English version
JB000120 Sweex 3.2 Megapixel digital camera
Benefits
5 in 1 multifunction camera: digital camera that can make video and audio recordings, with webcam and card reader functions
White balance: automatic, daylight, shadow, tungsten and fluorescent
Image sensor: 1024x768, 2048x1536 (3MP), 2560x1920 (5MP interpolated)
Key Characteristics
Image sensor- High Quality 3.2 megapixels CMOS sensor
Audio recording
Webcam
Timer function, 2-10 seconds
Internal 16 MB flash memory
Specifications
1.5 inch LCD screen
Focal distance: f = 8.47
Aperture: F2.8
4x digital zoom
Focus:
Normal 1m - infinity
Macro 0.2m
File format: Jpeg EXIF, DPOF, AVI
Flash: automatic and manually adjustable
Power: 4 AAA batteries
USB 1.1 interface
Weight: 110 gram (without batteries)
Dimensions: 97 x 28 x 63mm
2
W W W . S W E E X . C O M
Camera Components
Front
Flash
Self-timer lamp
Microphone
Rear
Self-timer/Stop/Left button
Operation lamp
Viewfinder
LCD screen
DISP button
MENU/OK button
SHIFT/FLASH button
Top
Mode dial
Power button
Shutter button
English version
Viewfinder
Lens
Zoom in/Up button
Macro/Pause/Right button
Zoom out/Down button
Speaker
Battery cover
Side
Macro switch
USB port
Video out terminal
3
