kg / 12.3 lbs Stand 32F45 Set without 5.3 kg / 11.7 lbs Stand Set with 5.7 kg / 12.6 lbs Stand 32F53 32F55 Set without 5.0 kg / 11.0 lbs Stand Set with 8.9 kg / 19.6 lbs Stand 40F53...
  • Page 11 2. Product specifications 2-1-2. Feature & Specifications Model UA32F55**A* / UA32F5300A* (M or W: DVB-T, K: DVB-T2, R: READY) Feature • Digital-TV, RF, 3-HDMI, 1-Component, 1-A/V, 2-USB2.0, LAN • Brightness : 300 cd/m • Dynamic Contrast Ratio : Mega Contrast •...
  • Page 12 2. Product specifications Model UA40F55**A* / UA40F53**A* (M or W: DVB-T, K: DVB-T2, R: READY) Feature • Digital-TV, RF, 3-HDMI, 1-Component, 1-A/V, 2-USB2.0, LAN • Brightness : 300 cd/m • Dynamic Contrast Ratio : Mega Contrast • Response Time : 6.5 ms •...
  • Page 13 2. Product specifications Model UA46F55**A* / UA46F53**A* (M or W: DVB-T, K: DVB-T2, R: READY) Feature • Digital-TV, RF, 3-HDMI, 1-Component, 1-A/V, 2-USB2.0, LAN • Brightness : 300 cd/m • Dynamic Contrast Ratio : Mega Contrast • Response Time : 6.5 ms •...
  • Page 14 2. Product specifications Model UA50F55**A* (M or W: DVB-T, K: DVB-T2, R: READY) Feature • Digital-TV, RF, 3-HDMI, 1-Component, 1-A/V, 2-USB2.0, LAN • Brightness : 300 cd/m • Dynamic Contrast Ratio : Mega Contrast • Response Time : 6.5 ms •...
  • Page 15 2. Product specifications Model UA32F45**A* (M or W: DVB-T, K: DVB-T2, R: READY) Feature • Digital-TV, RF, 3-HDMI, 1-Component, 1-A/V, 2-USB2.0, LAN • Brightness : 300 cd/m • Dynamic Contrast Ratio : Mega Contrast • Response Time : 6.5 ms •...

  • Page 16: Accessories

    2. Product specifications 2-2. Accessories Product Description Code. No Remark AA59-00790A (AU) Remote Control & Batteries AA59-00793A (NZ,SG) (AAA x 2) AA59-00797A (Etc.) 3903-000845 (AU,NZ) Power Cord 3903-000847 (SG) 3903-000849 (Etc.) BN68-04827A (AU) BN68-04827F (NZ) Owners Manual BN68-04827C (SG) BN68-04827B (Etc.)

  • Page 17: Disassembly And Reassembly

    3. Disassembly and Reassemble 3. Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the LED TV. This LED TV contains electrostatically sensitive devices. Use caution when handling these components. WARNING 3-1. Disassembly and Reassembly Disconnect the LED TV from the power source before disassembly.
  • Page 18 3. Disassembly and Reassemble Description Picture Description Screws Remove 15 screws of Rear Cover. 6003-001782 6003-002755 Remove the Cover Jack. Lift up Rear Cover slightly from the bottom.
  • Page 19 3. Disassembly and Reassemble Description Picture Description Screws Disconnect the Function Assy Cable. Remove the Rear Cover. Remove 9 screws of Main Board and Power Board. 6001-003016 Remove the Speakers and Power Cables.
  • Page 20 3. Disassembly and Reassemble Description Picture Description Screws Remove the LVDS Cable and Panel Drive Cable. Completed disassembly. NOTE Reassembly procedures are in the reverse order of disassembly procedures.
  • Page 21 ★ C 0.6 ± 0.1 CROSS #2(3.56) 3. Disassembly and Reassemble B 8.0R M4.0 x 1.8 RECESS TAPPING △ B-TYPE Screw Size „ CROSS #2(3.08 특수 Punch D:7.5 Code No. COLOR A (mm) B (mm) C (mm) Q'ty RECESS Screw Image M3 x 0.5 PITCH SCALOCK 32"...

  • Page 22: Assy Board P-Jog Switch & Ir

    3. Disassembly and Reassemble 3-2. Assy Board P-Jog Switch & Ir How to disassembly „ Description Picture Description Refer Loosen 2 screws. Pull out a jog function.
  • Page 23 3. Disassembly and Reassemble How to assembly „ Description Picture Description Refer Insert a jog function. Put 2 screws. When you want to ignore the funtion key actions Option 0 : New Function (Naviagtion) Key [ Default ] Control Config Option Navigation Key Func 1 : Old Function (Touch) Key Debug...

  • Page 24: Disassembly(Ptc)

    3. Disassembly and Reassemble 3-3. Disassembly(PTC) How to disassembly „ Description Picture Description Refer Place TV face up on cushioned table. Products at the top of the central TOP- CHASSIS is rotated by 45 degrees outward and pulls.
  • Page 25 3. Disassembly and Reassemble Description Picture Description Refer Pull in the same way from the center of the top. Pull the left part of the product as shown while holding the raised portion on figure 3. Pull the bottom part of the product as figure 2 while holding the raised portion on figure 4.
  • Page 26 3. Disassembly and Reassemble Description Picture Description Refer As shown in the picture, Lift the bottom of the TOP-CHASSIS. Pull the products at the bottom of the right side of the chassis. 3-10...
  • Page 27 3. Disassembly and Reassemble Description Picture Description Refer Lift the bottom of the chassis with one hand and holding the bottom of the product after you pull the right side of the product chassis. Disassembly is complete. CAUTION To use JIG : Does not lift the chassis by hand, JIG using the lift.

  • Page 28: Troubleshooting

    4. Troubleshooting 4. Troubleshooting 4-1. Troubleshooting Previous Check „ Check the various cable connections first. Check to see if there is a burnt or damaged cable. Check to see if there is a disconnected or loose cable connection. Check to see if the cables are connected according to the connection diagram. Check the power input to the Main Board.
  • Page 29 4. Troubleshooting Inside View „ Power Ass’y Main Ass’y 20P Cable LVDS T-Con Speaker...

  • Page 30: How To Check Fault Symptom

    4. Troubleshooting 4-2. How to Check Fault Symptom No Video (HDMI 1, 2, 3 - Digital Signal) „ *Refer to the next page to check the lacation such a CN201 or IC201 SVC Manual mentioned. • Audio is normal but no picture is displayed on the screen. Symptom •...
  • Page 31 4. Troubleshooting Location of Parts „ Main Board_Front Detail CN604_H4 : HDMI3 CN601_H1 : HDMI4 CN603_H3 : HDMI2 CN602_H2 : HDMI1...
  • Page 32 4. Troubleshooting WAVEFORMS „ HDMI input (RX_Data, RX_Clk) LVDS output...
  • Page 33 4. Troubleshooting No Video (Tuner_CVBS) „ *Refer to the next page to check the lacation such a CN201 or IC201 SVC Manual mentioned. Symptom • Audio is normal but no picture is displayed on the screen. • Check the Tuner CVBS source. •...
  • Page 34 4. Troubleshooting Location of Parts „ Main Board_Front Detail Pin #4 : B3.3V Pin #1 : B1.8V...
  • Page 35 4. Troubleshooting WAVEFORMS „ CVBS OUT (Grey Bar) LVDS output...
  • Page 36 4. Troubleshooting No Video (Tuner DTV) „ *Refer to the next page to check the lacation such a CN201 or IC201 SVC Manual mentioned. • Audio is normal but no picture is displayed on the screen. Symptom • Check the DTV source. Major •...
  • Page 37 4. Troubleshooting Location of Parts „ Main Board_Front Detail Pin #4 : B3.3V Pin #1 : B1.8V 4-10...
  • Page 38 4. Troubleshooting WAVEFORMS „ LVDS output CH_CLK, CH_VALID 4-11...
  • Page 39 4. Troubleshooting No Video (Video AV) „ *Refer to the next page to check the lacation such a CN201 or IC201 SVC Manual mentioned. • Audio is normal but no picture is displayed on the screen. Symptom • Check the Video CVBS source Major •...
  • Page 40 4. Troubleshooting Location of Parts „ Main Board_Front Detail R816 : COMP2_Y_CVBS 4-13...
  • Page 41 4. Troubleshooting WAVEFORMS „ CVBS OUT (Grey Bar) LVDS output 4-14...
  • Page 42 4. Troubleshooting No Video (Component) „ *Refer to the next page to check the lacation such a CN201 or IC201 SVC Manual mentioned. • Audio is normal but no picture is displayed on the screen. Symptom • Check the Component source. Major •...
  • Page 43 4. Troubleshooting Location of Parts „ Main Board_Front Detail R817 : COMP2_PB R816 : COMP2_Y_CVBS R815 : COMP2_PR 4-16...
  • Page 44 4. Troubleshooting WAVEFORMS „ Compnent_Y (Gray scale) / Pb / Pr (Color bar) LVDS output 4-17...
  • Page 45 4. Troubleshooting No Sound (1.Speaker 2.Monitor_out, 3.Optical)_X12 „ *Refer to the next page to check the lacation such a CN201 or IC201 SVC Manual mentioned. • Video is normal but there is no sound. Symptom • When the speaker connectors are disconnected or damaged. Major •...
  • Page 46 4. Troubleshooting Location of Parts „ Main Board_Front Detail Pin #20 : LRclk RA503 : COMP_L/R Pin #15 : Bclk Pin #23,#24 : I2C_SDA/SCL CN303_IBR: Monitor out_Sound OP301: Optical CN302 : SPK 4-19...
  • Page 47 4. Troubleshooting WAVEFORMS „ MCLK / LRCLK / PCM_I2C_DATA Speaker / Monitor OUT , SPDIF OUT 4-20...

  • Page 48: Factory Mode Adjustments

    4. Troubleshooting 4-3. Factory Mode Adjustments 4-3-1. Detail Factory Option NOTE If you replace the main board with new one, please change the factory option as well. The options you must change are "Type". 5500_5300 „ Model Name UA32F5*00 UA40F5*00 UA46F5*00 Vendor SHARP...
  • Page 49 4. Troubleshooting 5500, 5300, 4500 „ Model Name UA50F5*00 UA32F4500 Vendor BN07-01278A Panel Code BN07-01263A BN07-01278B HF500BGA-B1 Spec. HF320AGM-C1 HF500BGA-B2 SMPS PD Board BN44-00612A BN44-00604B Chassis Ass'y BN91-10323X BN91-10318F MAIN ASSY depend on country) PBA Ass'y code BN94-06364A BN94-06174F Byte Item Factory Reset 50R6AF0S...
  • Page 50 4. Troubleshooting 4-3-2. Entering Factory Mode To enter ‘Service Mode’ Press the remote -control keys in this sequence : • If you do not have Factory remote control Power OFF Info MENU MUTE Power On • If you have Factory remote control INFO Factory •...

  • Page 51: Factory Data

    4. Troubleshooting 4-3-3. Factory Data Note • Version of the software is written in 0002. • : I should not be possible to adjust or change that does not require a change item Black : Adjustment Services for the corresponding Blue : Items that are secured Option...
  • Page 52 4. Troubleshooting Factory Menu Data Range Remark Name Num of Display Num of IPTV Num of RUI Num of PVR RECORD TOOLS Support LNA Support 24Px4 Support BD Wise Support Data Service Support PVR Support CI Support LEDMotionPlus Support Natural Mode Support Relax Mode Support HDMI/DVI SEL...
  • Page 53 4. Troubleshooting Factory Menu Data Range Remark Name D AGC PH BW FQ BW PH RATE PD EN PEQ Inx WF Scale WF Type Nu of Network Stream DP V Size Backend Device FOX-FT1 BT_AUDIO_ON_ Config_AV_PATH ECO Standby Fast Logo Delay Num of PANEL KEY Control „...
  • Page 54 4. Troubleshooting Factory Menu Name Data Range Remark TTX Group Visual Test MediaPlayDB OPTION_SWU OTN Server Type operating OTN Test Server SWU Reset SWU Duration SWU Fail Test OPTION_NUM Num of ATV Num of SVIDEO Num of PC Num of DVI Num of OPTICAL Link Num of MEDIA Num of Tuner...
  • Page 55 4. Troubleshooting Factory Menu Name Data Range Remark PDP Option Pixel Shift Test Logic SW Panel Temperature LOGIC Waveform Day Logic CheckSum SAPC Timer APC Speed Hotel Option Hospitality Mode Power On … Menu OSD … Operation … Music Mode …...
  • Page 56 4. Troubleshooting Factory Menu Name Data Range Remark NICAM Prescale 0x48h BTSC Mono Prescale 0x19h BTSC stereo Prescale 0x2Fh BTSC SAP Prescale 0x2Bh A2Ident High THID A2Ident Low THID Pilot Level High Thld 0x28h Pilot Level Low Thld 0x10h Carrier2 Amp High THID Carrier2 Amp Low THID Carrier2 SNR High THR Carrier2 SNR Low THR...
  • Page 57 4. Troubleshooting Debug „ Factory Menu Name Data Range Remark Spread Spectrum LVDS Spread DDR Spread 1.0% Spectrum Period Amplitude HD SSC ON/Off HD SSC Value LVDS SSC ON/Off LVDS SSC Value DDR SSC ON/Off DDR SSC Value FRC LVDS SSC ON/OFF FRC LVDS SSC MRR FRC LVDS SSC MFR FRC LVDS SSC Period...
  • Page 58 4. Troubleshooting Factory Menu Name Data Range Remark H.264 Margin CAM Wait Time TS Clock deldy TCON_TEMP READ TEMP LAST DCC VERSION DCC CHK SEL DCC CHECK LOCAL DCC CHECK TOTAL MulitACC Checksum IIC Bus stop Tuner Status Signal Strength Bandwidth Frequency LNA Status...
  • Page 59 4. Troubleshooting Factory Menu Name Data Range Remark Guard Interval_1 Freq. Offset_1 SNR_1 IF AGC_1 TMCC Lock_1 TS Packer_1 Master Lock_1 A_Modulation_1 A_Code Rate_1 A_Timer InterLeave_1 A_Segments Num_1 A_BER_1 B_Modulation_1 B_Code Rate_1 B_Timer InterLeave_1 B_Segments Num_1 B_BER_1 C_Modulation_1 C_Code Rate_1 C_Timer InterLeave_1 C_Segments Num_1 C_BER_1...
  • Page 60 4. Troubleshooting Factory Menu Name Data Range Remark HDMI WB Pattern HDMI Pattern Sel Parma Pre Test Pattern Parma Post Test Pattern Panel Display Time SVC Info Delete S/N Upgrade T-CON Usb Download Failute T-CON CheckSum Error Logic Usb D/L …...
  • Page 61 4. Troubleshooting Factory Menu Name Data Range Remark Self Diagnosis Loop Back LAN Test AV Audio Test DVIN Audio Test CVBS Test COMP Test USB HUB Test HDMI Test SCART Audio Test SCART CVBS Test SCART RGB Test FLASH EEPROM Sound AMP HDMI Switch IC USB HUB IC...
  • Page 62 4. Troubleshooting Factory Menu Name Data Range Remark DVB CI CAL Data Backup … CAL Data Restore … ADC/WB „ Factory Menu Name Data Range Remark AV Calibration Success Comp Calibration Success PC Calibration Success HDMI Calibration Success ADC Result 1st_Y_GH 1st_Y_GL 1st_Cb_BH...
  • Page 63 4. Troubleshooting Factory Menu Name Data Range Remark WB_N_R_Gain WB_N_B_Gain MGA On/Off R1_Gain … B1_Gain … G1_Gain … R2_Gain … B2_Gain … G2_Gain … R3_Gain … B3_Gain … G3_Gain … R4_Gain … B4_Gain … G4_Gain … R5_Gain … B5_Gain … G5_Gain …...

  • Page 64: White Balance

    4. Troubleshooting 4-4. White Balance 4-4-1. Calibration Into the Factory Mode. Select Menu. ADC/WB Select menu. Select menu. Option Control Debug AV Calibration ADC/WB Comp Calibration Advanced PC Calibration HDMI Calibration 4-4-2. Service Adjustment You must perform Calibration in the Lattice Pattern before adjusting the White Balance. Color Calibration „...
  • Page 65 4. Troubleshooting Method of Color Calibration (AV) „ Apply the NTSC Lattice (N0. 3) pattern signal to the AV IN 1 port. Press the Source key to switch to “AV1” mode. Enter Service mode. Select the “ADC” menu. Select the “AV Calibration” menu. In “AV Calibration Off”...
  • Page 66 4. Troubleshooting 4-4-3. Adjustment Into the Factory Mode. Select Menu. ADC/WB Select menu. Select White Balance menu. Option Control Debug (low light) (hight light) Sub Bright Sub Contrast White Balance ADC/WB R offset R gain Advanced G offset G gain B offset B gain 4-39...

  • Page 67: White Ratio (Balance) Adjustment

    4. Troubleshooting 4-5. White Ratio (Balance) Adjustment You can adjust the white ratio in factory mode (1:Calibration, 3:White-Balance). Since the adjustment value and the data value vary depending on the input source, you have to adjust these in CVBS, Component 1 and HDMI 1 modes. The optimal values for each mode are configured by default.
  • Page 68 4. Troubleshooting Gray Check Adjust Spec(xyL) 2nd Adjust Spec(xyL) Levels Code Check x(±) y(±) L(±) x(±) y(±) L(±) 10 IRE 0x01 0.007 0.007 0.11 0.007 0.007 0.11 20 IRE 0x02 0.007 0.007 0.08 0.007 0.007 0.08 30 IRE 0x03 0.007 0.007 0.06 0.007...

  • Page 69: Detail Specifications

    4. Troubleshooting 4-6. Detail Specifications 4-6-1. UA**F5500A*_UA**F5300AM_1 General Information • UA**F5500AMXXY UA**F5500AMXRD Item UA**F5500AKXXS UA**F5300AMXXY UA**F5300AMXRD Product Cabinet Basic Code Series Series Name LED F5500 / F5300 LED F5500 / F5300 LED F5500 / F5300 Country AUSTRALIA NEW ZEALAND SINGAPORE Tools Support Platform(TV) Mstar | X12...
  • Page 70 TI | TAS5745 Speaker Volume 10W +10W 10Wx2 10W +10W Woofer Speaker Volume Analog Digital Optical Optical • SMART TV Functionality UA**F5500AMXXY UA**F5500AMXRD Item UA**F5500AKXXS UA**F5300AMXXY UA**F5300AMXRD Samsung SMART TV Smart Guide Family Story Movie & TV Shows Fitness Apps Kids 4-43...
  • Page 71 Samsung SMART View Yes (Clone View only) Yes (Clone View only) Yes (Clone View only) Smart Hub Search All Your Video Social TV Samsung Sports Experience (SSE) Samsung Apps Smart Scene Skype™ on Samsung TV Web Browser AllShare Control Recommendation Bar •...
  • Page 72 Wireless LAN Adaptor Support ISP Bound Service BT HID Built-in USB HID Support OSD Language Local Languages Local Languages Local Languages Samsung IR Blaster Support User Interface Golden Bridge Golden Bridge Golden Bridge Digital Noise Filter Analog Signal Booster Network Speaker Support...
  • Page 73 Paratal Lock Kids Lock Media Play(USB & DLNA) Bluetooth Home Network Centre Zero Stand-By Power USB Copy IP Video Closed Caption • Additional Feature UA**F5500AMXXY UA**F5500AMXRD Item UA**F5500AKXXS UA**F5300AMXXY UA**F5300AMXRD Self Diagnosis Software Upgrade HD Connection Guide Contact Samsung 4-46...
  • Page 74 Dolby Dolby Dolby Tuner Vendor & Model • Core Component UA**F5500AMXXY UA**F5500AMXRD Item UA**F5500AKXXS UA**F5300AMXXY UA**F5300AMXRD DDR SDRAM Samsung Samsung Samsung Nand Flash Memory Samsung Samsung Samsung OneNand Flash Memory FlexOneNand Flash Memory Serial Flash Memory WINBOND WINBOND WINBOND HDMI Switch Display Device Vender •...
  • Page 75 4. Troubleshooting DVI Port Port1 Type Port1 Type Port1 Type PC Resolution 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz MHL Port HDMI/DVI SEL Port 1 Type Host Host Host Port 2 Type Host Host...
  • Page 76 4. Troubleshooting • Design UA**F5500AMXXY UA**F5500AMXRD Item UA**F5500AKXXS UA**F5300AMXXY UA**F5300AMXRD Design Logo Deco Logo Deco Logo Deco Bezel Type Slim Type Slim 1 Slim 1 Slim 1 Front Color Black Black Black Light Effect (Deco) Stand Type Quad Quad Quad Swivel (Left/Right) Push &...
  • Page 77 4. Troubleshooting • Dimension (WxHxD) UA**F5500AMXXY UA**F5500AMXRD Item UA**F5500AKXXS UA**F5300AMXXY UA**F5300AMXRD Set Size without Stand (mm) Set Size with Stand (mm) Package Size (mm) Weight • UA**F5500AMXXY UA**F5500AMXRD Item UA**F5500AKXXS UA**F5300AMXXY UA**F5300AMXRD Set Weight without Stand (kg) Set Weight with Stand (kg) Package Weight (kg) •...
  • Page 78 4. Troubleshooting • License UA**F5500AMXXY UA**F5500AMXRD Item UA**F5500AKXXS UA**F5300AMXXY UA**F5300AMXRD Oracle JAVA Universial Remote Control MS DRM Movie Codec DivX DivX DivX 4-6-2. UA**F5500AM_UA**F5300AM_2 • General Information UA**F5500AMXHC UA**F5500AMXSQ Item UA**F5500AMXXD UA**F5300AMXHC UA**F5300AMXSQ Product Cabinet Basic Code Series Series Name LED F5500 / F5300 LED F5500 / F5300 LED F5500 / F5300...
  • Page 79 Sound Amp IC TI | TAS5745 TI | TAS5745 TI | TAS5745 Speaker Volume 10W +10W 10W +10W 10W +10W Woofer Speaker Volume Analog Digital Optical Optical Optical • SMART TV Functionality UA**F5500AMXHC UA**F5500AMXSQ Item UA**F5500AMXXD UA**F5300AMXHC UA**F5300AMXSQ Samsung SMART TV 4-52...
  • Page 80 Yes (Clone View only) Yes (Clone View only) Yes (Clone View only) Smart Hub Search All Your Video Social TV Samsung Sports Experience (SSE) Samsung Apps Smart Scene Skype™ on Samsung TV Web Browser AllShare Control Recommendation Bar VESA Standard •...
  • Page 81 Wireless LAN Adaptor Support ISP Bound Service BT HID Built-in USB HID Support OSD Language Local Languages Local Languages Local Languages Samsung IR Blaster Support User Interface Golden Bridge Golden Bridge Golden Bridge Digital Noise Filter Analog Signal Booster Network Speaker Support...
  • Page 82 4. Troubleshooting Teletext (TTX) Triple Protector Miracast Anynet+ (HDMI-CEC) BD Wise Plus Auto Channel Search Auto Power Off Auto Volume Leveler Caption (Subtitle) 2 Tuner Clock&On/Off Timer Game Mode Battery Ready Picture-In-Picture Sleep Timer Screen Burn Protection Channel List USB-Clone V-Chip Embeded POP Calibration Mode...
  • Page 83 4. Troubleshooting HD Connection Guide Contact Samsung • UA**F5500AMXHC UA**F5500AMXSQ Item UA**F5500AMXXD UA**F5300AMXHC UA**F5300AMXSQ Linux Linux Linux • System UA**F5500AMXHC UA**F5500AMXSQ Item UA**F5500AMXXD UA**F5300AMXHC UA**F5300AMXSQ DTV Tuner DVB-T/C DVB-T/C DVB-T/C Analog Tuner CI/CI+ MHP / MHEG (version) / ACAP NTSC 3.58...
  • Page 84 4. Troubleshooting • Input & Output UA**F5500AMXHC UA**F5500AMXSQ Item UA**F5500AMXXD UA**F5300AMXHC UA**F5300AMXSQ HDMI 1920 x 1080i 60,1920 x 1080i 1920 x 1080i 60,1920 x 1080i 1920 x 1080i 60,1920 x 1080i Resolution DVI Port Port1 Type Port1 Type Port1 Type PC Resolution 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz...
  • Page 85 4. Troubleshooting DVI Port Port1 Type Port1 Type Port1 Type PC Resolution 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz D-Sub Resolution N/A | N/A N/A | N/A N/A | N/A •...
  • Page 86 4. Troubleshooting • Security UA**F5500AMXHC UA**F5500AMXSQ Item UA**F5500AMXXD UA**F5300AMXHC UA**F5300AMXSQ Kensington Lock • Dimension (WxHxD) UA**F5500AMXHC UA**F5500AMXSQ Item UA**F5500AMXXD UA**F5300AMXHC UA**F5300AMXSQ Set Size without Stand (mm) Set Size with Stand (mm) Package Size (mm) • Weight UA**F5500AMXHC UA**F5500AMXSQ Item UA**F5500AMXXD UA**F5300AMXHC UA**F5300AMXSQ Set Weight without Stand (kg)
  • Page 87 4. Troubleshooting Power Cable User Manual E-Manual Floor Stand Support • License UA**F5500AMXHC UA**F5500AMXSQ Item UA**F5500AMXXD UA**F5300AMXHC UA**F5300AMXSQ Oracle JAVA Universial Remote Control MS DRM Movie Codec DivX DivX DivX 4-6-3. UA**F5500AK_UA**F5*00AW_UA32F4500AM - 3 • General Information UA**F5500AWXMV Item UA**F5500AKXKE UA32F4500AMXXY UA**F5300AWXMV Product...
  • Page 88 4. Troubleshooting Clear Motion Rate 600Hz Subfield Motion Dynamic Contrast Ratio Mega Contrast Mega Contrast Mega Contrast New Picture Differentiation Micro Dimming Cinema Smooth Precision Black (Local Dimming) Wide Color Enhancer (Plus) Auto Motion Plus 120/240Hz Motion Judder Canceller Film Mode Brightness Contrast Ratio 4000:1...
  • Page 89 Yes (Clone View only) Yes (Clone View only) Yes (Clone View only) Smart Hub Search All Your Video Social TV Samsung Sports Experience (SSE) Samsung Apps Smart Scene Skype™ on Samsung TV Web Browser AllShare Control Recommendation Bar VESA Standard •...
  • Page 90 4. Troubleshooting Camera App HM App Samsung TV Apps supported • Feature UA**F5500AWXMV Item UA**F5500AKXKE UA32F4500AMXXY UA**F5300AWXMV Samsung 3D 3D Converter Dual View Samsung One Line History MultiTasking Smart Phone Remote support Smart Evolution Support Extended PVR Time Shift Allshare Play AllShare Cloud Storage ConnectShare™...
  • Page 91 4. Troubleshooting HDMI 1.4 3D Auto Setting HDMI 1.4 A/Return Ch. Support Analog Clean View HbbTV Teletext (TTX) Triple Protector Miracast Anynet+ (HDMI-CEC) BD Wise Plus Auto Channel Search Auto Power Off Auto Volume Leveler Caption (Subtitle) 2 Tuner Clock&On/Off Timer Game Mode Battery Ready Picture-In-Picture...
  • Page 92 4. Troubleshooting • Additional Feature UA**F5500AWXMV Item UA**F5500AKXKE UA32F4500AMXXY UA**F5300AWXMV Self Diagnosis Software Upgrade HD Connection Guide Contact Samsung • UA**F5500AWXMV Item UA**F5500AKXKE UA32F4500AMXXY UA**F5300AWXMV Linux Linux Linux • System UA**F5500AWXMV Item UA**F5500AKXKE UA32F4500AMXXY UA**F5300AWXMV DTV Tuner DVB-T2/C DVB-T/C DVB-T/C...
  • Page 93 4. Troubleshooting Display Device Vender • Input & Output UA**F5500AWXMV Item UA**F5500AKXKE UA32F4500AMXXY UA**F5300AWXMV HDMI 1920 x 1080i 60,1920 x 1080i 1920 x 1080i 60,1920 x 1080i 1920 x 1080i 60,1920 x 1080i Resolution DVI Port Port1 Type Port1 Type Port1 Type PC Resolution 1920 x 1080 | 60 Hz...
  • Page 94 4. Troubleshooting 1920 x 1080i 60,1920 x 1080i Resolution 1920 x 1080i 60 1920 x 1080i 60 DVI Port Port1 Type Port1 Type Port1 Type PC Resolution 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz D-Sub Resolution N/A | N/A N/A | N/A...
  • Page 95 4. Troubleshooting Frequency (Hz) 50/60Hz 50/60Hz 50/60Hz SMPS/IP Board DongYang E&P Security • UA**F5500AWXMV Item UA**F5500AKXKE UA32F4500AMXXY UA**F5300AWXMV Kensington Lock • Dimension (WxHxD) UA**F5500AWXMV Item UA**F5500AKXKE UA32F4500AMXXY UA**F5300AWXMV Set Size without Stand (mm) Set Size with Stand (mm) Package Size (mm) •...
  • Page 96 4. Troubleshooting Electric Stand Support Slim Gender Cable ANT-Cable Power Cable User Manual E-Manual Floor Stand Support • License UA**F5500AWXMV Item UA**F5500AKXKE UA32F4500AMXXY UA**F5300AWXMV Oracle JAVA Universial Remote Control MS DRM Movie Codec DivX DivX 4-6-4. UA32F4500A* - 4 • General Information Item UA32F4500AMXRD...
  • Page 97 4. Troubleshooting • Video Item UA32F4500AMXRD UA32F4500AKXXS UA32F4500AMXHC Picture Engine HyperReal Engine HyperReal Engine HyperReal Engine OLED Motion Rate Clear Motion Rate 600Hz Subfield Motion Dynamic Contrast Ratio Mega Contrast Mega Contrast Mega Contrast New Picture Differentiation Micro Dimming Cinema Smooth Precision Black (Local Dimming) Wide Color Enhancer (Plus) Auto Motion Plus 120/240Hz...
  • Page 98 Samsung SMART View Yes (Clone View only) Yes (Clone View only) Yes (Clone View only) Smart Hub Search All Your Video Social TV Samsung Sports Experience (SSE) Samsung Apps Smart Scene Skype™ on Samsung TV Web Browser AllShare Control Recommendation Bar •...
  • Page 99 4. Troubleshooting VM App NLU (Natural Language Understanding) Camera App HM App Samsung TV Apps supported Feature • Item UA32F4500AMXRD UA32F4500AKXXS UA32F4500AMXHC Samsung 3D 3D Converter Dual View Samsung One Line History MultiTasking Smart Phone Remote support Smart Evolution Support...
  • Page 100 4. Troubleshooting InstaPort S (HDMI quick switch) HDMI 1.4 3D Auto Setting HDMI 1.4 A/Return Ch. Support Analog Clean View HbbTV Teletext (TTX) Triple Protector Miracast Anynet+ (HDMI-CEC) BD Wise Plus Auto Channel Search Auto Power Off Auto Volume Leveler Caption (Subtitle) 2 Tuner Clock&On/Off Timer...
  • Page 101 4. Troubleshooting IP Video Closed Caption • Additional Feature Item UA32F4500AMXRD UA32F4500AKXXS UA32F4500AMXHC Self Diagnosis Software Upgrade HD Connection Guide Contact Samsung • Item UA32F4500AMXRD UA32F4500AKXXS UA32F4500AMXHC Linux Linux Linux • System Item UA32F4500AMXRD UA32F4500AKXXS UA32F4500AMXHC DTV Tuner DVB-T/C DVB-T2/C...
  • Page 102 4. Troubleshooting Display Device Vender • Input & Output Item UA32F4500AMXRD UA32F4500AKXXS UA32F4500AMXHC HDMI 1920 x 1080i 60,1920 x 1080i 1920 x 1080i 60,1920 x 1080i 1920 x 1080i 60,1920 x 1080i Resolution DVI Port Port1 Type Port1 Type Port1 Type PC Resolution 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz...
  • Page 103 4. Troubleshooting Monitor Output 1920 x 1080i 60,1920 x 1080i 1920 x 1080i 60,1920 x 1080i 1920 x 1080i 60,1920 x 1080i Resolution DVI Port Port1 Type Port1 Type Port1 Type PC Resolution 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz D-Sub Resolution N/A | N/A...
  • Page 104 4. Troubleshooting SMPS/IP Board DongYang E&P DongYang E&P DongYang E&P • Security Item UA32F4500AMXRD UA32F4500AKXXS UA32F4500AMXHC Kensington Lock • Dimension (WxHxD) Item UA32F4500AMXRD UA32F4500AKXXS UA32F4500AMXHC Set Size without Stand (mm) Set Size with Stand (mm) Package Size (mm) • Weight Item UA32F4500AMXRD UA32F4500AKXXS...
  • Page 105 4. Troubleshooting User Manual E-Manual Floor Stand Support • License Item UA32F4500AMXRD UA32F4500AKXXS UA32F4500AMXHC Oracle JAVA Universial Remote Control MS DRM Movie Codec 4-6-5. UA32F4500A* - 5 General Information • Item UA32F4500AMXSQ UA32F4500AMXXD UA32F4500AWXMV Product Cabinet Basic Code Series Series Name LED F4500 LED F4500 LED F4500...
  • Page 106 4. Troubleshooting Dynamic Contrast Ratio Mega Contrast Mega Contrast Mega Contrast New Picture Differentiation Micro Dimming Cinema Smooth Precision Black (Local Dimming) Wide Color Enhancer (Plus) Auto Motion Plus 120/240Hz Motion Judder Canceller Film Mode Brightness Contrast Ratio 4000:1 4000:1 4000:1 WSS,Film Mode,HDMI Black WSS,Film Mode,HDMI Black...
  • Page 107 Samsung SMART View Yes (Clone View only) Yes (Clone View only) Yes (Clone View Only) Smart Hub Search All Your Video Social TV Samsung Sports Experience (SSE) Samsung Apps Smart Scene Skype™ on Samsung TV Web Browser AllShare Control Recommendation Bar •...
  • Page 108 4. Troubleshooting Samsung TV Apps supported • Feature Item UA32F4500AMXSQ UA32F4500AMXXD UA32F4500AWXMV Samsung 3D 3D Converter Dual View Samsung One Line History MultiTasking Smart Phone Remote support Smart Evolution Support Extended PVR Time Shift Allshare Play AllShare Cloud Storage ConnectShare™ (USB2.0)
  • Page 109 4. Troubleshooting Analog Clean View HbbTV Teletext (TTX) Triple Protector Miracast Anynet+ (HDMI-CEC) BD Wise Plus Auto Channel Search Auto Power Off Auto Volume Leveler Caption (Subtitle) 2 Tuner Clock&On/Off Timer Game Mode Battery Ready Picture-In-Picture Sleep Timer Screen Burn Protection Channel List USB-Clone V-Chip Embeded POP...
  • Page 110 4. Troubleshooting Software Upgrade HD Connection Guide Contact Samsung • Item UA32F4500AMXSQ UA32F4500AMXXD UA32F4500AWXMV Linux Linux Linux • System Item UA32F4500AMXSQ UA32F4500AMXXD UA32F4500AWXMV DTV Tuner DVB-T/C DVB-T/C DVB-T/C Analog Tuner CI/CI+ CI+ (1.3) MHP / MHEG (version) / ACAP NTSC 3.58...
  • Page 111 4. Troubleshooting 1920 x 1080i 60,1920 x 1080i 1920 x 1080i 60,1920 x 1080i 1920 x 1080i 60,1920 x 1080i Resolution DVI Port Port1 Type Port1 Type Port1 Type PC Resolution 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz MHL Port HDMI/DVI SEL...
  • Page 112 4. Troubleshooting • Design Item UA32F4500AMXSQ UA32F4500AMXXD UA32F4500AWXMV Design Bezel Type Slim Type Slim 1 Slim 1 Slim 1 Front Color Black Black Black Light Effect (Deco) Stand Type Arch Arch Arch Swivel (Left/Right) Push & Pull Camera Design Name Design Steam Mold Steam Mold...
  • Page 113 4. Troubleshooting • Dimension (WxHxD) Item UA32F4500AMXSQ UA32F4500AMXXD UA32F4500AWXMV Set Size without Stand (mm) Set Size with Stand (mm) Package Size (mm) Weight • Item UA32F4500AMXSQ UA32F4500AMXXD UA32F4500AWXMV Set Weight without Stand (kg) Set Weight with Stand (kg) Package Weight (kg) •...
  • Page 114 4. Troubleshooting Oracle JAVA Universial Remote Control MS DRM Movie Codec 4-6-6. UA32F4500AK_ UA32F5*00AR - 6 General Information • UA**F5500ARXXZ Item UA32F4500AKXKE UA**F5500ARXXT UA**F5300ARXXZ Product Cabinet Basic Code Series Series Name LED F4500 LED F5500 LED F5500 Country KENYA THAILAND CHINA Tools Support Platform(TV)
  • Page 115 Speaker Volume 10W + 10W 10W x 2 10W x 2 Woofer Speaker Volume Analog Digital Optical Optical Optical • SMART TV Functionality UA**F5500ARXXZ Item UA32F4500AKXKE UA**F5500ARXXT UA**F5300ARXXZ Samsung SMART TV Smart Guide Family Story Movie & TV Shows 4-88...
  • Page 116 Samsung SMART View Yes (Clone View only) Yes (Clone View only) Yes (Clone View only) Smart Hub Search All Your Video Social TV Samsung Sports Experience (SSE) Samsung Apps Smart Scene Skype™ on Samsung TV Web Browser AllShare Control Recommendation Bar •...
  • Page 117 Wireless LAN Adaptor Support ISP Bound Service BT HID Built-in USB HID Support OSD Language Local Languages Local Languages Local Languages Samsung IR Blaster Support User Interface Golden Bridge Golden Bridge Golden Bridge Digital Noise Filter Analog Signal Booster Network Speaker Support...
  • Page 118 4. Troubleshooting Teletext (TTX) Triple Protector Miracast Anynet+ (HDMI-CEC) BD Wise Plus Auto Channel Search Auto Power Off Auto Volume Leveler Caption (Subtitle) 2 Tuner Clock&On/Off Timer Game Mode Battery Ready Picture-In-Picture Sleep Timer Screen Burn Protection Channel List USB-Clone V-Chip Embeded POP Calibration Mode...
  • Page 119 4. Troubleshooting HD Connection Guide Contact Samsung • UA**F5500ARXXZ Item UA32F4500AKXKE UA**F5500ARXXT UA**F5300ARXXZ Linux Linux Linux • System UA**F5500ARXXZ Item UA32F4500AKXKE UA**F5500ARXXT UA**F5300ARXXZ DTV Tuner DVB-T2/C Ready Ready Analog Tuner CI/CI+ CI+ (1.3) MHP / MHEG (version) / ACAP NTSC 3.58 AV only NTSC 4.43, VIT...
  • Page 120 4. Troubleshooting • Input & Output UA**F5500ARXXZ Item UA32F4500AKXKE UA**F5500ARXXT UA**F5300ARXXZ HDMI 1920 x 1080i 60,1920 x 1080i Resolution 1920 x 1080 1920 x 1080 DVI Port Port1 Type Port1 Type Port1 Type PC Resolution 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz MHL Port...
  • Page 121 4. Troubleshooting 1920 x 1080i 60,1920 x 1080i Resolution 1920 x 1080i 60 1920 x 1080i 60 DVI Port Port1 Type Port1 Type Port1 Type PC Resolution 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz D-Sub Resolution N/A | N/A N/A | N/A...
  • Page 122 4. Troubleshooting SMPS/IP Board DongYang E&P • Security UA**F5500ARXXZ Item UA32F4500AKXKE UA**F5500ARXXT UA**F5300ARXXZ Kensington Lock • Dimension (WxHxD) UA**F5500ARXXZ Item UA32F4500AKXKE UA**F5500ARXXT UA**F5300ARXXZ Set Size without Stand (mm) Set Size with Stand (mm) Package Size (mm) • Weight UA**F5500ARXXZ Item UA32F4500AKXKE UA**F5500ARXXT UA**F5300ARXXZ...
  • Page 123 4. Troubleshooting Slim Gender Cable ANT-Cable Power Cable User Manual E-Manual Floor Stand Support • License UA**F5500ARXXZ Item UA32F4500AKXKE UA**F5500ARXXT UA**F5300ARXXZ Oracle JAVA Universial Remote Control MS DRM Movie Codec DivX DivX 4-6-7. UA**F5*00AR - 7 • General Information UA**F5500ARXZN Item UA**F5500ARLXL UA**F5500ARXSJ...
  • Page 124 4. Troubleshooting UA**F5500ARXZN Item UA**F5500ARLXL UA**F5500ARXSJ UA**F5300ARXZN Picture Engine HyperReal Engine HyperReal Engine HyperReal Engine OLED Motion Rate Clear Motion Rate 600Hz Subfield Motion Dynamic Contrast Ratio Mega Contrast Mega Contrast Mega Contrast New Picture Differentiation Micro Dimming Cinema Smooth Precision Black (Local Dimming) Wide Color Enhancer (Plus) Auto Motion Plus 120/240Hz...
  • Page 125 Yes (Clone View only) Yes (Clone View only) Yes (Clone View only) Smart Hub Search All Your Video Social TV Samsung Sports Experience (SSE) Samsung Apps Smart Scene Skype™ on Samsung TV Web Browser AllShare Control Recommendation Bar VESA Standard •...
  • Page 126 4. Troubleshooting VM App NLU (Natural Language Understanding) Camera App HM App Samsung TV Apps supported Feature • UA**F5500ARXZN Item UA**F5500ARLXL UA**F5500ARXSJ UA**F5300ARXZN Samsung 3D 3D Converter Dual View Samsung One Line History MultiTasking Smart Phone Remote support Smart Evolution Support...
  • Page 127 4. Troubleshooting Regional EQ InstaPort S (HDMI quick switch) HDMI 1.4 3D Auto Setting HDMI 1.4 A/Return Ch. Support Analog Clean View HbbTV Teletext (TTX) Triple Protector Yes (Pakistan Only) Miracast Anynet+ (HDMI-CEC) BD Wise Plus Auto Channel Search Auto Power Off Auto Volume Leveler Caption (Subtitle) 2 Tuner...
  • Page 128 4. Troubleshooting IP Video Closed Caption • Additional Feature UA**F5500ARXZN Item UA**F5500ARLXL UA**F5500ARXSJ UA**F5300ARXZN Self Diagnosis Software Upgrade HD Connection Guide Contact Samsung • UA**F5500ARXZN Item UA**F5500ARLXL UA**F5500ARXSJ UA**F5300ARXZN Linux Linux Linux • System UA**F5500ARXZN Item UA**F5500ARLXL UA**F5500ARXSJ UA**F5300ARXZN DTV Tuner...
  • Page 129 4. Troubleshooting FlexOneNand Flash Memory Serial Flash Memory HDMI Switch Display Device Vender Panel Allocation. Panel Allocation. Panel Allocation. • Input & Output UA**F5500ARXZN Item UA**F5500ARLXL UA**F5500ARXSJ UA**F5300ARXZN HDMI Resolution 1920 x 1080 1920 x 1080 1920 x 1080 DVI Port Port1 Type Port1 Type Port1 Type...
  • Page 130 4. Troubleshooting Coaxial EX-Link Monitor Output Resolution 1920 x 1080i 60 1920 x 1080i 60 1920 x 1080i 60 DVI Port Port1 Type Port1 Type Port1 Type PC Resolution 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz D-Sub Resolution N/A | N/A...
  • Page 131 4. Troubleshooting Peak Luminance Ratio Yearly Power Consumption (EU standard) Frequency (Hz) 50/60Hz 50/60Hz 50/60Hz SMPS/IP Board • Security UA**F5500ARXZN Item UA**F5500ARLXL UA**F5500ARXSJ UA**F5300ARXZN Kensington Lock • Dimension (WxHxD) UA**F5500ARXZN Item UA**F5500ARLXL UA**F5500ARXSJ UA**F5300ARXZN Set Size without Stand (mm) Set Size with Stand (mm) Package Size (mm) •...
  • Page 132 4. Troubleshooting VESA Wall Mount Support Electric Wall Mount Support Electric Stand Support Slim Gender Cable ANT-Cable Power Cable User Manual E-Manual Floor Stand Support • License UA**F5500ARXZN Item UA**F5500ARLXL UA**F5500ARXSJ UA**F5300ARXZN Oracle JAVA Universial Remote Control MS DRM Movie Codec DivX DivX DivX...
  • Page 133 4. Troubleshooting • Video Item UA**F5520ARXZN UA50F5500ARX** Picture Engine HyperReal Engine HyperReal Engine OLED Motion Rate Clear Motion Rate 600Hz Subfield Motion Dynamic Contrast Ratio Mega Contrast Mega Contrast New Picture Differentiation Micro Dimming Cinema Smooth Precision Black (Local Dimming) Wide Color Enhancer (Plus) Auto Motion Plus 120/240Hz Motion Judder Canceller...
  • Page 134 Yes (Clone View only) Yes (Clone View only) Smart Hub Search All Your Video Social TV Samsung Sports Experience (SSE) Samsung Apps Smart Scene Skype™ on Samsung TV Web Browser AllShare Control Recommendation Bar • VESA Standard Item UA**F5520ARXZN UA50F5500ARX** Samsung SMART TV Smart Interaction •...
  • Page 135 4. Troubleshooting NLU (Natural Language Understanding) Camera App HM App Samsung TV Apps supported • Feature Item UA**F5520ARXZN UA50F5500ARX** Samsung 3D 3D Converter Dual View Samsung One Line History MultiTasking Smart Phone Remote support Smart Evolution Support Extended PVR Time Shift...
  • Page 136 4. Troubleshooting InstaPort S (HDMI quick switch) HDMI 1.4 3D Auto Setting HDMI 1.4 A/Return Ch. Support Analog Clean View HbbTV Teletext (TTX) Triple Protector Yes (Pakistan Only) Miracast Anynet+ (HDMI-CEC) BD Wise Plus Auto Channel Search Auto Power Off Auto Volume Leveler Caption (Subtitle) 2 Tuner...
  • Page 137 4. Troubleshooting • Additional Feature Item UA**F5520ARXZN UA50F5500ARX** Self Diagnosis Software Upgrade HD Connection Guide Contact Samsung • Item UA**F5520ARXZN UA50F5500ARX** Linux Linux • System Item UA**F5520ARXZN UA50F5500ARX** DTV Tuner Ready Ready Analog Tuner CI/CI+ MHP / MHEG (version) / ACAP NTSC 3.58...
  • Page 138 4. Troubleshooting • Input & Output Item UA**F5520ARXZN UA50F5500ARX** HDMI Resolution 1920 x 1080 1920 x 1080 DVI Port Port1 Type Port1 Type PC Resolution 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz MHL Port HDMI/DVI SEL Port 1 Type Host Host...
  • Page 139 4. Troubleshooting PC Resolution 1920 x 1080 | 60 Hz 1920 x 1080 | 60 Hz D-Sub Resolution N/A | N/A N/A | N/A Design • Item UA**F5520ARXZN UA50F5500ARX** Design Logo Deco Logo Deco Bezel Type Slim Type Slim 1 Slim 1 Front Color Black...
  • Page 140 4. Troubleshooting • Security Item UA**F5520ARXZN UA50F5500ARX** Kensington Lock • Dimension (WxHxD) Item UA**F5520ARXZN UA50F5500ARX** Set Size without Stand (mm) Set Size with Stand (mm) Package Size (mm) • Weight Item UA**F5520ARXZN UA50F5500ARX** Set Weight without Stand (kg) Set Weight with Stand (kg) Package Weight (kg) •...
  • Page 141 4. Troubleshooting Floor Stand Support • License Item UA**F5520ARXZN UA50F5500ARX** Oracle JAVA Universial Remote Control MS DRM Movie Codec DivX 4-114...

  • Page 142: Software Upgrade

    4. Troubleshooting 4-7. Software Upgrade Software Upgrade can be performed by downloading the. latest firmware from samsung.com to a USB memory device. • Current Version - The software already installed in the TV. Software is represented as ‘Year/Month/Day_Version’. 4-7-1. How to Check the Software Version Use the Main Menu „...
  • Page 143 4. Troubleshooting Use the Factory Mode „ Access the factory mode T-MST12UABC-xxxx Option T-MST12DEUS-xxxx Control BT Version : xxxx Debug Camera Version : xxxx E-Manual : xxxx EDID SUCCESS ADC/WB CALIB : AV/COMP/PC/HDMI/ Advanced Option : 40H6AF0S,AD_AU_NZ2,5500,NONE USB RS232C : OFF SDAL-X12-MAIN-xxxx-xxxx RFS : "X12 0071"...
  • Page 144 4-7-2. How to Upgade Software and Micom Insert a USB drive containing the firmware upgrade downloaded from samsung.com into the TV. Please be careful not to disconnect the power or remove the USB drive while upgrades are being applied. The TV will turn off and turn on automatically after completing the firmware upgrade.

  • Page 145: Rear Cover Dimension

    4. Troubleshooting 4-8. Rear Cover Dimension 4500 „ SET Size (With Stand) 750.9 * 476.9 * 207.8 SET Size (Without Stand) 750.9 * 456.6 * 59.3 Packing Size 835 * 657 * 143 W / W NET (SET) Weight (With Stand) 5.6 kg NET (SET) Weight (Without Stand) 5.3 kg...
  • Page 146 4. Troubleshooting 5300 „ BASIC SPEC AREA 32" 40" SET w/o Stand (W * H 738.0 * 445.4 * 49.0 928.2*612.2*235.0 * D) (mm) SET with Stand (W * H 738.0 * 505.8 * 191.7 928.2*552.3*49.4 * D) (mm) 919.0 * 514.0 * 143.0 1160*616*147 Packing (W * H * D) F5000...
  • Page 147 4. Troubleshooting UF5300 32" 40" 46" WALL MOUNT (A * B) 200 * 200 200 * 200 400 * 400 364.1 329.8 116.2 170.4 78.1 4-120...
  • Page 148 4. Troubleshooting 5500 „ 32", 40" Item 32" 40" SET (W/Quad Stand) mm (W * H2 * D2) 738.0 * 509.6 * 265 928.2 * 615.5 * 265 SET (W/O Stand) mm (W * h * d) 738.2 * 445.4 * 49.0 928.2 * 552.3 * 49.4 Packing (out) mm (W * H * D) 985 * 596 * 143...
  • Page 149 4. Troubleshooting UF5500 32" 40" 46" 50" WALL MOUNT (A X B) 200 X 200 200 X 200 400 X 400 400 X 400 364.1 329.8 367.7 116.2 170.4 78.1 4-122...

  • Page 150: Wiring Diagram

    5. Wiring Diagram 5. Wiring Diagram 5-1. Wiring Diagram...

  • Page 151: Connector

    5. Wiring Diagram 5-2. Connector Main Board „ CN1401_FHD CN1401_FHD EVEN_TX3+ ODD_TX3+ ODD_TX0- EVEN_TX3- ODD_TX3- FRC_SDA FRC_PWM1 EVEN_TXCLK- ODD_TXCLK+ FRC_SCL EVEN_TXCLK+ ODD_TXCLK- FRC_PWM4 FRC_PWM3 PANEL_13V_PW FRC_PWM2 EVEN_TX2+ ODD_TX2+ PANEL_13V_PW TCON_SDA EVEN_TX2- ODD_TX2- PANEL_13V_PW PANEL_I2C_EN EVEN_TX1+ ODD_TX1+ PANEL_13V_PW BT_SYNC EVEN_TX1- ODD_TX1- PANEL_13V_PW UPDATE_CHK EVEN_TX0+...
  • Page 152 5. Wiring Diagram CN201 (to Powr board) CN601 (HDMI3) B13V HDMI1_RX2+ SW_POWER B13V HDMI1_RXCLK- B13V HDMI1_RX2- PWM_DIMM HDMI1_RX1+ HDMI1_SCL_DDC HDMI1_RX1- HDMI1_SDA_DDC B13VS HDMI1_RX0+ HDMI1_5V B13VS HDMI1_RX0- HDMI1_HOT_PLUG SW_INVERTER HDMI1_RXCLK+ CN1201 (FUNCTION) CN602 (HDMI1) A5.3V HDMI2_RX2+ LED_STB HDMI2_RXCLK- BT_WAKE HDMI2_RX2- FRAME_SYNC_IN IR_GND HDMI2_RX1+ ARC2_SIGLE...
  • Page 153 5. Wiring Diagram CN1502 (USB2) B5V_USB2_PW USB2_DP USB2_DM OP301 (OPTICAL) SPDIF_OUT B5V_DC_PW CN1402 (LAN) LAN_TXD+ B2.5V B2.5V LAN_RXD- LAN_TXD- LAN_RXD+ CN304_NIRB / CN303_IRB TEST_SR HP_LINE_SL_OUT IDENT_HP HP_LINE_SR_OUT TEST_SL IPR_JACK_ID...
  • Page 154 5. Wiring Diagram SMPS „ CNM803 (to MAIN board) B13V PWM_DIM B13V ECO_ON/OFF Vamp BLU_ON/OFF Vamp PS ON/OFF CNL802 CN801S...

  • Page 155: Connector Functions

    5. Wiring Diagram 5-3. Connector Functions Connector Function Supply main power and dimming signal from IP board to Main Board. CN201  IP CN CN1401_FHD ↔ T-CON CNF1 The LVDS signal transfered from Main Board to Panel.

  • Page 156: Cables

    5. Wiring Diagram 5-4. Cables LEAD (Main-IP 14P) LVDS CALBE (Main - Panel 51P) UA32F45** : BN39-01652S UA32F53**/55** : UA32F53**/55** : BN39-01652S BN96-24278U, BN96-29942A Code No. UA40F53**/55** :BN39-01652T UA40F53**/55** : BN96-24278X UA46F53**/55** : BN39-01652D UA46F53**/55** : BN96-24278V UA50F55** : BN39-01652U UA50F55** : BN96-26699B Image LVDS CALBE (Main - Panel 30P)

This manual is also suitable for:

Ua32f53 seriesUa46f53 seriesUa46f55 seriesUa50f55 seriesUa32f55 seriesUa40f53 series ... Show all

Table of Contents
