Niles IW2550LCR Installation Manual page 9

IW2770LCR
Perforated Screen
Figure 4. Recommended center-channel placement behind a perforated projection screen.
Loudspeaker may be installed vertically or horizontally. Tweeter/Midrange Pod should be
positioned as shown.
(Optional Placement Above TV)
Pod rotated
(tweeter up)
Pod rotated
(tweeter up)
Figure 3.
IW2770LCR
IW2770LCR
Not Greater
than 24"
Not Greater
than 24"
IW2770LCR
Perforated Screen
7
