TECHNICAL SPECIFICATIONS MP3/WMA PLAYER SECTION Signal to Noise Ratio > 60 dB Channel Separation > 50 dB (1kHz) Frequency Response 60Hz - 15 kHz TUNER FM Frequency range 87.5-108 MHz Sensitivity 2.8 µV Stereo separation 30 dB Signal to noise ratio 45 dB Channel step 50 kHz...
Location of parts and controls RMD 213 (1-6) 1. Switching the device on and off ( ) / turning the sound off (MU) 2. Call up Settings menu 3. Turn to set values/volume 4. Preset stations (1,2,3,4,5,6) 5. Setting the operating mode (MD) / setting the PTY function (PTY) 6.
Installation PRECAUTIONS • Choose the mounting location carefully so that the unit will not interfere with the normal driving functions of the driver. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight or hot air from the heater, or where it would be subject to dust, dirt or excessive vibration. • Use only the supplied mounting hardware for a safe and secure installation. 182mm • Be sure to remove the front panel before installing the unit. 53mm NOTE : Inclination angle for car radio installation must not exceed 30˚ otherwise the front panel will not open. 182mm 53mm Bend these claws, if necessay Note: Keep the release key in the safe place as you may need it in future to remove the unit from the car. To support the unit UNIT RELEASE CASE DASH BOARD HEX NUT LOCK WASHER Dashboard PLAIN WASHER CAR BODY REAR SUPPORT STRAP TAPPING SCREW 10.
General operations Switching on and off /MU button pressed. Press any button to switch the device on. To switch off, press and hold the Volume Turn the VOL(3) knob to set the volume. Switching mute on / off /MU button briefly to turn the sound off. Press the /MU button again to turn the sound on again.
DX / LOCAL - Set reception sensitivity Turn the VOL knob to align the reception sensitivity to national stations (DX) or regional stations (LOCAL). ADJ - Set the time Turn the VOL knob to the right to set the minutes and to the left to set the hours. Note: The device has an RDS-controlled clock. The clock sets itself automatically when the RDS function is enabled and continues to run when the radio is switched off . If you do not receive any RDS signal, you can set the time of day manually.
Disabling / enabling the PTY function • Press the MD button to activate the PTY search. The PTY symbol is shown on the display with the last PTY entry selected (e.g. POP M, Rock M...). Only stations with the PTY ID currently selected are included in the station search.
Search functions Title number search • Press the A/PS button. • Turn the VOL knob to set the first digit of the title number required. • Press the SEL button to confirm the entry and to skip to entry of the second, third or fourth digit. • Press the 1 PAU button to commence playback of the selected title.
