ADDON GWAR3000 V2.0 11g /54Mbps ADSL
Wireless Router Quick Installation Guide

Package Contents

• 1 x ADSL Ethernet or Wireless Gateway
• 1 x Detachable antenna (Wireless models)
• 1 x 12V/1A DC Power Adapter
• 1 x Quick Installation Guide

Front View

POWER:
WAN:
This LED is lighted when the WAN connection is established and flashes
when the WAN port is sending/receiving data.
WLAN:
This LED is lighted when a wireless link is established and flashes when
the data is sending/receiving via wireless. (Wireless models)
LAN:
The LED is lighted when a connection is established to LAN port and
flashes when LAN port is sending/receiving data. (The number of LAN ports
depends on your model.)
(4 Ports Wireless Gateway)
The LED stays lighted to indicate the system is power on properly.
• 1 x CD-ROM (with Manual and USB driver)
• 1 x Ethernet (RJ-45) cable
• 1 x telephone (RJ-11) cable
Wireless Model
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GWAR3000 and is the answer not in the manual?

Questions and answers

Related Manuals for ADDON GWAR3000

Summary of Contents for ADDON GWAR3000

  • Page 1: Package Contents

    ADDON GWAR3000 V2.0 11g /54Mbps ADSL Wireless Router Quick Installation Guide Package Contents • 1 x ADSL Ethernet or Wireless Gateway • 1 x CD-ROM (with Manual and USB driver) • 1 x Detachable antenna (Wireless models) • 1 x Ethernet (RJ-45) cable •...

  • Page 2: Before You Start

    Before You Start Proper placement of your Gateway is important to improve your network performance. The figure below is a rough overview of the connection. Especially, in order to ensure the best performance of your wireless network, keep the following tips in mind to choose the location of your wireless gateway. •...

  • Page 3: Configuring Your Router

    Configuring your router A: Through ADDON Quick Installation Wizard 1. you can find the ADDON Quick Installation Wizard on the installation CD 2. install the ADDON Quick Installation Wizard and double click the ADDON icon on you desktop 3. Enter the USERNAME and PASSWORD given by your ISP (you can also enter the encryption key in 10 digits format).
  • Page 4 Open your web browser and type the address 192.168.1.1 into the URL address field and then press Enter or Return key. The login screen will appear. The login dialog window will appear. This device’s default user name is Admin (case sensitive) and password is Admin (case sensitive). Type in Admin (case sensitive) for user name and Admin (case sensitive) for password and then press Log in button.
  • Page 5 In order to be able to connect to the internet, you must enter the Username and Password given by your ISP (if no Password given, please leave it as default). The connection protocol has already been set to UK standard (Type = PPPoA, VCI=38, Encapsulation=VC).
