Summary of Contents for KMS AS-186
-
Page 1: Instruction Manual
INSTRUCTION MANUAL AIRBRUSH COMPRESSOR AS-186 Thanks for purchasing our airbrush compressor and please read this Instruction Manual carefully and thoroughly before operating the tool to get best performance. -
Page 2: Features And Functions
8. Safety Protect devices for air tank. 2. Application Field: Airbrush compressor AS-186, together with airbrush, can be widely used in craftwork spraying, cosmetics, temporary tattoo, tanning, hobbies/models, fingernail painting and so on. Moreover, it is also as the air source for medical, environment protect, breed aquatics Industrial, food Industrial, chemical industrial, laboratory and so on. - Page 3 3. Specification: 1. Type: Single Cylinder Piston Compressor With Air Tank 2. Power: 1/6 HP 3. Speed: 1450/1700 r.p.m 4. Air flow: 20~23L/min 5. Auto Stop Function: Stop at 4BAR(57PSI), Re-start at 3BAR(43PSI) 6. Working Pressure : 0~4 bar 7. Air tank: 3.0L 8.
- Page 4 into the mains supply, turn on the switch, then the air compressor will start work. The press gauge will show the max pressure, and you can adjust the working pressure by adjusting the pressure adjustor. 4. Checking the air leakage. Please do not use any air tools firstly before the compressor reach the maximum pressure and observe whether it will be auto-stop.
- Page 5 advantages is folloings: a. Tanks provide a reservoir of pressurized air that you can draw from while you're spraying. b. You can draw air at a regulated pressure from the tank instead of the average pressure of the piston cylinders. c.
-
Page 6: Spare Part List
5. The vacuum pump must be used in suitable environments (well-ventilated, with an ambient temperature between +5℃ and +40℃). 6. Never use the appliance in your bare feet or wet feet, as well as the wet hand. 7. Never allow the children to touch the working machine or insert the stick into the machine. - Page 7 PARTS DESCRIPTTON PARTS NO. DESCRIPTTON Q TY Q TY AS-186 #01 POWER SWITCH AS186--#25 CYLINDER AS186--#02 REAR COVER AS186--#26 FRONT COVER AS186--#03 WIRE AS186--#27 RETAINER RING AS186-#04 CONDENSER AS186--#28 SCREW AS186--#05 REAR BODY AS186--#29 AS186--#06 SCREW AS186--#30 PRESSURE REGULATOR AS186--#07 STATIONARY MOTOR...
- Page 8 Air compressor structure 、 a.Power switch b.Pressure regulator c.Pressure gauge d.Connection e.Air filter f.Power plug...
