- Page 1 Installation Manual V2.1 SMA 4000 Network TalkBack Repeater The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com...
-
Page 2: Table Of Contents
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com SMA 4000 Series Network TalkBack Repeater Table of Contents Installation Instructions Mounting Instructions- 3 Wiring Instructions - 4 Setting Up The Repeater... -
Page 3: Installation Instructions
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Installation Instructions Mounting Instructions 1. Remove the cover of the wiring panel. 2. Mark the four drilling points on the wall based on the drawing above. -
Page 4: Wiring Information
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Installation Instructions Wiring Information Blue Yellow/ Brown Europe Green White Green Black 120VAC @ .2 amp Note: 14 AWG is the smallest conductor acceptable for power input. -
Page 5: Initial Setup
To access the web interface, type in the new IP address in the web browser. 4. DHCP - If DHCP is being utilized, load the Sapling IP Monitor software on a PC that is connected to the network. Launch the Monitor.exe file. -
Page 6: Web Interface
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Login Password Type in the password in this field to access the Network TalkBack Repeater’s Web Interface. The default user password is 1111. -
Page 7: Home
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Home Home This screen displays the time, date and the Daylight Saving Time status. -
Page 8: Clock Settings
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Clock Settings User Password This field allows the user to enter a new password for the user level programming. The password must be entered once in the User Password field and once in the Confirm Password field in order to be changed. -
Page 9: Network Settings
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Network Settings Gateway IP Address - This field allows for the Gateway IP address to be set. Subnet Mask - This field allows the Subnet Mask to be set. -
Page 10: Network Servers
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Network Servers Retry Failed Server After This field allows the user to specify how many refresh cycles before the network repeater will retry to access the time from an SMA Master Clock. -
Page 11: Clock Status
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Clock Status NTP Details This button, when clicked, provides additional details about the NTP synchronization. Resync NTP Now This button, when clicked, forces a synchronization with the master clock. -
Page 12: Daylight Saving Time
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Daylight Saving Time IMPORTANT: In order to correctly synchronize with the SMA Series Master Clock, use the same DST setting as the SMA Series Master Clock that is being used as the primary time source. -
Page 13: Email Alerts
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Email Alerts Email Recipient This field is where the user name of the email recipient will be inserted. Do not enter the domain and suffix. -
Page 14: Event Log
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface Event Log Clear Log - This button, when clicked, allows the user to clear the log of all results. Event List - This feature allows the user to see all the events and settings the Network TalkBack Repeater has previously carried out. -
Page 15: Talkback Technology
The Sapling Company, Inc. +1 215.322.6063 P. 1633 Republic Road +1 215.322.8498 F. Huntingdon Valley, PA 19006 www.sapling-inc.com Web Interface TalkBack Technology Please Note: The TalkBack Technology tab will only appear if the Network Repeater has relayed TalkBack data to the master clock. -
Page 16: Support
The Network TalkBack Repeater sends out the signal once a minute. Can the Network TalkBack Repeater receive time from other devices besides the Sapling SMA Series Master Clock? No, the Network TalkBack Repeater only receives time from the SMA Series Master Clock. -
