Summary of Contents for Jayco Kiwi
- Page 1 Where Tradition and Innovation Meet ® Kiwi & Kiwi Too Travel Trailer Owner’s Manual...
- Page 2 Just call us with your VIN # and we will find what you need and ship it directly from Jayco to your front door. Like Jayco, we are family owned and operated. Our courteous professionals are here to help make your shopping experience as pleasant as humanly possible.
- Page 3 Nothing in this manual creates any warranty, either expressed or implied. The only warranty offered by Jayco, Inc. is as set forth in the limited warranty applicable to this vehicle. The owner’s failure to provide required service and/or maintenance could result in the loss of warranty.
- Page 4 YOUR NEW JAYCO IS YOUR PASSPORT TO A WHOLE WORLD OF NEW FRIENDS, CAMPING FUN AND TRAVEL ADVENTURE WHEN YOU JOIN THE THOUSANDS OF JAYCO FAMILIES WHO MAKE UP THE . . . JAYCO JAFARI INTERNATIONAL TRAVEL CLUB You will find us enjoying the friendship and fellowship of JAFARI CAMPING as we join our local area FLIGHTS at hundreds of weekend camp-outs all over North America each month .
- Page 5 TO: Membership Coordinator for the Jayco Jafari International Travel Club Please enroll us as members in the Jayco Travel Club. We are ready to roll to where the “friends we just haven’t met yet” have the coffee on the fire and are waiting for us to arrive: We are ...
-
Page 6: Table Of Contents
Condensation ..........4 Seasoning the Bed Canvas (Kiwi Only) ......4 Chapter 2 –... - Page 7 Maintenance ..........25 Closing the Beds (Kiwi Models Only) ......25 Fire Extinguisher .
- Page 8 Operating the Refrigerator Controls – N621 ....62 Monitor Panel (Kiwi Too Only) ....... . 63...
- Page 9 Kiwi Too Travel Trailer ........79...
-
Page 10: Chapter 1 - Introduction To Rv Ownership
Your purchase of a Jayco RV allows you to enter this unique world of camping and leisure in a grand style. Your Jayco RV has been designed and engineered to offer you many comforts of home that will make your camping experience as enjoyable as possible. -
Page 11: Safety Considerations
If you believe that your vehicle has a defect which could cause a crash, injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Jayco, Inc. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. -
Page 12: Electrical System Safety
Chapter 3. If you do not understand the information provided, please consult your dealer or Jayco owner representative. • Sanitize the fresh water supply system periodically (see sanitizing instructions). • Prevent water connection fittings from coming in contact with the ground or drain hose to reduce chance of contamination. -
Page 13: Insurance
Many RV and marine dealers carry small dehumidifiers especially sized for recreation use. Condensation causes dampness, mildew, staining and if allowed to continue at high levels, damage to the tent (Kiwi only), paneling and wood structures. SEASONING THE BED CANVAS (KIWI ONLY) Prior to use, season the canvas sections of your travel trailer. -
Page 14: Chapter 2 - Obtaining Service
CHAPTER 2 OBTAINING SERVICE WARRANTY REGISTRATION... -
Page 16: Service Procedures
Some RV dealers may be authorized service centers for certain manufacturers of products warranted separately. Check with your dealer before contacting others to reduce delays. If your Jayco dealer is not an authorized service center for the product in question, he can assist you in obtaining authorized service. -
Page 17: Factory
A factory service department is operated at our Middlebury, Indiana, manufacturing facility. Should your Jayco RV be in need of repairs and your dealer recommends that the factory make the necessary repairs, it may be returned to our plant upon following these procedures: A. -
Page 18: Towable Transferable Limited Warranty
TOWABLE TRANSFERABLE LIMITED WARRANTY... -
Page 20: Chapter 3 - Use Of Your Travel Trailer
CHAPTER 3 USE OF YOUR TRAVEL TRAILER In this chapter you will find helpful information to assist you in preparing, traveling and using your travel trailer. EQUIPMENT Tow Vehicle Begin your camping experiences by using a tow vehicle that will adequately transport your travel trailer to and from your destinations. -
Page 21: Hitches
• Using an oversized or undersized hitch can cause damage to the frame of your travel trailer. • Jayco, Inc. cannot be responsible for the suspension system of the tow vehicle. The final hitch ball height after the travel trailer is completely hooked up is a factor to be considered. -
Page 22: Hookup
Hookup Hooking up a travel trailer is not difficult and will become easier with practice. The following procedure will help you until you become more experienced. 1. Block Wheels. 2. Turn crank on jack to raise tongue of trailer above hitch ball on hitch. 3. -
Page 23: Towing
Figure 3-1 Towing While towing your Jayco travel trailer you need to be aware of the extra weight behind your vehicle. The following list contains some pointers to remember while traveling. • With the travel trailer attached you will have slower acceleration and need more distance to stop. -
Page 24: Traveling
(i.e. tires, brakes, springs, axle). Make sure that you review and understand the weight terms and information. The weight provided in the Jayco literature for your travel trailer is based on standard equipment on that particular model and is “dry” (i.e. no liquids of cargo). Remember that any options or personal cargo added must be subtracted from the available cargo capacity. - Page 25 TRAILER WEIGHT INFORMATION VIN or SERIAL NUMBER ______________________________________ MODEL _____________________________________________________ GVWR (Gross Vehicle Weight Rating) is the maximum permissible weight of this trailer when separated from the tow vehicle. UVW (Unloaded Vehicle Weight) is the total weight of this trailer as manufactured at the factory when separated from the tow vehicle.
-
Page 26: Loading Cargo
CAUTION: DO NOT overload your travel trailer. Please follow the GVWR when loading your Jayco travel trailer. When loading is completed, it is strongly suggested that you drive to a large scale and have your travel trailer weighed. If you are over loaded, it is advisable that you remove some of your cargo or liquids. -
Page 27: Tires
TIRES All Jayco towable travel trailers are equipped with name brand tires, designed and built for recreation vehicles. Tires are radial in design, having two steel cords and two polyester cords, offering excellent strength and mileage in various types of weather. -
Page 28: Wheel Lugs
Wheel Lugs When the wheels are installed on your Jayco travel trailer, the lug nuts must be tightened at 50-75 foot pounds of torque. WARNING: Wheel lugs should be checked at 10, 25 & 50 miles when new, then every 3,000 miles. The wheel lugs should then be checked after winter storage, before starting a trip, or following extensive braking. -
Page 29: Breakaway Switch
Breakaway Switch Schematics Hydraulic (Option for Kiwi 17A Only) Your travel trailer may be equipped with hydraulic surge brakes. These brakes operate automatically as the tow vehicle’s brakes are applied. When the tow vehicle operator begins to decrease speed and apply the brakes, the weight of the moving travel trailer pushes forward and the coupler moves downward. -
Page 30: Breakaway Protection
Check this before towing. Do not use the breakaway protection as a parking brake. SETTING UP YOUR KIWI/KIWI TOO TRAVEL TRAILER We recommend that you select a level or nearly level place for camping. There are two reasons to be level. First, your travel trailer is designed to operate in a level position for both water drainage system and especially your refrigerator. -
Page 31: Bed Setup (Front And Rear) (For Kiwi Models Only)
Bed Setup (Front and Rear) (For Kiwi Models Only) IMPORTANT: We recommend that well in advance of any trip, you set up your Kiwi travel trailer and using a garden hose, thoroughly soak the tent with a light spray of water. After the tent dries, repeat the soaking process three additional times. -
Page 32: Slideout Operation (For Models 28R, 26S, 30T)
Slideout Operation (For Models 28R, 26S, 30T) Extending Room 1. Release the travel lock behind the center door of the overhead cabinets located above the sofa. 2. Release second travel lock located below the sofa. 3. For one person operation, push slideout into the extended position by pushing on the sofa. -
Page 33: Tv Antenna (Standard On Kiwi Too, Option On Kiwi)
TV ANTENNA (Standard on Kiwi Too, Option on Kiwi) Raising Antenna to Operating Position Turn the elevating crank clockwise in the UP direction about thirteen turns or until some resistance to turning is noted. (Fig. 3-4) On Amplified models, 12-Volt DC power is required. Turn the power supply ON to use either the front or rear TV outlet. -
Page 34: Maintenance
Maintenance See “TV Antenna Maintenance” in Chapter 7. Closing the Beds (Kiwi Models Only) 1. Remove thin cushion from under extension and fold bed cushion at crease. Remove bow brace from the bracket on the roof and pull toward you, removing it from bed bow peg on the bed bow. -
Page 35: Chapter 4 - The Systems
CHAPTER 4 THE SYSTEMS PLUMBING SYSTEM Included in your Jayco recreation vehicle is a complete fresh water system. Fresh water may be obtained through two sources: city water connection or gravity fill tank. Each component is explained along with its operation. -
Page 36: 12-Volt Demand Pump
12-Volt Demand Pump When water is desired and you are not hooked up to city water, you need to turn on 12- volt power to start demand pump. The switch is located on the monitor panel or a wall near the pump. Energy for pump is supplied by auxiliary battery or converter. Pump will self prime when started and provide water for travel trailer. -
Page 37: Bath And Shower
Bath and Shower Your bathroom facilities function similar to those in your home. Prepare bath or shower curtains to prevent water from spilling onto floor. Ensure water heater is in operation before bathing. Adjust the faucets for desired temperature before entering tub or shower. Used water will drain through plumbing pipes into gray water holding tank. -
Page 38: Winterizing Your Travel Trailer
Failure to prepare the travel trailer will cause supply lines and water heater to freeze causing breakage. Repairs due to freezing are not to be covered under the terms of your Jayco Limited Warranty. Please keep in mind that your travel trailer was not designed for use during sub-freezing weather. -
Page 39: Sanitation System
7. Close valve E. 8. Before using the water system again, drain and flush the water system. Close valve C and open valves D, A, and B. Sanitize and flush the whole system. It is now ready for use. To winterize: Valves A, B, and D are closed; E and C are open. Fig. -
Page 40: Maintenance
® OPERATING INSTRUCTIONS – AQUA MAGIC ® The Aqua Magic 4 is equipped with two operating levers located on the right side of the toilet when facing the unit. To flush, pull the black lever forward (clockwise) until rinse clears bowl and release lever slowly. Movement of the flush lever opens the waste valve and allows waste to pass into the holding tank. -
Page 41: Vents
Vents Another important part of the sanitation system are the vents which release air from tanks. Each tank has a vent pipe built into the travel trailer through the cabinet, wall and roof. A vent cap is attached to the roof and must be clear of obstructions to perform as intended. -
Page 42: The Lp Fuel System
2. Attach a flexible sewer hose to adapter and secure with a clamp. 3. Remove cap and attach adapter onto valve housing. 4. Turn adapter 10° to lock onto pegs. 5. Place other end into approved sewer system. 6. Open the 3” drain valve to drain the sewage tank. 7. -
Page 43: Servicing And Filling Lp Containers
Servicing and Filling LP Containers WARNING: Because your vehicle has exterior combustion air inlets, all appliance pilot lights should be turned off during gasoline or propane refuel- ing. Laws in some states require this. Filling an LP container correctly is very important and should be performed by a qualified person who knows the proper inspection and safety procedures. -
Page 44: Opd Overfill Protection
When an LP tank gets low, sometimes there is a concentration of garlic-like odor which may be mistaken for a gas leak. After a change over to a full tank, the odor usually will disappear. If not, turn off the LP containers and have the system checked by a qualified technician. -
Page 45: Main Supply Hose
4. Attach the inverted flare x 11” Type-1 pigtail hose to the regulator inlet and the right hand swivel nut to the cylinder valve. WARNING: The pigtail hose must be installed to avoid tension or pulling stress at either end of the hose. WARNING: Keep the pigtail hose away from sharp edges of the cylinder collar, rigid corners, walls, doors or other compartment structures including the cover. -
Page 46: Regulator
Automatic Changeover Regulator (STANDARD FOR KIWI TOO, OPTION FOR KIWI) The automatic changeover regulator allows both gas bottles to be turned on simulta- neously. The arrow on the regulator handle indicates which bottle is in service. When the indicated bottle in service becomes empty, changeover is automatically accomplished to commence drawing fuel from the other bottle. -
Page 47: Operation
Operation After the camper is completely set up and you are prepared for camping enjoyment, follow these steps for LP gas operation. 1. Close ALL burner valves, controls and pilot light valves. 2. Open main valve on LP container slowly to avoid fast rush through excess flow valve causing “gas freeze.”... -
Page 48: Lp Detector
Furnace (Kiwi) ........16,000 to 20,000... -
Page 49: Operation
Operation Power On Warm Up: When power is first applied the yellow LED will flash for three minutes while the detector is warming up. At the end of that time the LED will turn green indicating full operation. If the detector has detected unsafe levels of gas it will immedi- ately go into alarm. -
Page 50: Malfunctioning Alarm
Malfunctioning Alarm The microprocessor will activate the malfunction alarm when it detects a fault in the detectors operation. The LED will alternately flash red and green, while the sounder beeps twice every fifteen seconds. The mute switch will not function. Remove the detector immediately and return it for repair or replacement. -
Page 51: Electrical System
12-volt DC (direct current) capabilities. All installations are made in compliance with safety requirements of ANSI standard A.1192, National Electric Code, and Canadian Standards Association. All Kiwi Travel Trailers will have 30-amp service pre-wired into breaker box, in accordance with codes. Changes, Modifications and Additions Any changes or additions made after delivery may cause a hazardous condition. -
Page 52: Circuit Breakers And Box
It is strongly recommended to avoid the use of extension cords. If an extension cord is used, it MUST be the same amperage rating as the RV power cord. Using an improper extension cord will cause overheating of the cord and equipment as well as possibly causing premature failure of the AC equipment. -
Page 53: Consumption Of 120-Volt Power
Below is a generic drawing with circuit breaker alignment. Your travel trailer may not be exactly the same as shown depending on model, floor plan, and options. = 30-amp main, incoming power to travel trailer. = 20-amp circuit to air conditioning = 15-amp microwave oven. -
Page 54: Auxiliary Battery (Option On Some Units)
Fig. 4-9 – Kiwi Too Auxiliary Battery (Option on Some Units) All Jayco Travel Trailers are designed and built to accept a battery. A deep cycle marine type is recommended as you need longer energy rather than cold cranking power. A battery is required to operate the breakaway switch and is also available as a source of energy when traveling and camping. -
Page 55: Battery Isolator (For Tow Vehicle)
Battery Isolator (For Tow Vehicle) When an auxiliary or “house” battery is installed in a recreation vehicle, it is the nature of parallel circuity to draw energy from both batteries. A device called an “isolator” should be installed for two purposes. First it receives current from the alternator and controls distribution of energy to both batteries. -
Page 56: Brakes
Bulbs Interior: Exterior: Square lights ....#921 Porch Light ..... #912 Round Lights . -
Page 57: Chapter 5 - Appliances
CHAPTER 5 APPLIANCES GENERAL All appliances in your Jayco RV are name brand quality built equipment, guided by current code and standards. Appliances are designed to operate using LP gas only, not on natural gas. Included with each travel trailer are specific operation manuals, written and published by the manufacturer for each appliance. -
Page 58: For Your Safety Read Before Operating
For Your Safety Read Before Operating WARNING: If these instructions are not followed precisely, a fire or explo- sion may result causing property damage, personal injury or loss of life. A. This appliance does not have a pilot light. It is equipped with an ignition device that automatically lights the burner. -
Page 59: To Turn Off Gas To Appliance
To Turn Off Gas to Appliance 1. Set the thermostat to lowest setting. 2. Turn off all electric power to the appliance if service is to be performed. 3. Open the access panel (Outer Door Assembly) to turn off the electric switch. 4. - Page 60 Warning: Personal Injury Hazard • Verify sufficient gas supply before attempting to light any top burner. Air in the gas supply line will significantly delay burner ignition, and a burner may light unexpectedly as the air in the line clears out and is replaced by LP gas;...
-
Page 61: Range And Oven Operation (Option Kiwi Too Only)
Many other tips, cautions, warnings and information will be found in the manual published and supplied by the manufacturer of this product. RANGE AND OVEN OPERATION (Option Kiwi Too Only) WARNING: Personal Injury Hazard • Do not touch or allow clothing and flammable materials to come in contact with burner grates or areas near top burners until they have sufficient time to cool. -
Page 62: Water Heater
WARNING: Burn, Fire and Explosion Hazard • Use care when lighting a top burner by hand. If the burner lights unexpectedly, or your hand is close to the burner, you may be burned. • If any burner should extinguish (after initially lighting or due to accidental blow-out) turn gas supply off and WAIT FIVE MINUTES before again attempting to light the burner. -
Page 63: Pilot Operation
Pilot Operation CAUTION: Do not tamper with the pilot orifice. High water temperature and failure of the gas control could result. 1. Turn lighting control (Fig. 5-1B or 5-2B) to “OFF” position. 2. Wait at least five minutes to allow gas which may have accumulated in burner compartment to escape. -
Page 64: Electric Ignition Operation
To adjust Main Burner (Fig. 5-3): 1. Loosen air shutter screw (Fig. 5-3A). 2. Slide air shutter (Fig. 5-3B) to the right until a small amount of yellow color appears in the main burner flame. 3. Move air shutter (Fig. 5-3B) to left until yellow disap- Fig. -
Page 65: Electric Operation
Electric Operation 1. For gas operation refer to Pilot Operation or Electronic Ignition Operation section. 2. For electrical operation, use the switch inside the travel trailer in the utility panel. 3. Completely fill tank with water. 4. Turn switch (Fig. 5-7) located in the travel trailer to the “ON” position. NOTE: Turning the power on in the heater with little or no water covering the heating element may burn out the element and void the warranty. - Page 66 1. Turn off your main water supply (pump or water hook-up source). 2. Drain the water heater inner tank. Approximately two quarts of water will remain in the bottom of the tank. This water contains a great deal of the harmful corrosive material that has accumulated in the tank.
-
Page 67: Refrigerator
REFRIGERATOR This appliance in your Jayco travel trailer has been designed by its manufacturer to operate on 120 volt AC, 12 volt DC or on LP gas energy. Its performance depends on numerous factors such as energy, venting, leveling, humidity and atmosphere tempera- tures. -
Page 68: Operating The Refrigerator Controls - N300 (Kiwi 17A)
Operating the Refrigerator Controls – N300 (Kiwi 17A) The thermostat (1) changes the amount of propane gas that goes to the burner. This acts as the temperature control of the refrigerator. Number 5 is the coldest temperature setting. NOTE: This is not an automatic gas control. It does not change the flame from high fire to low fire as do some RV refrigerators. -
Page 69: Start Up - Ac Operation
Shut Down 1. Turn the selector switch to the OFF position ( Operating the Refrigerator Controls – N500 (Kiwi 23B & 21C) The thermostat (A) changes the amount of propane gas that goes to the burner. This acts as the temperature control of the refrigerator. Number 5 is the coldest temperature setting. -
Page 70: Ignition - Propane Gas Operation
Ignition – Propane Gas Operation 1. Open the valve at the propane gas storage tank. 2. Turn the thermostat (A) to the 5 position. 3. Turn the selector switch (B) to the propane gas position ( 4. Push and hold in the safety valve (C) for about five seconds. •... -
Page 71: Operating The Refrigerator Controls - N621
Operating the Refrigerator Controls – N621 (Kiwi Too, Option Kiwi 23B) CONTROL PANEL Fig. 5-9 The refrigerator control panel is between the freezer compartment and the fresh food compartment. The ON/OFF button (1) starts and shuts down the refrigerator. If the refrigerator is shut down, press the ON/OFF button to start the refrigerator in auto mode. -
Page 72: Monitor Panel (Kiwi Too Only)
LP gas supply line; consult your local dealer or an authorized Norcold Serivice Center; change to manual mode and operate on AC electric. MONITOR PANEL (Kiwi Too Only) The monitor panel will provide useful information on the capacities of the water tanks and the battery condition. -
Page 73: Chapter 6 - Care Of Body Components
CHAPTER 6 CARE OF BODY COMPONENTS EXTERIOR CARE CAUTION: We do not recommend you take your recreation vehicle through auto- matic car washes and extreme caution should be used if utilizing any type of pressure sprayer around all attachments, doors, windows, appliance vents, etc. to avoid forcing water inside the unit, possibly damaging components. -
Page 74: Frame
For best results, professionally dry clean. Paneling The wall paneling in your new Jayco is a vinyl covered panel. If deep scratches occur, putty sticks can be used to cover scratches on wood surfaces. These can be obtained from hardware stores and lumber yards. -
Page 75: Hardware, Sink And Shower Fixtures
(refer to awning definition) is made of an embossed vinyl with textile backing. On the interior of the Kiwi travel trailer tent, the material is a 100% polyester backing. The following definitions will assist you in providing the proper care for your Kiwi travel trailer tent components. -
Page 76: Exterior
• Screen Room - Available feature to enhance the canopy area by providing an added “room” to your travel trailer. This “room” is attached to the canopy and the camper. FABRIC CARE (Kiwi Only) Cushions/Bed Mats Please use common sense and treat your furniture as you would at home. Remember, your travel trailer is a small living area, so soiling may occur more frequently and the fabric will probably need more attention than your furniture at home. -
Page 77: Tents
Tents Proper care and maintenance are important for the life of your travel trailer’s tent. We recommend the following list of suggestions be adhered to when there is a need to clean the tents. EXTERIOR • If the tent becomes dirty, use a damp cloth or sponge with water. Do not use harsh detergents, soaps or solvents since they may remove water repellency, fire retardants, and damage the surface or color. -
Page 78: Condensation
“breathe.” This will help minimize moisture gathering above bunk area on the vinyl. Use only breathable fabric camper covers, such as those available through your Jayco dealer, when storing your travel trailer. -
Page 79: Chapter 7 - Options
AIR CONDITIONER (Option – Kiwi; Standard – Kiwi Too) Air conditioners may be installed by the Jayco factory or by your dealer. If you did not buy your travel trailer with the optional air conditioner, one of your roof vents may be pre-wired for later installation. -
Page 80: Kiwi Too
Kiwi Too The following procedures should be used in securing the spare tire in the travel position: 1. Put the steel hoist lift support located on the end of the cable through the rim of the tire. Clips need to seat inside of the hole. - Page 81 3. Attach the fuel hose to the grill and the LP gas connection located under the travel trailer by using the “Quick-Coupler” instruction as follows (Fig. 7-4): • Place the handle in the “OFF” position and push back the sleeve. Valve handle must be in the “OFF”...
-
Page 82: Chapter 8 - Maintenance/Storage
CHAPTER 8 MAINTENANCE/STORAGE Your new Jayco travel trailer is designed to be as maintenance free as possible. However, maintenance is important to retain its condition as near new as possible. Proper mainte- nance will give you many trouble-free miles. NOTE: Some areas in this chapter may not be applicable to your travel trailer. -
Page 83: Lp Gas Bottles
TL Enterprises (Trailer Life, Motorhome, etc.) can offer additional and practical advice on the proper storage of your camper. Damage from rodents or insects are NOT covered under your Jayco Limited Warranty. CAUTION: When storing your travel trailer, it is recommended that the battery be... -
Page 84: Mechanical Maintenance Chart
MAINTENANCE AVOID The wheel bearings in your Exposure to water or con- Wheel Bearings Jayco travel trailer are pre- densation will cause bear- greased. It is recommended that ings to rust and be dam- you repack bearings at 12 aged. - Page 85 COMPONENT MAINTENANCE AVOID Lug Nuts Lug nuts must be checked at 10, DO NOT ignore check- 25 & 50 miles when new, then ing wheel lug nuts. every 3,000 miles. Lug nuts should be checked periodically for safety, especially before any long trip, extensive braking or a tire change.
- Page 86 COMPONENT MAINTENANCE AVOID Brakes It is important to have brakes Poorly adjusted brakes adjusted between 200-1,000 will not function cor- miles after initial break-in pe- rectly. riod by qualified technician. This operation may or may not be included as part of selling price.
- Page 87 COMPONENT MAINTENANCE AVOID Sealants All sealants used in construction Using poor quality seal- See Fig. 8-4 can deteriorate from U.V. expo- ing materials. Ignoring sure, air pollution, freezing tem- sealed areas. peratures and other exposure to weather elements. Tape sealants used around doors, windows, and extrusions are subject to dry out conditions by sunlight and will allow water...
-
Page 88: Inspection Points For Sealing
INSPECTION POINTS FOR SEALING Fig. 8-4 Kiwi Too Travel Trailer 1. Moldings 4. Windows 2. Vents 5. Exterior Attachments 3. Slideout Trim 6. Marker & Tail Lights... -
Page 89: Kiwi Travel Trailer
Fig. 8-5 Kiwi Travel Trailer 1. Moldings 4. Windows 2. Vents 5. Exterior Attachments 3. Slideout Trim 6. Marker & Tail Lights... -
Page 90: Maintenance Checklist
MAINTENANCE CHECKLIST Prior to First Trip Check LP gas lines for leaks. Test LP gas detector. Sanitize fresh water system. Tighten wheel nuts to specified torque values. Open all windows and the door and start the furnace. Leave the windows and door open and the furnace on until all fumes fully dissipate. - Page 91 After Every Tire Change Tighten wheel nuts to specified torque values at ten miles, twenty-five miles and fifty miles. Daily Recharge battery after each use. Ensure LP gas detector operation light is green in color. Weekly Test LP gas detector. Check tire pressure and wear.
- Page 92 Every Four Months or 4,000 Miles Flush out water heater tanks. Every Six Months or 6,000 Miles Clean drains with approved drain cleaners. Check pipe connections for tightness. Tighten if necessary. Lubricate all moving parts on the entrance steps. Lubricate entrance and baggage door locks. Clean and lubricate stabilizer jacks.
- Page 93 We are pleased you chose Jayco and want to do everything possible to make sure you stay as happy with your Jayco RV home as you were on the day you bought it. We work closely with Jayco dealers to provide customer service for you.
