- Page 1 C3X 1080 user and installation manual manuale d’uso ed installazione bedienungs und wartungsanleit manuel d’utilisation et d’installation manual de uso e instalación manual de utilização 使用及安装手册 ВИДЕОПРОЕКТОР...
-
Page 2: Table Of Contents
APP .1 PROJECTION DISTANCES alternatively, the projector can be controlled by a domestic automation system through its serial port or USB port. APP .2 DIMENSIONS C3X 1080 APP .3 INSTALLATION INSTRUCTIONS The appliance has been subjected to exhaustive operating tests by SIM2 to ensure the very highest quality. -
Page 3: Remote Control
C3X1080 2.1 REMOTE CONTROL BACKLIghTINg STAND-BY / ON Backlights the keys on the remote control. LIGHT Sets the panel to stand-by. KEYS 0-9 Selects the sources directly. Switches the panel on from Standby. SOURCE Displays the source selection menu. ESCAPE Disables the On Screen Display. -
Page 4: Important Safety Instructions
Due to the compact nature, high brightness and contrast of the optical system within the C3X 1080, a small amount of light scatter may be seen outside the edges of the screen area and this effect will vary depending on the type of lens used and the zoom and shift setting. - Page 5 C3X1080 • Read this manual carefully and keep it in a safe • Be careful with cables. place for future consultation. Make certain cables are routed so that people will This manual contains important information on how not be impeded or tripped up. Keep all cables away to install and use this equipment correctly.
-
Page 6: Unpacking
C3X 1080 4 UNPACKINg To remove the C3X1080 system from its carton follow the diagrams (Fig. 4). Keep the carton for use when transporting or shipping the unit. Fig.4 CONTENTS Of PACKAgE 1) Projector 2) Remote control 3) Four 1.5V AAA batteries (for remote control) -
Page 7: Installation
C3X1080 5 INSTALLATION Position the projector on a stable, suitable surface or use if the image is correctly focused, you should be able to the optional ceiling mount bracket. see each single pixel of the projected image when close to the screen (Fig. 7). wARNINg: when using the ceiling mount bracket, the safety instructions provided with the bracket must be If this adjustment is insufficient, tilt the projector and cor-... -
Page 8: Switching The Projector On And Of
C3X 1080 SwITChINg ThE PROJECTOR ON AND Off wARNINg: Connect the projector to a power supply with a rated voltage within the following values: 110-240 V AC, 50/60 hz. It must be earthed (fig. 12). Power Switch: Position I: On... - Page 9 C3X1080 age displays (blue LED on). The projected image comes from the input selected when the unit was last switched off (Fig. 14). If a very short time has passed since the unit was last switched off, the lamp may not switch on because it is too hot.
-
Page 10: Projector Status
C3X 1080 7 PROJECTOR STATUS Led red Logo Backlit Status Led blue Initialisation Blue Color Standby Red Color O / Blue Color Cooling Red Blu Overtemperature Red Color Fan Error Red Color (*): selectable from OSD : On : Flashing... - Page 11 C3X1080 COMPOSITE VIDEO hDMI ™ Fit an RCA connector with a Composite Video (CVBS) HDMI™ (High Definition Multimedia Interface) integrates an uncompressed high definition video signal with a signal to this input. The output connector on the external multichannel audio signal and allows exchange of control appliance is normally coloured yellow and will often be data between the video source and the C3X1080.
-
Page 12: Remote Control
C3X 1080 During the short time that it takes to find the signal, a box 9 REMOTE CONTROL will appear showing the signal requested. As soon as the signal is shown in the box additional information will be dis- The remote control requires four 1.5 V batteries, size AAA. - Page 13 C3X1080 PICTURE determines the red-green ratio of the picture. Decreasing the value increases the red content of the image, increas- This menu includes all image adjustment settings. Adjust- ing it increases the green. For this adjustment use skin tones ments that are not available for a given input do not ap- or a test card image with colour bars as a reference.
- Page 14 C3X 1080 IMAgE signal. When the input signal aspect ratio is 4:3 black verti- cal bands are displayed on each side of the picture. ANAMORPHIC: correctly displays a 16:9 image. This menu features adjustments relating to picture position, aspect ratio, magnification etc.
- Page 15 C3X1080 The default settings are: For general use STANDARD applies a certain white balance depending on the standard selected in column “1 RgB”; HIGH - MEDIUM - LOW (default white balance levels); NATIVE (the projector’s native white balance); D75 - D65 - D50 - C standard CIE illuminants; Image Suitable for displaying images from video R G B...
- Page 16 C3X 1080 because the system checks the input signal and automati- with the base of the projection screen (Fig.26). cally sets the most suitable values. If however the image If this adjustment is insufficient to centre the image, tilt the...
- Page 17 C3X1080 To do this, select the input in the pull down menu which appears when you press ◀, and choose whether to en- able or disable the input (Fig.29). Enabling or disabling of sources will automatically cause the renumbering of the remaining active inputs.
- Page 18 C3X 1080 The screen has six options, one for each line, and two MEMORIES columns indicating the keys F1-F2. You can select F1 and The main picture parameters can be saved in discrete F2 with the keys ◀ and ▶ on the remote control; select the sets of values called Memories so that they can be subse- function to assign to F1 or F2 with the keys ▼...
-
Page 19: Cleaning And Maintenance
C3X1080 USINg A MEMORY ments appear at the bottom of the screen one after the To use a Memory, select the line in question and press other when the ▼ and ▲ keys are pressed. the . key. The settings stored in the memory you have selected will be applied to the projected image, while a MESSAgES message will confirm that Memory has been applied. - Page 20 C3X 1080 with an identical type (T 5A H). • Adjust the horizontal and vertical position of the im- age with the IMAGE / POSITION menu (if available for If the fuse blows repeatedly, seek technical assistance • the input in question).
-
Page 21: Optional Accessories
C3X1080 13 OPTIONAL ACCESSORIES You can purchase the following optional accessories at your Dealer: CEILINg MOUNT KIT A range of lenses are available from our dealers to satisfy varying installation and projection distance needs. See the Additional Information chapter for greater details on projection distance and enlargement ratios. -
Page 22: Technical Specification
C3X 1080 14 TEChNICAL SPECIfICATIONS ELECTRONICS gENERAL: Mains cable: (EU, UK and US); 2m length Input signals: Mains: from 110 to 240 Vac (3,8-1,5 A) • COMPOSITE VIDEO (CVBS) Frequency: from 50 to 60 Hz gold plated RCA connectors 350 W max 1,0 V / 75 Ω, negative synchronisation... -
Page 23: Appendix
C3X 1080 APPENDIX DIMENSIONS C3X 1080 PROJECTION DISTANCES INSTALLATION INSTRUCTIONS... - Page 24 C3X1080 App.1 C3X 1080 DIMENSIONS (unit of measure: mm) 9,5 (0,37) (1,63) (2,86) 41,5 72,6 336 (13,23) 431,4 (16,99) (2,92) 141,2 (5,56) 76,05 285,2 (11,23) 142,6 434,5 (17,11) (5,62)
-
Page 25: App .1 Projection Distances
C3X 1080 App.2 PROJECTION DISTANCES 16:9 Metric Measure SCREEN PROJECTION DISTANCE Height offset* (Ho) Screen Size Screen Width Screen Height Min Projection Max Projection Min Projection Max Projection Min. Offset Min. Offset Min. Offset Max. Offset (Diagonal) Distance Distance Distance... - Page 26 C3X1080 App.2 PROJECTION DISTANCES 2.35.1 Metric Measure SCREEN PROJECTION DISTANCE Height offset* (Ho) Screen Size Screen Width Screen Height Min Projection Max Projection Min Projection Max Projection Min. Offset Min. Offset Min. Offset Max. Offset (Diagonal) Distance Distance Distance Distance Inches 1,43 1,76...
-
Page 27: App .3 Installation Instructions
C3X 1080 App.3 INSTALLATION INSTRUCTIONS (VERTICAL SHIFT) To install the HT3000 HOST system correctly place the projector so that the projected image completely fills the screen. Ideally, to avoid image distortion, the projector should be positioned perfectly perpendicular to the projection screen, as shown in the figure below. -
Page 28: Projection Lens
C3X1080 VERTICAL SHIFT (ASSUMING +50% OFFSET) If it is not possible to position the projector perdicular to the projection screen (with the centre of the lens in line with the centre of the screen) you can use the mechanical shift to move the projected image either above or below the centre of the projection lens. - Page 29 SIM2 Multimedia S.p.a. Viale Lino Zanussi, 11 33170 Pordenone - ITALY Phone +39,434,383,253-256 Fax +39.434.383260-261 www.sim2.com e-mail: info@sim2.it SIM2 USA Inc. 10108 USA Today Way 33025 Miramar FL - USA Phone +1.954.4422999 Fax +1.954.4422998 www.sim2usa.com e-mail: sales@sim2usa.com SIM2 Deutschland GmbH Arndtstrasse 34-36 - D-60325 Frankfurt Am Main Phone 0800.800.7462 (Germany only) Int.
